Page 1481 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 7. CAUTION: Make sure the torque converter is fully located into the oil pump drive. 8. CAUTION: Make sure that the torque conver

Page 1482 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 9. 10. 11. NOTE: Transmission shown removed for clarity. Torque: 48 Nm Torque: 48 Nm

Page 1483 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 12. Torque: 45 Nm 13. Remove the support. 14. 15. Torque: 110 Nm CAUTION: Only rotate the crankshaft clockwise.

Page 1484 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 1485 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 19. 20. 21. Torque: 10 Nm CAUTION: Install new o-ring seals Torque: 10 Nm www.JagDocs.com

Page 1486 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 22. 23. 24. Refer to: Catalytic Converter LH (309-00C Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and Installation). 25. Refer to: Catalytic Co

Page 1487 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 30. CAUTION: Observe the engine temperature warning light. If the warning light is displayed, switch off immediately and allow to cool. Failure to follow this instruction may cause damage to the v

Page 1488 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 12-Sep-2011 Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Transmission and Transmission Fluid Cooler V8 5.0L Petrol/V8 S/C 5.0L Petrol Removal a
