Page 1209 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 3. Special Tool(s): 310-199 4. CAUTION: If the original fuel injector is being installed, the original fuel injector clamp must installed with the

Page 1210 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5. CAUTION: If a new cylinder head has been installed then the special tool 310-200-02 without the thread must be used to install the fuel rail. Special Tool(s): 310-200-01, 310-200-02

Page 1211 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 9. 10. 11. 12. NOTE: LH shown RH similar. Torque: 20 Nm NOTES: LH shown RH similar. Tighten in the sequence indi

Page 1212 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 13. 14. 15. NOTE: LH shown RH similar. Torque: 7 Nm NOTE: LH shown RH similar. CAUTION: L

Page 1213 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 17. NOTES: Do not tighten at this stage. Remove and discard the blanking caps. 18. WARNING: Do not work on or under a vehicle supported only by a jack. Always support t

Page 1214 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 20. 21. 22. NOTE: Engine shown removed for clarity. Torque: 21 Nm NOTE: Engine shown removed f

Page 1215 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 24. 25. NOTES: Lubricate the union threads with clean engine oil. Do not tighten at this stage. Remove

Page 1216 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 28. Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation). 29. 30. 31.
