Page 1577 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Fuel System - General Information - Quick Release Coupling General Procedures Disconnect Published: 11-May-2011 1. WARNINGS: Place the vehicle in a quarantined area and arrange "No Smok

Page 1578 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Fuel System - General Information - Quick Release Coupling - Push Connect General Procedures Disconnect 1. WARNINGS: Place the vehicle in a quarantined area and arr

Page 1579 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 1580 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Fuel system Electronic returnless fuel system (ERFS) Fuel tank Multi layer plastic Fuel tank sender unit Mounted on the body of the fuel pump Fuel filter Located in the fuel tank Fuel pump Electric,lo

Page 1581 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 1 Fuel feed pipe connection 2 EVAP pipe connection 3 Manifold 4 Low Pressure (LP) sensor 5 Fuel feed pipe 6 Fuel vapor vent valve 7 Fuel pump module assembly 8 Fuel tank www.JagDocs.com

Page 1582 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 10 FPDM (fuel pump driver module) 11 Fuel filler pipe 12 Fuel filler cap and lanyard 13 Charcoal canister 14 Pipe - EVAP charcoal canister to purge valve COMPONENT LOCATION - NORTH AMERICAN SPECIFICAT

Page 1583 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 8 Fuel tank 9 Fuel filler hose 10 FPDM 11 Anti-trickle valve 12 Fuel filler cap and lanyard 13 DMTL filter 14 Fuel filler pipe 15 Charcoal canister 16 DMTL pump 17 Pipe - EVAP charcoal canister to pur

Page 1584 of 3039

JAGUAR XFR 2010 1.G Workshop Manual the flow and pressure supplied by controlling the operation of the fuel pump using a PWM (pulse width modulation) output. A LP sensor is located in the fuel feed supply line to the engine and is moni
