JAGUAR XFR 2010 1.G Workshop Manual 3. Special Tool(s): 204-267, 204-266, 204-265 4. CAUTIONS: Make sure the drive pinion flange has no end float and is free to rotate. Make sure that the drive pinion flange scribed

Page 554 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Rear Drive Axle/Differential - Differential Locking Motor Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 26-Feb-2014

Page 555 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 556 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 557 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 1. Torque: 11 Nm 2. CAUTIONS: Make sure that the mating faces are clean and free of foreign material. Apply a continuous bead

Page 558 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Axle/Differential, General Procedures). 5. www.JagDocs.com

Page 559 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 8. Torque: 25 Nm

Page 560 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Rear Drive Halfshafts - Lubricants, Fluids, Sealers and Adhesives Published: 11-May-2011 Item Specification Constant velocity (CV) grease Optimal LN 584 LO Fill Capacities Description Grams Greas
