AV-104
NAVIGATION SYSTEM
Revision: November 20092006 QX56
41–Shield
ground –– –
––
42 (W/L) Ground Audio RX
communica- tion signal Input ON
Operate audio
volume. Audio does not
operate properly.
43 (W) 41 RGB syn-
chronizing signal Input ON
Press the
“MAP ”
button. NAVI screen is
rolling.
44 (R/L) 45 RGB signal
(R: red) Input ON Select
“Display
Diagnosis (NAVI) ” of
CONFIRMATION/
ADJUSTMENT function. NAVI screen
looks bluish.
45 –Shield
ground –– –
––
46 (R/W) 45 RGB signal
(G: green) Input ON Select
“Display
Diagnosis (NAVI) ” of
CONFIRMATION/ ADJUSTMENT function. NAVI screen
looks reddish.
47 –Shield
ground –– –
––
48 (B) 45 RGB signal
(B: blue) Input ON Select
“Display
Diagnosis (NAVI) ” of
CONFIRMATION/
ADJUSTMENT function. NAVI screen
looks yellowish.
49 –Shield
ground –– –
––
50 (R/L) 47 RGB signal
(R: red) Output ON Select
“Display
Diagnosis (DCU) ” of
CONFIRMATION/ ADJUSTMENT
function. NAVI screen
looks bluish.
Terminal No.
(Wire color)
ItemSignal
input/
output Condition
Voltag e
(Approx.) Example of
symptom
+ – Igni-
tion
switch Operation
SKIA4403E
SKIA0164E
SKIA4977E
SKIA4978E
SKIA4979E
SKIA4980E
Page 698 of 3383

NAVIGATION SYSTEMAV-105
C
DE
F
G H
I
J
L
M A
B
AV
Revision: November 2009 2006 QX56
51 (B) 49RGB area
(YS) signal Output ON
Press the
“TRIP ”
button. RGB screen is
not shown.
52 (R/W) 47 RGB signal
(G: green) Output ON Select
“Display
Diagnosis (DCU) ” of
CONFIRMATION/ ADJUSTMENT function. Screen looks
reddish.
53 (W) 49 Vertical syn-
chronizing
(VP) signal Input ON
– Operating
screen for audio
and A/C is not
displayed when
showing NAVI
screen.
54 (B) 47 RGB signal
(B: blue) Output ON Select
“Display
Diagnosis (DCU) ” of
CONFIRMATION/ ADJUSTMENT
function. Screen looks
yellowish.
55 (R) 49 Horizontal
synchroniz-
ing (HP) sig- nal Input ON
– Operating
screen for audio
and A/C is not
displayed when
showing NAVI
screen.
56 (G) 49 RGB syn-
chronizing signal Output ON
Press the “
TRIP”
button. NAVI screen is
rolling.
Terminal No.
(Wire color)
ItemSignal
input/
output Condition
Voltage
(Approx.) Example of
symptom
+ – Igni-
tion
switch Operation
SKIA0162E
SKIA4981E
SKIA4983E
SKIA4982E
SKIA4983E
SKIA0164E
Page 699 of 3383

AV-106
NAVIGATION SYSTEM
Revision: November 20092006 QX56
Terminals and Reference Value for Display unitEKS00BJM
Terminal No. (Wire
color)
ItemSignal
input/
output Condition
Voltage
(Approx.) Example of
symptom
+ – Igni-
tion
switch Operation
1 (B) Ground Ground –ON – 0 V –
2 (L/W) Ground Power sup-
ply (Inverter) Input ON
– 9 VScreen is not
shown.
3 (L/R) Ground Power sup-
ply (Signal) Input ON
– 9 VScreen is not
shown.
6 (R/W) 7 RGB signal
(G: green) Input ON Select
“Display
Diagnosis (DCU) ” of
CONFIRMATION/
ADJUSTMENT function. Screen looks
reddish.
7 –Shield
ground –– –
––
8 (R) 21 Horizontal
synchroniz-
ing (HP) sig-
nal Output ON
– Operating
screen for audio
and A/C is not
displayed when
showing NAVI
screen.
9 (B) 21 RGB area
(YS) signal Input ON Press the “
TRIP”
button. RGB screen is
not shown.
11 (B/W) 23 Display com-
munication signal
(DCU-DSP) Input ON
– Though a screen
is displayed, it is
impossible to
adjust bright-
ness.
13 (P) Ground (Inverter)
Ground –
ON – 0 V –
14 (P/L) Ground (Signal)
Ground –
ON – 0 V –
17 (R/L) 7 RGB signal
(R: red) Input ON Select
“Display
Diagnosis (DCU) ” of
CONFIRMATION/ ADJUSTMENT
function. Screen looks
bluish.
SKIA4981E
SKIA4983E
SKIA0162E
SKIA4364E
SKIA4980E
Page 700 of 3383
NAVIGATION SYSTEMAV-107
C
DE
F
G H
I
J
L
M A
B
AV
Revision: November 2009 2006 QX56
18 (B) 7RGB signal
(B: blue) Input ON Select
“Display
Diagnosis (DCU) ” of
CONFIRMATION/
ADJUSTMENT function. Screen looks
yellowish.
19 (G) 21 RGB syn-
chronizing signal Input ON
Press the
“TRIP ”
button. NAVI screen is
rolling.
20 (W) 21 Ve r ti c a l s y n -
chronizing
(VP) signal Output ON
– Operating
screen for audio
and A/C is not
displayed when
showing NAVI
screen.
21 –Shield
ground –– –
––
22 (L) 23 Display com-
munication signal
(DSP-DCU) Output ON
– Though a screen
is displayed, it is
impossible to
adjust bright-
ness.
23 –Shield
ground –– –
––
Terminal No. (Wire
color)
ItemSignal
input/
output Condition
Vo l ta g e
(Approx.) Example of
symptom
+ – Igni-
tion
switch Operation
SKIA4982E
SKIA0164E
SKIA4983E
SKIA4363E
Page 701 of 3383

AV-108
NAVIGATION SYSTEM
Revision: November 20092006 QX56
Terminals and Reference Value for AV SwitchEKS00BJN
Terminal No.
(Wire color) ItemSignal
input/
output Condition
Voltage
(Approx.) Example of
symptom
+ – Ignition
switch Operation
1 (Y) Ground Battery
power Input OFF
-Battery voltage System does not
work properly.
2 (V) Ground ACC signal Input ACC -Battery voltage System does not
work properly.
3 (R/L) Ground Illumination
signal Input OFF Lighting switch is
ON (position 1).
Battery voltageAV switch illumi-
nation does not
come on when
lighting switch is
ON (position 1).
Turn lighting switch
OFF.
3.0V or less
4 (BR) Ground Illumination
control signal Input ON Illumination control
switch is operated
by lighting switch in
1st position. Changes between 0 and 12V.
AV switch illumi-
nation cannot be
controlled.
5 (B) Ground Ground - ON -0V -
6 (V) Ground Communica-
tion signal (+) Input/
output ON
- System does not
work properly.
7- Shield
ground -- -
--
8 (LG) Ground Communica-
tion signal (-) Input/
output ON
- System does not
work properly.
12 (R) Ground Remote con-
trol A Input ON Press MODE
switch 0V
Steering wheel
audio controls
do not function.
Press SEEK UP
switch 0.75V
Press VOL UP switch 2V
Except for above 5V
13 (G) Ground Remote con-
trol B Input ON Press POWER
switch 0V
Steering wheel
audio controls
do not function.
Press SEEK
DOWN switch 0.75V
Press VOL DOWN switch 2V
Except for above 5V
14 (L) - Remote con-
trol ground -- -
-Steering wheel
audio controls
do not function.
SKIA0175E
SKIA0176E
Page 702 of 3383

NAVIGATION SYSTEMAV-109
C
DE
F
G H
I
J
L
M A
B
AV
Revision: November 2009 2006 QX56
Terminals and Reference Value for BCMEKS00BJO
Te r m i n a l
No. Wire
color Signal name Measuring condition
Reference value
(Approx.)
Ignition
switch Operation or condition
2 SB Combination switch input 5 ONLighting, turn, wiper OFF
Wiper dial position 4
3 G/Y Combination switch input 4 ONLighting, turn, wiper OFF
Wiper dial position 4
4 Y Combination switch input 3 ONLighting, turn, wiper OFF
Wiper dial position 4
5 G/B Combination switch input 2 ONLighting, turn, wiper OFF
Wiper dial position 4
6 V Combination switch input 1
11 O Ignition switch (ACC) ACC— Battery voltage
32 R/G Combination switch output 5 ON Lighting, turn, wiper OFF
Wiper dial position 4
33 R/Y Combination switch output 4 ON Lighting, turn, wiper OFF
Wiper dial position 4
34 L Combination switch output 3 ON Lighting, turn, wiper OFF
Wiper dial position 4
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E
Page 703 of 3383
AV-110
NAVIGATION SYSTEM
Revision: November 20092006 QX56
35 O/B Combination switch output 2
ONLighting, turn, wiper OFF
Wiper dial position 4
36 R/W Combination switch output 1
38 W/L Ignition switch (ON) ON— Battery voltage
39 L CAN-H —— —
40 P CAN-L —— —
57 Y/R Battery power supply OFF— Battery voltage
67 B Ground ON— 0V
70 W/B Battery power supply (fusible link) OFF —Battery voltage
Terminal
No. Wire
color Signal name Measuring condition
Reference value
(Approx.)
Ignition
switch Operation or condition
SKIA5292E
Page 704 of 3383

NAVIGATION SYSTEMAV-111
C
DE
F
G H
I
J
L
M A
B
AV
Revision: November 2009 2006 QX56
On Board Self-Diagnosis FunctionEKS00BJP
DESCRIPTION
Diagnosis function consists of the self-diagnosis mode performed automatically and the CONFIRMATION/
ADJUSTMENT mode operated manually.
Self-diagnosis mode checks for connections between the units constituting this system, analyzes each
individual unit at the same time, and displays the results on the LCD screen.
CONFIRMATION/ADJUSTMENT mode is used to perform trouble diagnosis that require operation and
judgment by an operator (trouble that cannot be automatically judged by the system), to check/change the
set value, and to display the History of Errors of the navigation system.
DIAGNOSIS ITEM
NOTE:
Make the status that is set by D/N function be shown.
ModeDescription
Self-diagnosis (DCU) Display control unit diagnosis.
Self-diagnosis (NAVI)
NAVI Control unit diagnosis (DVD-ROM drive) will not be diagnosed
when no map DVD-ROM is in it.
Analyzes connection between the NAVI control unit and the GPS
antenna and operation of each unit.
CONFIRMATION/
ADJUSTMENT Display diagnosis
In display control unit mode, color tone and shading of the screen can be
checked by the display of a color bar and a gray scale.
Vehicle signals In display control unit mode, analyzes the following vehicle signals: Vehi-
cle speed signal, light signal
NOTE , ignition switch signal, and reverse sig-
nal.
Auto Climate Control A/C self-diagnosis of A/C system.
Navigation Display diagnosis
In NAVI C/U mode, color tone and shading of the screen can be checked
by the display of a color bar and a gray scale.
Vehicle signals In NAVI C/U mode, analyzes the following vehicle signals: Vehicle speed
signal, light signal, ignition switch signal, and reverse signal.
History of Errors Diagnosis results previously stored in the memory (before turning ignition
switch ON) are displayed in this mode. Time and location when/where the
errors occurred are also displayed.
Naviga-
tion Display Lon-
gitude & Lat-
itude
Display the map. Use the joystick to adjust position. Longitude and latitude
will be displayed.
Speed Cali-
bration Under ordinary conditions, the navigation system distance measuring
function will automatically compensate for minute decreases in wheel and
tire diameter caused by tire wear or low-pressure. Speed calibration imme-
diately restores system accuracy in cases such as when distance calibra-
tion is needed because of the use of tire chains in inclement weather.
Angle
adjustment Corrects difference between actual turning angle of a vehicle and turning
angle of the car mark on the display.
Initialize
Location This mode is for initializing the current location. Use when the vehicle is
transported a long distance on a trailer, etc.
CAN DIAG SUPPORT MONITOR Display status of CAN communication.
