JAGUAR XFR 2010 1.G Workshop Manual www.JagDocs.com

Page 2570 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Roof Opening Panel - Roof Opening Panel Frame Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011 1. Refer to:

Page 2571 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 6. WARNING: This step requires the aid of another technician. NOTE: Note the fitted position of the spacers. Torque: 8 Nm 7. NOTE: Do not disassemble further if the comp

Page 2572 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 9. Installation 1. CAUTION: Make sure that the component is correctly located on the locating dowels. NOTE: Replace the spacers to the fitted position. To install, reverse the

Page 2573 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Roof Opening Panel - Roof Opening Panel Glass Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. 1. 2. Published: 11-May-

Page 2574 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 1. To install, reverse the removal procedure. www.JagDocs.com

Page 2575 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Roof Opening Panel - Roof Opening Panel Motor Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011 1. Refer to:

Page 2576 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Roof Opening Panel - Roof Opening Panel Rear Drain Hose Removal and Installation Removal Published: 11-May-2011 1. Refer to: Loadspace Trim Panel RH (501-05 Interior Trim and Ornamentation, R
