Page 2585 of 3383

INFINITI QX56 2006 Factory Service Manual LU-2Revision: November 2009 PRECAUTIONS 2006 QX56 PRECAUTIONSPFP:00001 Precautions for Liquid GasketEBS00NIH REMOVAL OF LIQUID GASKET SEALING After removing the bolts and nuts, separate the mating su

Page 2586 of 3383

INFINITI QX56 2006 Factory Service Manual PREPARATIONLU-3 C DE F G H I J K L M A LU Revision: November 2009 2006 QX56 PREPARATIONPFP:00002 Special Service ToolsEBS00LMO The actual shapes of Kent-Moore tools may differ from those of special se

Page 2587 of 3383

INFINITI QX56 2006 Factory Service Manual LU-4Revision: November 2009 PREPARATION 2006 QX56 Commercial Service ToolEBS00LMP Tool nameDescription Power tool Loosening bolts and nuts Deep socket Removing and installing oil pressure switch Deep

Page 2588 of 3383

INFINITI QX56 2006 Factory Service Manual LUBRICATION SYSTEMLU-5 C DE F G H I J K L M A LU Revision: November 2009 2006 QX56 LUBRICATION SYSTEMPFP:15010 Lubrication CircuitEBS00LMQ WBIA0399E 1. Exhaust camshaft2. Intake camshaft3. Main oil ga

Page 2589 of 3383

INFINITI QX56 2006 Factory Service Manual LU-6Revision: November 2009 LUBRICATION SYSTEM 2006 QX56 System DrawingEBS00LMR PBIC1901E

Page 2590 of 3383

INFINITI QX56 2006 Factory Service Manual ENGINE OILLU-7 C DE F G H I J K L M A LU Revision: November 2009 2006 QX56 ENGINE OILPFP:KLA92 InspectionEBS00LMS OIL LEVEL Before starting the engine make sure the vehicle is parked on a flat and le

Page 2591 of 3383

INFINITI QX56 2006 Factory Service Manual LU-8Revision: November 2009 ENGINE OIL 2006 QX56 5. Install Tools. 6. Start the engine and warm it up to normal operating temperature. 7. Check the engine oil pressure with engine running under no-loa

Page 2592 of 3383

INFINITI QX56 2006 Factory Service Manual ENGINE OILLU-9 C DE F G H I J K L M A LU Revision: November 2009 2006 QX56 Engine oil capacity (Approximate):
