INFINITI QX56 2006 Factory Service Manual BCS-16
BCM (BODY CONTROL MODULE)
Revision: November 20092006 QX56
8. Configuration of current BCM is printed out automatically. A list-
ing of manual setting items and auto setting items will be dis-

Page 778 of 3383

INFINITI QX56 2006 Factory Service Manual BCM (BODY CONTROL MODULE)BCS-17
C
DE
F
G H
I
J
L
M A
B
BCS
Revision: November 2009 2006 QX56
2. Touch “START (NISSAN BASED VHCL) ”.
3. Touch “BCM” on “SELECT SYSTEM ” screen.
If "BCM" is

Page 779 of 3383

INFINITI QX56 2006 Factory Service Manual BCS-18
BCM (BODY CONTROL MODULE)
Revision: November 20092006 QX56
6. Touch “JA60” and "OK" on “VEHICLE SELECT ” screen. For
canceling, touch "CANCEL" on "VEHICLE SELECT" screen.
NOTE:
Confirm

Page 780 of 3383

INFINITI QX56 2006 Factory Service Manual BCM (BODY CONTROL MODULE)BCS-19
C
DE
F
G H
I
J
L
M A
B
BCS
Revision: November 2009 2006 QX56
11 . To u c h “OK” on "WRITE CONFIGURATION" screen.
If "CANCEL" is touched, it will return to previous

Page 781 of 3383

INFINITI QX56 2006 Factory Service Manual BCS-20
BCM (BODY CONTROL MODULE)
Revision: November 20092006 QX56
BCMEKS00D82
REMOVAL AND INSTALLATION
NOTE:
If possible, before removing BCM, retrieve current BCM configuration to use for reference w

Page 782 of 3383

INFINITI QX56 2006 Factory Service Manual BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
DE
F
G H
J
K L
M
SECTION
A
B
BL
