Page 921 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 2. CAUTION: Install a new friction washer before installing the crankshaft pulley. NOTES: Make sure to clean the threads in the end of the crankshaft and that the crank nose is free of any f

Page 922 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 923 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 6. CAUTION: Rotate the crankshaft pulley installation tool anti-clockwise until the pulley is fully located, do not over tighten. Failure to do this may result in damge to the components.

Page 924 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 925 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 10. 11. 12. WARNING: Make sure that a new bolt is installed. Apply loctite 270 to the thread of the bolts. Torque: 65 Nm

Page 926 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 13. 14. 15. Torque: 65 Nm NOTE: The graphic shows the tool position for LH thread only, RH thread will be the opposite. Using a suitable stand, su

Page 927 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 16. 17. NOTES: The graphic shows the step for LH thread only, RH thread will be the opposite. The use of a torque multiplyer capable of 600Nm will be required. Make sure that t

Page 928 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 18. 19. WARNING: Make sure that a new bolt is installed. Apply loctite 270 to the thread of the bolts. Torque: 65 Nm
