OIL FILTER
2006 QX56
OIL FILTERPFP:15208
Removal and InstallationEBS00LMU
REMOVAL
1. Remove the engine front undercover using power tool.
2. Remove the oil filter using Tool.WARNING:
The oil filter is provided with a relief valve.
Use Genuine NISSAN oil filter or equivalent.
When removing, prepare a shop cloth to absorb any
engine oil leakage or spillage.
Do not allow engine oil to adhere to the drive belts.
Completely wipe off any engine oil that adheres to the
engine and the vehicle.
CAUTION:
Be careful not to get burned when the engine and engine oil are hot.
INSTALLATION
1. Remove foreign materials adhering to the oil filter installation surface.
2. Apply engine oil to the oil seal circumference of the new oil filter.
3. Screw the oil filter manually until it touches the installation sur- face, then tighten it by 2/3 turn. Or tighten to specification.
4. Inspect the engine for oil leakage. Refer to LU-10, "
INSPEC-
TION AFTER INSTALLATION" .
5. Install the engine front undercover using power tool.
INSPECTION AFTER INSTALLATION
1. Check the engine oil level. Refer to LU-7, "OIL LEVEL" .
2. Start the engine and check for engine oil leakage.
3. Stop the engine and wait for 10 minutes.
4. Check the engine oil level and add engine oil as required. Tool number : KV10115801 (J-38956)
WBIA0388E
SMA010
Oil filter : 17.7 N·m (1.8 kg-m, 13 ft-lb)
SMA229B
Page 2594 of 3383

OIL COOLERLU-11
C
DE
F
G H
I
J
K L
M A
LU
Revision: November 2009 2006 QX56
OIL COOLERPFP:21305
Removal and InstallationEBS00LMV
CAUTION:
Be careful not to burn yourself, as the engine oil and engine coolant are hot.
REMOVAL
1. Remove engine front undercover using power tool.
2. Disconnect water hoses, pinching hoses near oil cooler to prevent engine coolant from spilling.
CAUTION:
Do not spill engine coolant on the drive belt.
3. Remove oil filter. Refer to LU-10, "
Removal and Installation" .
CAUTION:
Do not spill engine oil on the drive belts.
4. Remove connector bolt, and remove oil cooler.
INSPECTION AFTER REMOVAL
Oil Cooler
Check oil cooler for cracks. Check oil cooler for clogging by blowing compressed air through engine coolant
inlet. If necessary, replace oil cooler assembly.
Relief Valve
Inspect relief valve for movement, cracks and breaks by pushing the ball. If replacement is necessary, remove
valve by prying it out using a suitable tool. Install a new valve in place by tapping it.
WBIA0414E
1. Oil pan 2. Water hose3. Water pipe
4. Water hose 5. Oil cooler bolt6. Oil filter
7. Oil cooler 8. O-ring9. Relief valve
10. Water hose 11. Connector pipe12. Gasket
Page 2595 of 3383
LU-12Revision: November 2009
OIL COOLER
2006 QX56
INSTALLATION
Installation is in the reverse order of removal, paying attention to the following:
Confirm that no foreign objects are adhering to the sealing sur-
faces of the oil cooler or oil pan.
Tighten the connecting bolt after aligning the stopper on the oil
pan side with protrusion of the oil cooler.
INSPECTION AFTER INSTALLATION
1. Check levels and add engine oil and engine coolant. Refer to LU-7, "OIL LEVEL" .
2. Start the engine, and check for leaks of engine oil and engine coolant.
3. Stop engine and wait for 10 minutes.
4. Check engine oil level and engine coolant level again.
KBIA2500E
Page 2596 of 3383
OIL PUMPLU-13
C
DE
F
G H
I
J
K L
M A
LU
Revision: November 2009 2006 QX56
OIL PUMPPFP:15010
Removal and InstallationEBS00LMW
REMOVAL
1. Remove front cover. Refer to EM-38, "REMOVAL" .
2. Remove the oil pump drive spacer.
3. Remove the oil pump.
INSTALLATION
Installation is in the reverse order of removal, paying attention of the following:
When inserting the oil pump drive spacer, align the crankshaft
key and the flat face of the inner rotor.
If they are not aligned, rotate the oil pump inner rotor by hand.
Make sure that the each part is aligned and tap lightly until it
reaches the end.
WBIA0415E
1. Oil pump body 2. Outer rotor3. Inner rotor
4. Oil pump cover 5. Oil pump drive spacer6. Regulator valve
7. Regulator spring 8. Regulator plug
KBIA2512E
KBIA2490E
Page 2597 of 3383

LU-14Revision: November 2009
OIL PUMP
2006 QX56
INSPECTION AFTER INSTALLATION
Start the engine, and check for leaks of engine oil.
Stop engine and wait 10 minutes.
Check level and add engine oil as required. Refer to LU-7, "ENGINE OIL" .
Disassembly and AssemblyEBS00LMX
DISASSEMBLY
1. Remove oil pump cover.
2. Remove inner rotor and outer rotor from oil pump body.
3. Remove the regulator plug, regulator spring and regulator valve.
INSPECTION AFTER DISASSEMBLY
Clearance of Oil Pump Parts
Measure radial clearance using a suitable tool.
Measure side clearance using suitable tools.
Calculate the clearance between inner rotor and oil pump body
as follows.
1. Measure the outer diameter of protruded portion of inner rotor (position 5) using suitable tool.Body to outer rotor (position 1)
: 0.114 - 0.200 mm (0.0045 - 0.0079 in)
Inner rotor to outer rotor tip (position 2)
: Below 0.180 mm (0.0071 in)
PBIC0139E
Body to inner rotor (position 3)
: 0.030 - 0.070 mm (0.0012 - 0.0028 in)
Body to outer rotor (position 4)
: 0.030 - 0.090 mm (0.0012 - 0.0035 in)
PBIC0140E
PBIC0141E
Page 2598 of 3383
OIL PUMPLU-15
C
DE
F
G H
I
J
K L
M A
LU
Revision: November 2009 2006 QX56
2. Measure the inner diameter of oil pump body to brazed portion
(position 6) using suitable tool.
3. Calculate the clearance using the following formula.
(Clearance) = (Inner diameter of oil pump body) - (Outer diameter of inner rotor)
Regulator Valve Clearance
Check regulator valve to oil pump cover clearance using the following formula.
(Clearance) = D1 (Valve hole diameter) - D2 (Outer Diameter of
valve)
CAUTION:
Coat regulator valve with engine oil.
Check that it falls smoothly into the regulator valve hole by
its own weight.
ASSEMBLY
Installation is in the reverse order of removal.
NOTE:
Install the inner rotor and outer rotor with the punched marks on the
oil pump cover side.
PBIC0142E
Inner rotor to brazed portion of housing
clearance
: 0.045 - 0.091 mm (0.0018 - 0.0036 in)
Regulator valve to oil pump cover
: 0.040 - 0.097 mm (0.0016 - 0.0038 in)
PBIC0143E
PBIC0144E
Page 2599 of 3383
LU-16Revision: November 2009
SERVICE DATA AND SPECIFICATIONS (SDS)
2006 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitEBS00LMY
OIL PRESSURE
Unit: kPa (kg/cm2, psi)
OIL PUMP
Unit: mm (in)
REGULATOR VALVE
Unit: mm (in)
ENGINE OIL CAPACITY (APPROXIMATE)
Unit: (US qt, Imp qt)
Engine speed
rpm Approximate discharge oil pressure
Idle speed 2,000 More than 98 (1.0, 14)
More than 294 (3.0, 43)
Body to outer rotor radial clearance 0.114 - 0.200 (0.0045 - 0.0079)
Inner rotor to outer rotor tip clearance Below 0.180 (0.0071)
Body to inner rotor side clearance 0.030 - 0.070 (0.0012 - 0.0028)
Body to outer rotor side clearance 0.030 - 0.090 (0.0012 - 0.0035)
Inner rotor to brazed portion of housing clearance 0.045 - 0.091 (0.0018 - 0.0036)
Regulator valve to oil pump cover clearance0.040 - 0.097 (0.0016 - 0.0038)
Drain and refillWith oil filter change 6.2 (6 1/2, 5-1/2)
Without oil filter change 5.9 (6-1/4, 5-1/4)
Dry engine (engine overhaul) 7.6 (8, 6-3/4)
Page 2600 of 3383
