BL-68
REMOTE KEYLESS ENTRY SYSTEM
Revision: November 20092006 QX56
ACC Power CheckEIS00606
1. CHECK ACC POWER
With CONSULT-II
Check "ACC ON SW" in DATA MONITOR mode with CONSULT –II. Refer to BL-27, "
DATA MONITOR" .
Without CONSULT-II
Check voltage between BCM connector M18 terminal 11 and
ground.
OK or NG
OK >> ACC power circuit is OK.
NG >> Check the following:
10A fuse [No. 4, located in fuse block (J/B)]
Harness for open or short.
IPDM E/R Operation CheckEIS00607
1. CHECK IPDM E/R INPUT VOLTAGE
Check voltage between IPDM E/R connector E122 terminal 45 and
ground.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
Monitor Item Condition
ACC ON SW Ignition switch position ACC : ON
Ignition switch position OFF : OFF
PIIA3367E
ConnectorTerminals
ConditionVoltage (V)
(Approx.)
(+) ( –)
M18 11 Ground ACC
Battery voltage
OFF 0
PIIA7002E
ConnectorTerminals
Voltage (V)
(Approx.)
(+) (– )
E122 45 Ground Battery voltage
LIIA1053E
Page 850 of 3383
REMOTE KEYLESS ENTRY SYSTEMBL-69
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
2. CHECK IPDM E/R INPUT VOLTAGE
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and horn relay.
3. Check continuity between IPDM E/R connector E122 terminal 45 and horn relay connector H-1 terminal 1.
4. Check continuity between IPDM E/R connector E122 terminal 45 and ground.
OK or NG
OK >> Further inspection is necessary. Refer to BL-60, "SYMP-
TOM CHART" .
NG >> Repair or replace harness 45 - 1
: Continuity should exist.
45 - Ground : Continuity should not exist.WIIA0679E
Page 851 of 3383

BL-70
REMOTE KEYLESS ENTRY SYSTEM
Revision: November 20092006 QX56
Check Hazard FunctionEIS00608
1. CHECK HAZARD WARNING LAMP
Does hazard indicator flash with hazard switch?
Ye s o r N o
Yes >> Hazard warning lamp circuit is OK.
No >> Check hazard indicator. Refer to LT- 8 0 , "
TURN SIGNAL AND HAZARD WARNING LAMPS" .
Check Horn FunctionEIS00609
First, perform the "SELF-DIAG RESULTS" in "BCM" with CONSULT-II, then perform the trouble diagnosis of
malfunction system indicated in "SELF-DIAG RESULTS" of "BCM".
1. CHECK HORN FUNCTION
Does horn sound with horn switch?
Ye s o r N o
Yes >> Horn circuit is OK.
No >> Check horn circuit. Refer to WW-55, "
HORN" .
Check Headlamp FunctionEIS0060A
First, perform the "SELF-DIAG RESULTS" in "BCM" with CONSULT-II, then perform the trouble diagnosis of
malfunction system indicated in "SELF-DIAG RESULTS" of "BCM".
1. CHECK HEADLAMP OPERATION
Does headlamp come on when turning lighting switch ON?
Ye s o r N o
Yes >> Headlamp operation circuit is OK.
No >> Check headlamp circuit. Refer to LT- 5 , "
HEADLAMP (FOR USA)" .
Check Map Lamp Illumination FunctionEIS0060B
1. CHECK MAP LAMP ILLUMINATION FUNCTION
When map lamp switch is in DOOR position, open the front door LH or RH.
OK or NG
OK >> System is OK.
NG >> Check map lamp illumination circuit. Refer to LT- 1 5 7 , "
ILLUMINATION" .
Map lamp and ignition keyhole illumination should illuminate.
Page 852 of 3383

REMOTE KEYLESS ENTRY SYSTEMBL-71
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
ID Code Entry ProcedureEIS0060C
KEYFOB ID SET UP WITH CONSULT-II
NOTE:
If a keyfob is lost, the ID code of the lost keyfob must be erased to prevent unauthorized use. A
specific ID code can be erased with CONSULT-II. However, when the ID code of a lost keyfob is not
known, all controller ID codes should be erased. After all ID codes are erased, the ID codes of all
remaining and/or new keyfobs must be re-registered.
When registering an additional keyfob, the existing ID codes in memory may or may not be erased.
If five ID codes are stored in memory when an additional code is registered, only the oldest code is
erased. If less than five codes are stored in memory when an additional code is registered, the
new ID code is added and no ID codes are erased.
Entry of a maximum of five ID codes is allowed. When more than five codes are entered, the oldest
ID code will be erased.
Even if the same ID code that is already in memory is input, the same ID code can be entered. The
code is counted as an additional code.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to the data link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL) ”.
5. Touch “BCM”.
If "BCM" is not indicated, refer to GI-40, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BBIA0336E
BCIA0029E
BCIA0030E
Page 853 of 3383
BL-72
REMOTE KEYLESS ENTRY SYSTEM
Revision: November 20092006 QX56
6. Touch “MULTI REMOTE ENT ”.
7. Touch “WORK SUPPORT ”.
8. The items are shown on the figure can be set up.
“REMO CONT ID REGIST ”
Use this mode to register a keyfob ID code.
NOTE:
Register the ID code when keyfob or BCM is replaced, or
when additional keyfob is required.
“REMO CONT ID ERASUR ”
Use this mode to erase a keyfob ID code.
“REMO CONT ID CONFIR ”
Use this mode to confirm if a keyfob ID code is registered or
not.
LIIA0194E
BCIA0031E
LIIA1147E
Page 854 of 3383
REMOTE KEYLESS ENTRY SYSTEMBL-73
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
KEYFOB ID SET UP WITHOUT CONSULT-II
LIIA1670E
Page 855 of 3383

BL-74
REMOTE KEYLESS ENTRY SYSTEM
Revision: November 20092006 QX56
NOTE:
If a keyfob is lost, the ID code of the lost keyfob must be erased to prevent unauthorized use. A specific ID
code can be erased with CONSULT-II. However, when the ID code of a lost keyfob is not known, all con-
troller ID codes should be erased. After all ID codes are erased, the ID codes of all remaining and/or new
keyfobs must be re-registered.
To erase all ID codes in memory, register one ID code (keyfob) five times. After all ID codes are erased,
the ID codes of all remaining and/or new keyfobs must be re-registered.
When registering an additional keyfob, the existing ID codes in memory may or may not be erased. If five
ID codes are stored in memory, when an additional code is registered, only the oldest code is erased. If
less than five ID codes are stored in memory, when an additional ID code is registered, the new ID code is
added and no ID codes are erased.
If you need to activate more than two additional new keyfobs, repeat the procedure “Additional ID code
entry ” for each new keyfob.
Entry of maximum five ID codes is allowed. When more than five ID codes are entered, the oldest ID code
will be erased.
Even if same ID code that is already in the memory is input, the same ID code can be entered. The code
is counted as an additional code.
Keyfob Battery ReplacementEIS0060D
LIIA1514E
Page 856 of 3383
VEHICLE SECURITY (THEFT WARNING) SYSTEMBL-75
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
VEHICLE SECURITY (THEFT WARNING) SYSTEMPFP:28491
Component Parts and Harness Connector LocationEIS0060E
LIIA2374E
1. Fuse block (J/B)2. Fuse and fusible link box3. IPDM E/R fuse layout
4. IPDM E/R E122, E123, E124 5. Steering column
(view with instrument panel LH
removed) 6. Data link connector M22
(view with instrument panel LH
removed)
