LAN-124
[CAN]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
Inspection Between TCM and Driver Seat Control Unit CircuitUKS004TC
1. CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check following terminals and connectors for damage, bend and loose connection (connector side and harness side).
–Harness connector F14
–Harness connector E5
–Harness connector E34
–Harness connector B40
OK or NG
OK >> GO TO 2.
NG >> Repair terminal or connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect A/T assembly connector and harness connector F14.
2. Check continuity between A/T assembly harness connector (A) and harness connector (B).
OK or NG
OK >> GO TO 3.
NG >> Repair harness.
3. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector E34.
2. Check continuity between harness connector (A) and harness connector (B).
OK or NG
OK >> GO TO 4.
NG >> Repair harness.
AB Continuity
Connector Terminal Connector Terminal
F9 3
F14 5 Yes
81 5Yes
PKIC3825E
AB
Continuity
Connector Terminal Connector Terminal
E5 5
E34 24 Yes
15 23Yes
PKIC3826E
Page 2394 of 3383
![INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSIS FOR SYSTEMLAN-125
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
4. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector B37.
2. Check continuity betwee INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSIS FOR SYSTEMLAN-125
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
4. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector B37.
2. Check continuity betwee](/manual-img/42/57028/w960_57028-2393.png)
TROUBLE DIAGNOSIS FOR SYSTEMLAN-125
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
4. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector B37.
2. Check continuity between harness connector (A) and harness connector (B).
OK or NG
OK >> Connect all the connectors and diagnose again. Refer to LAN-5, "
TROUBLE DIAGNOSES WORK FLOW" .
NG >> Repair harness.
Inspection Between ICC Sensor and ICC Unit CircuitUKS004TD
1. CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check following terminals and connectors for damage, bend and loose connection (connector side and harness side).
–Harness connector E34
–Harness connector B40
OK or NG
OK >> GO TO 2.
NG >> Repair terminal or connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect ICC sensor connector and harness connector E34.
2. Check continuity between ICC sensor harness connector (A) and harness connector (B).
OK or NG
OK >> GO TO 3.
NG >> Repair harness.
AB Continuity
Connector Terminal Connector Terminal
B40 24
B37 15 Yes
23 14Yes
PKIC3828E
AB
Continuity
Connector Terminal Connector Terminal
E42 2
E34 24 Yes
32 3Yes
PKIC3837E
Page 2395 of 3383
![INFINITI QX56 2006 Factory Service Manual LAN-126
[CAN]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
3. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect ICC unit connector.
2. Check continuity between harness connector (A) and IC INFINITI QX56 2006 Factory Service Manual LAN-126
[CAN]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
3. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect ICC unit connector.
2. Check continuity between harness connector (A) and IC](/manual-img/42/57028/w960_57028-2394.png)
LAN-126
[CAN]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
3. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect ICC unit connector.
2. Check continuity between harness connector (A) and ICC unit harness connector (B).
OK or NG
OK >> Connect all the connectors and diagnose again. Refer to LAN-5, "
TROUBLE DIAGNOSES WORK FLOW" .
NG >> Repair harness.
Inspection Between ICC Unit and Driver Seat Control Unit CircuitUKS004TE
1. CHECK HARNESS FOR OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect ICC unit connector and harness connector B37.
4. Check continuity between ICC unit harness connector (A) and harness connector (B).
OK or NG
OK >> Connect all the connectors and diagnose again. Refer to LAN-5, "
TROUBLE DIAGNOSES WORK FLOW" .
NG >> Repair harness.
Inspection Between Driver Seat Control Unit and Data Link Connector CircuitUKS004TG
1. CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check following terminals and connectors for damage, bend and loose connection (connector side and harness side).
–Harness connector B69
–Harness connector M40
OK or NG
OK >> GO TO 2.
NG >> Repair terminal or connector.
AB Continuity
Connector Terminal Connector Terminal
B40 24
B13 14 Yes
23 5Yes
PKIC3838E
AB
Continuity
Connector Terminal Connector Terminal
B13 14
B37 15 Yes
51 4Yes
PKIC3839E
Page 2396 of 3383
![INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSIS FOR SYSTEMLAN-127
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector B37 and harness connector B69.
INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSIS FOR SYSTEMLAN-127
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector B37 and harness connector B69.](/manual-img/42/57028/w960_57028-2395.png)
TROUBLE DIAGNOSIS FOR SYSTEMLAN-127
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector B37 and harness connector B69.
2. Check continuity between harness connector (A) and harness connector (B).
OK or NG
OK >> GO TO 3.
NG >> Repair harness.
3. CHECK HARNESS FOR OPEN CIRCUIT
Check continuity between harness connector (A) and data link con-
nector (B).
OK or NG
OK >> Connect all the connectors and diagnose again. Refer to LAN-5, "
TROUBLE DIAGNOSES WORK FLOW" .
NG >> Repair harness.
Inspection Between Data Link Connector and ABS Actuator and Electric Unit
(Control Unit) Circuit
UKS004TH
1. CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check following terminals and connectors for damage, bend and loose connection (connector side and harness side).
–Harness connector M31
–Harness connector E152
OK or NG
OK >> GO TO 2.
NG >> Repair terminal or connector.
AB Continuity
Connector Terminal Connector Terminal
B37 15
B69 51J Yes
14 52JYes
PKIC3832E
AB
Continuity
Connector Terminal Connector Terminal
M40 51J
M22 6 Yes
52J 14Yes
PKIC3830E
Page 2397 of 3383
![INFINITI QX56 2006 Factory Service Manual LAN-128
[CAN]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector M31.
2. Check continuity between data link connector (A) a INFINITI QX56 2006 Factory Service Manual LAN-128
[CAN]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect harness connector M31.
2. Check continuity between data link connector (A) a](/manual-img/42/57028/w960_57028-2396.png)
LAN-128
[CAN]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
2. CHECK HARNESS FOR OPEN CIRCUIT
