Page 2969 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 10. 11. NOTE: Drill out from underneath to allow spot welds to be used in installation. If undamaged, retain the mounting bra

Page 2970 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2971 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2972 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 12. If the right-hand rear floor side extension is to be repaired, spot weld the AJB mounting bracket as indicated. 13. Dress all welded joints. 14. Make sure any remain

Page 2973 of 3039

JAGUAR XFR 2010 1.G Workshop Manual (100-00 General Information, Description and Operation) / Body Repairs (501-25A Body Repairs - General Information, Description and Operation) / Corrosion Protection (501-25B Body Repairs - Corrosio

Page 2974 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Rear End Sheet Metal Repairs - Rear Side Member Section Removal and Installation Removal Published: 11-May-2011 1. NOTE: The rear side member section is manufactured from High Strength Low

Page 2975 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Body and Frame (501-26 Body Repairs - Vehicle Specific Information and Tolerance Checks, Description and Operation). 7. Disconnect the generator electrical connectors. 8. Remove the luggage comp

Page 2976 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 13. 14. CAUTION: Care should be taken not to cut through into the rear side member. Mark out the position where the rear side
