2006 INFINITI QX56 Factory Service Manual

adding oil navigation update wiring steering wheel airbag off lug pattern

Load previous 8 pages

Page 17 of 3383

INFINITI QX56 2006 Factory Service Manual ACS-4
[ICC]
PRECAUTIONS
Revision: November 20092006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EKS00BLC
The Suppleme

Page 18 of 3383

INFINITI QX56 2006 Factory Service Manual PREPARATIONACS-5
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
PREPARATIONPFP:00002
Special Service ToolEKS00BLF
The actual shapes of Kent-Moore tools may differ from those of spe

Page 19 of 3383

INFINITI QX56 2006 Factory Service Manual ACS-6
[ICC]
DESCRIPTION
Revision: November 20092006 QX56
DESCRIPTIONPFP:00000
OutlineEKS00BLG
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
a

ACS-6
[ICC]
DESCRIPTION
Revision: November 20092006 QX56
DESCRIPTIONPFP:00000
OutlineEKS00BLG
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
ahead according to that vehicle's speed, or at the set speed, if the road ahead is clear.
The ICC function has two cruise control modes and brake assist (with preview function). The ICC system may
AUTO-CANCEL for various reasons, for example, when the windshield wipers are operating.
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
Vehicle-to-vehicle distance control mode, the same speed as other vehicles, can be maintained without the
constant need to adjust the operating speed as with a conventional cruise control system.
The system is intended to enhance the operation of the vehicle when following another vehicle in the same
lane and direction.
If the distance sensor detects a slower moving vehicle ahead, the system will reduce speed so that the vehicle
ahead can be followed at the selected distance.
The system automatically controls the throttle and applies the brakes (up to 25% of vehicle braking power) if
necessary.
The detection range of the sensor is approximately 120 m (390 ft) ahead.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Conventional (fixed speed) cruise control mode is cruising at preset speeds.
Refer to Owner's Manual for Intelligent Cruise Control System operation instructions.
BRAKE ASSIST (WITH PREVIEW FUNCTION)
When the force applied to brake pedal exceeds a certain level, the brake assist is activated and generates a
greater braking force than that of a conventional brake booster, even with light pedal force.
When the preview function identifies the need to apply the sudden brake by sensing the vehicle ahead in the
same lane and the distance and relative speed from it, it applies the brake pre-pressure before driver
depresses the brake pedal and improves brake response by reducing its free play.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
System DiagramEKS00BLH
WKIA1976E

Page 20 of 3383

INFINITI QX56 2006 Factory Service Manual DESCRIPTIONACS-7
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
Components DescriptionEKS00BLI
CAN CommunicationEKS00BLJ
SYSTEM DESCRIPTION
Refer to LAN-26, "CAN COMMUNICATION" .
S

Page 21 of 3383

INFINITI QX56 2006 Factory Service Manual ACS-8
[ICC]
DESCRIPTION
Revision: November 20092006 QX56
ICC System DisplayEKS00BLL
4 CANCEL switchDeactivates system without erasing set speed.
5 DISTANCE switch Changes the following distance from:

Page 22 of 3383

INFINITI QX56 2006 Factory Service Manual ACTION TESTACS-9
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
ACTION TESTPFP:00000
ICC System Running TestEKS00BLM
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
SET CHECKING
1. Press

ACTION TESTACS-9
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
ACTION TESTPFP:00000
ICC System Running TestEKS00BLM
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
SET CHECKING
1. Press the ON/OFF switch for less than 1.5 seconds.
2. Drive the vehicle between 40 km/h (25 MPH) and 144 km/h (89 MPH).
3. Push the COAST/SET switch.
4. Confirm that the desired speed is set as the COAST/SET switch is released.
NOTE:
When there is no vehicle ahead, drive at the set speed steadily.
When there is a vehicle ahead, control to maintain distance from the vehicle ahead, watching its speed.
The set vehicle speed is displayed on the ICC system indicator in the combination meter.
CHECK FOR INCREASE OF THE CRUISING SPEED
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed increases by 1.6 km/h (1 MPH) as ACCEL/RES switch is pushed.
NOTE:
The maximum set speed of the vehicle-to-vehicle distance control mode is 144 km/h (89 MPH).
CHECK FOR DECREASE OF THE CRUISING SPEED
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed decreases by 1.6 km/h (1 MPH) as COAST/SET switch is pushed.
NOTE:
Vehicle-to-vehicle distance control mode is automatically turned off when the driving speed lowers to 32
km/h (20 MPH) due to the deceleration of the vehicle ahead.
The minimum set speed of the vehicle-to-vehicle distance control mode is 40 km/h (25 MPH).
CHECK FOR THE CANCELLATION OF VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
(NORMAL DRIVING CONDITION) IN THE FOLLOWING CASES:
1. When the brake pedal is depressed after the system is turned on.
2. When the selector lever is shifted to the "N" (Neutral) position.
3. When the system is turned off.
4. When CANCEL switch is operated.
CHECK FOR RESTORING THE SPEED THAT IS SET BY VEHICLE-TO-VEHICLE DISTANCE
CONTROL MODE BEFORE CANCELLATION
1. Cancel the system by depressing the brake. Then, check that the speed before cancellation is restored
when pressing ACCEL/RES switch with vehicle speed at 40 km/h (25 MPH) or above.
2. Cancel the system by shifting the selector lever to “N”. Then, check if the speed set before the cancella-
tion is restored when ACCEL/RES switch is pressed.
3. Check if the speed previously set is restored when ACCEL/RES switch is operated when driving 40 km/h (25 MPH) or above, after canceling vehicle-to-vehicle distance control mode by operating the CANCEL
switch.
CHECK ON/OFF SWITCH OPERATION
1. Start the engine. Then, check that the following operations areperformed correctly.
2. Vehicle-to-vehicle distance control mode is displayed when ON/ OFF switch is pressed ON. Vehicle-to-vehicle distance control
mode goes off when ON/OFF switch is turned to OFF.
3. Turn off the ignition switch while ON/OFF switch is ON. Turn the ignition switch back to ON and confirm that CRUISE lamp and
ICC system display are OFF.
WKIA1978E

Page 23 of 3383

INFINITI QX56 2006 Factory Service Manual ACS-10
[ICC]
ACTION TEST
Revision: November 20092006 QX56
CHECK FOR ACCEL/RES, COAST/SET, CANCEL SWITCHES
1. Check if ACCEL/RES, COAST/SET, CANCEL switches operate smoothly.
2. Check if switch buttons

Page 24 of 3383

INFINITI QX56 2006 Factory Service Manual ACTION TESTACS-11
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
CHECK FOR INCREASE OF THE CRUISING SPEED
1. Set the conventional (fixed speed) cruise control mode at desired speed
