Page 2441 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 6. CAUTIONS: Protect the surrounding components. Protect the surrounding paintwork to avoid damage. 7. WARNING: This step requires the aid of

Page 2442 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 2. CAUTION: Touching the adhesive surface will impair rebonding. 3. WARNING: This step requires the aid of another technician. CAUTIONS: Make sure that the

Page 2443 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation). 7. Refer to: A-Pillar Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation). 8. Refer to: Cowl Vent Screen (501-02 Front End Body Panels, Removal and Insta

Page 2444 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Glass, Frames and Mechanisms - Door Window Regulator Motor Removal and Installation Removal Published: 11-May-2011 1. Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation,

Page 2445 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 4. NOTES: Make sure the door window glass is in the fully closed position. Components removed for clarity. Apply suitable adhesive tape to the door window glass and over the door frame,

Page 2446 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2447 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 2. CAUTIONS: Install all the bolts finger tight before final tightening. Care must be taken not to damage the outer door panel. Install the retaining bolt 1 to the witness mark on the

Page 2448 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Instrument panel retaining bolts 20 15 - Floor console retaining nuts 5 - 44 Instrument panel support brackets retaining bolts 9 - 80 Instrument panel support brackets retaining nuts 9 - 80
