Page 1553 of 3039
Published: 11-May-2011
Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Catalytic Converter RH
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNINGS:
Make sure to support the vehicle with axle stands.
Observe due care when working near a hot exhaust system.
Raise and support the vehicle.
3. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).
4. Refer to: Engine Rear Undershield (501-02 Front End Body Panels, Removal and Installation).
5. CAUTION: Make sure the catalyst monitor sensor wiring
harness is not twisted more than 180 degrees and is not in
contact with either the exhaust or driveshaft.
Page 1554 of 3039
6. CAUTION: Make sure that the exhaust system is
supported with suitable retaining straps.
Tighten the top retaining nut first.
Torque:
Top nut 40 Nm Bottom nut 40 Nm
7. CAUTION: Make sure that the exhaust system is
supported with suitable retaining straps.
Torque: 55 Nm
8. CAUTIONS:
Make sure the anti-seize compound does not contact
the catalyst monitor sensor tip.
If accidentally dropped or knocked install a new
sensor.
NOTES:
Do not disassemble further if the component is
removed for access only.
If the original sensor is to be installed, apply lubricant
meeting specification ESE-M12A4-A to the thread of the
sensor.
Torque: 48 Nm
Installation
1. To install, reverse the removal procedure.
Page 1555 of 3039
2. NOTE: For NAS vehicles only.
If required, carry out a long drive cycle.
Refer to: Powertrain Control Module (PCM) Long Drive Cycle Self-Test (303-14D Electronic Engine Controls - V8 S/C 5.0L Petrol, General
Procedures).
Page 1556 of 3039
Published: 11-May-2011
Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Exhaust Sound
Enhancement Valve
Removal and Installation
Removal
WARNING: Observe due care when working near a hot exhaust system.
NOTES:
The exhaust sound enhancement valve is an integeral part of the muffler and cannot be serviced separately.
Removal steps in this procedure may contain installation details.
1. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
Installation
2. CAUTION: Make sure that these components are
installed to the noted removal position.
Torque:
M8 25 Nm M10 55 Nm
1. To install, reverse the removal procedure.
Page 1557 of 3039
Published: 11-May-2011
Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Exhaust System
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNINGS:
Make sure to support the vehicle with axle stands.
Observe due care when working near a hot exhaust system.
Raise and support the vehicle.
3. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).
4. Refer to: Engine Rear Undershield (501-02 Front End Body Panels, Removal and Installation).
5.
6. www.JagDocs.com
Page 1558 of 3039
7. CAUTION: Make sure that the exhaust system is
supported with suitable retaining straps.
Torque: 40 Nm
8. Torque: 40 Nm
Page 1559 of 3039
9.
10.
11. CAUTION: Make sure that the exhaust system is
supported with suitable retaining straps.
CAUTION: Make sure that the exhaust system is
supported with suitable retaining straps.
Torque: 30 Nm
CAUTION: Make sure that the exhaust system is
supported with suitable retaining straps.
Torque: 6 Nm
Page 1560 of 3039
Installation
12.
NOTE: Do not disassemble further if the component is
removed for access only.
Torque: 48 Nm
1. To install, reverse the removal procedure.
