Page 1449 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Transmission Fluid Level Check General Procedures WARNINGS: Activation O

Page 1450 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 7. CAUTIONS: The transmission fluid level must only be checked when the temperature of the fluid is between 30 degrees and 50 degrees. The fluid level obtained will be incorrect if the reading

Page 1451 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 9. 10. NOTE: Make sure the transmission fluid temperature does not exceed 50 °C (122 °F). If the transmission fluid temperature does exceed 50

Page 1452 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation). 15. Lower the vehicle. 16. Disconnect the Jaguar approved diagnostic equipment from the vehicle. www.JagDocs.com

Page 1453 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Transmission Fluid Drain and Refill General Procedures WARNINGS: Observe due

Page 1454 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5. CAUTION: Discard the component. Allow the fluid to drain. 6. CAUTION: Make sure that a new component is installed. Torque: 8 Nm 7. NO

Page 1455 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 8. Allow the transmission fluid to drain from the transmission fluid filler plug hole until the flow almost stops. 9. NOTE: Install a new sealing wa

Page 1456 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol, General Procedures).
