Page 2281 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Interior Trim and Ornamentation - Sun Visor Vanity Mirror Removal and Installation General Equipment Published: 28-Jan-2013 Removal Installation 1. Using a suitable tool, release

Page 2282 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Luggage compartment lid moulding retaining nuts 3 - 26

Page 2283 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation). Installation 2. 3. NOTE: Note the fitted position of the locating pegs. 1. To install, reverse the removal procedure.

Page 2284 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Exterior Trim and Ornamentation - Luggage Compartment Lid Moulding Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation deta

Page 2285 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2286 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Exterior Trim and Ornamentation - Front Fender Moulding Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 03-Oct-2011

Page 2287 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Exterior Trim and Ornamentation - Rocker Panel Moulding Removal and Installation Removal CAUTIONS: Protect the surrounding paintwork to avoid damage. LH illustration shown, RH is simila

Page 2288 of 3039

JAGUAR XFR 2010 1.G Workshop Manual
