Page 2337 of 3383

INFINITI QX56 2006 Factory Service Manual LAN-68 [CAN] CAN SYSTEM (TYPE 2) Revision: November 20092006 QX56 Case 9 Check ICC unit circuit. Refer to LAN-130, "ICC Unit Circuit Inspection" . PKIC3527E PKIC3025E

Page 2338 of 3383

INFINITI QX56 2006 Factory Service Manual CAN SYSTEM (TYPE 2)LAN-69 [CAN] C DE F G H I J L M A B LAN Revision: November 2009 2006 QX56 Case 10 Check driver seat control unit circuit. Refer to LAN-130, "Driver Seat Control Unit Circuit Inspect

Page 2339 of 3383

INFINITI QX56 2006 Factory Service Manual LAN-70 [CAN] CAN SYSTEM (TYPE 2) Revision: November 20092006 QX56 Case 11 Check combination meter circuit. Refer to LAN-131, "Combination Meter Circuit Inspection" . PKIC3529E PKIC3027E

Page 2340 of 3383

INFINITI QX56 2006 Factory Service Manual CAN SYSTEM (TYPE 2)LAN-71 [CAN] C DE F G H I J L M A B LAN Revision: November 2009 2006 QX56 Case 12 Check display control unit circuit. Refer to LAN-131, "Display Control Unit Circuit Inspection" . P

Page 2341 of 3383

INFINITI QX56 2006 Factory Service Manual LAN-72 [CAN] CAN SYSTEM (TYPE 2) Revision: November 20092006 QX56 Case 13 Check BCM circuit. Refer to LAN-132, "BCM Circuit Inspection" . PKIC3531E PKIC3029E

Page 2342 of 3383

INFINITI QX56 2006 Factory Service Manual CAN SYSTEM (TYPE 2)LAN-73 [CAN] C DE F G H I J L M A B LAN Revision: November 2009 2006 QX56 Case 14 Check data link connector circuit. Refer to LAN-132, "Data Link Connector Circuit Inspection" . PKI

Page 2343 of 3383

INFINITI QX56 2006 Factory Service Manual LAN-74 [CAN] CAN SYSTEM (TYPE 2) Revision: November 20092006 QX56 Case 15 Check steering angle sensor circuit. Refer to LAN-133, "Steering Angle Sensor Circuit Inspection" . PKIC3533E PKIC3031E

Page 2344 of 3383

INFINITI QX56 2006 Factory Service Manual CAN SYSTEM (TYPE 2)LAN-75 [CAN] C DE F G H I J L M A B LAN Revision: November 2009 2006 QX56 Case 16 Check front air control circuit. Refer to LAN-133, "Front Air Control Circuit Inspection" . PKIC353
