Page 2137 of 3383

INFINITI QX56 2006 Factory Service Manual GI-46
RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS
Revision: November 20092006 QX56
RECOMMENDED CHEMICAL PRODUCTS AND SEALANTSPFP:00000
Recommended Chemical Products and SealantsEAS001G1
Refer to the fo

Page 2138 of 3383

INFINITI QX56 2006 Factory Service Manual IDENTIFICATION INFORMATIONGI-47
C
DE
F
G H
I
J
K L
M B
GI
Revision: November 2009 2006 QX56
IDENTIFICATION INFORMATIONPFP:00010
Model VariationEAS001G2
Prefix and suffix designations:
Drive Type Body

Page 2139 of 3383

INFINITI QX56 2006 Factory Service Manual GI-48
IDENTIFICATION INFORMATION
Revision: November 20092006 QX56
Identification NumberEAS001G3
VEHICLE IDENTIFICATION NUMBER ARRANGEMENT
1. Emission control information label 2. Tire placard3. F.M.V.

Page 2140 of 3383

INFINITI QX56 2006 Factory Service Manual IDENTIFICATION INFORMATIONGI-49
C
DE
F
G H
I
J
K L
M B
GI
Revision: November 2009 2006 QX56
ENGINE SERIAL NUMBER
TRANSFER SERIAL NUMBER
AUTOMATIC TRANSMISSION NUMBER
LAIA0044E
LAIA0048E
PAIA0054E

Page 2141 of 3383

INFINITI QX56 2006 Factory Service Manual GI-50
IDENTIFICATION INFORMATION
Revision: November 20092006 QX56
DimensionsEAS001G4
Unit: mm (in)
Wheels & TiresEAS001G5
Drive type2WD 4WD
Overall length 5255 (206.9) 5255 (206.9)
Overall width 2001

Page 2142 of 3383

INFINITI QX56 2006 Factory Service Manual TERMINOLOGYGI-51
C
DE
F
G H
I
J
K L
M B
GI
Revision: November 2009 2006 QX56
TERMINOLOGYPFP:00011
SAE J1930 Terminology List EAS001G6
All emission related terms used in this publication in accordance

TERMINOLOGYGI-51
C
DE
F
G H
I
J
K L
M B
GI
Revision: November 2009 2006 QX56
TERMINOLOGYPFP:00011
SAE J1930 Terminology List EAS001G6
All emission related terms used in this publication in accordance with SAE J1930 are listed. Accordingly, new
terms, new acronyms/abbreviations and old terms are listed in the following chart.
NEW TERMNEW ACRONYM /
ABBREVIATION OLD TERM
Air cleaner ACLAir cleaner
Barometric pressure BARO***
Barometric pressure sensor-BCDD BAROS-BCDD BCDD
Camshaft position CMP***
Camshaft position sensor CMPSCrank angle sensor
Canister ***Canister
Carburetor CARBCarburetor
Charge air cooler CACIntercooler
Closed loop CLClosed loop
Closed throttle position switch CTP switchIdle switch
Clutch pedal position switch CPP switchClutch switch
Continuous fuel injection system CFI system***
Continuous trap oxidizer system CTOX system***
Crankshaft position CKP***
Crankshaft position sensor CKPS***
Data link connector DLC***
Data link connector for CONSULT-II DLC for CONSULT-II Diagnostic connector for CONSULT-II
Diagnostic test mode DTMDiagnostic mode
Diagnostic test mode selector DTM selectorDiagnostic mode selector
Diagnostic test mode I DTM IMode I
Diagnostic test mode II DTM IIMode II
Diagnostic trouble code DTCMalfunction code
Direct fuel injection system DFI system***
Distributor ignition system DI systemIgnition timing control
Early fuel evaporation-mixture heater EFE-mixture heater Mixture heater
Early fuel evaporation system EFE systemMixture heater control
Electrically erasable programmable read
only memory EEPROM
***
Electronic ignition system EI systemIgnition timing control
Engine control EC***
Engine control module ECMECCS control unit
Engine coolant temperature ECTEngine temperature
Engine coolant temperature sensor ECTS Engine temperature sensor
Engine modification EM***
Engine speed RPMEngine speed
Erasable programmable read only memory EPROM ***
Evaporative emission canister EVAP canisterCanister
Evaporative emission system EVAP systemCanister control solenoid valve
Exhaust gas recirculation valve EGR valveEGR valve

Page 2143 of 3383

INFINITI QX56 2006 Factory Service Manual GI-52
TERMINOLOGY
Revision: November 20092006 QX56
Exhaust gas recirculation control-BPT
valveEGRC-BPT valve
BPT valve
Exhaust gas recirculation control-solenoid
valve EGRC-solenoid valve
EGR contro

GI-52
TERMINOLOGY
Revision: November 20092006 QX56
Exhaust gas recirculation control-BPT
valveEGRC-BPT valve
BPT valve
Exhaust gas recirculation control-solenoid
valve EGRC-solenoid valve
EGR control solenoid valve
Exhaust gas recirculation temperature sen-
sor EGRT sensor Exhaust gas temperature sensor
EGR temperature sensor
Flash electrically erasable programmable
read only memory FEEPROM
***
Flash erasable programmable read only
memory FEPROM
***
Flexible fuel sensor FFS ***
Flexible fuel system FF system ***
Fuel pressure regulator *** Pressure regulator
Fuel pressure regulator control solenoid
valve ***
PRVR control solenoid valve
Fuel trim FT ***
Heated Oxygen sensor HO2S Exhaust gas sensor
Idle air control system IAC system Idle speed control
Idle air control valve-air regulator IACV-air regulator Air regulator
Idle air control valve-auxiliary air control
valve IACV-AAC valve
Auxiliary air control (AAC) valve
Idle air control valve-FICD solenoid valve IACV-FICD solenoid valve FICD solenoid valve
Idle air control valve-idle up control sole-
noid valve IACV-idle up control solenoid valve Idle up control solenoid valve
Idle speed control-FI pot ISC-FI pot FI pot
Idle speed control system ISC system ***
Ignition control IC ***
Ignition control module ICM ***
Indirect fuel injection system IFI system ***
Intake air IA Air
Intake air temperature sensor IAT sensor Air temperature sensor
Knock *** Detonation
Knock sensor KS Detonation sensor
Malfunction indicator lamp MIL Check engine light
Manifold absolute pressure MAP ***
Manifold absolute pressure sensor MAPS ***
Manifold differential pressure MDP ***
Manifold differential pressure sensor MDPS ***
Manifold surface temperature MST ***
Manifold surface temperature sensor MSTS ***
Manifold vacuum zone MVZ ***
Manifold vacuum zone sensor MVZS ***
Mass air flow sensor MAFS Air flow meter
Mixture control solenoid valve MC solenoid valve Air-fuel ratio control solenoid valve
Multiport fuel injection System MFI system Fuel injection control
NEW TERM
NEW ACRONYM /
ABBREVIATION OLD TERM

Page 2144 of 3383

INFINITI QX56 2006 Factory Service Manual TERMINOLOGYGI-53
C
DE
F
G H
I
J
K L
M B
GI
Revision: November 2009 2006 QX56
Nonvolatile random access memory NVRAM***
On board diagnostic system OBD systemSelf-diagnosis
Open loop OLOpen loop
Oxidati

TERMINOLOGYGI-53
C
DE
F
G H
I
J
K L
M B
GI
Revision: November 2009 2006 QX56
Nonvolatile random access memory NVRAM***
On board diagnostic system OBD systemSelf-diagnosis
Open loop OLOpen loop
Oxidation catalyst OCCatalyst
Oxidation catalytic converter system OC system ***
Oxygen sensor O2SExhaust gas sensor
Park position switch ***Park switch
Park/neutral position switch PNP switchPark/neutral switch
Inhibitor switch
Neutral position switch
Periodic trap oxidizer system PTOX system***
Positive crankcase ventilation PCVPositive crankcase ventilation
Positive crankcase ventilation valve PCV valve PCV valve
Powertrain control module PCM***
Programmable read only memory PROM***
Pulsed secondary air injection control sole-
noid valve PAIRC solenoid valve
AIV control solenoid valve
Pulsed secondary air injection system PAIR system Air induction valve (AIV) control
Pulsed secondary air injection valve PAIR valve Air induction valve
Random access memory RAM***
Read only memory ROM***
Scan tool ST***
Secondary air injection pump AIR pump***
Secondary air injection system AIR system***
Sequential multiport fuel injection system SFI system Sequential fuel injection
Service reminder indicator SRI***
Simultaneous multiport fuel injection sys-
tem ***
Simultaneous fuel injection
Smoke puff limiter system SPL system***
Supercharger SC***
Supercharger bypass SCB***
System readiness test SRT***
Thermal vacuum valve TVVThermal vacuum valve
Three way catalyst TWCCatalyst
Three way catalytic converter system TWC system ***
Three way + oxidation catalyst TWC + OCCatalyst
Three way + oxidation catalytic converter
system TWC + OC system
***
Throttle body TBThrottle chamber
SPI body
Throttle body fuel injection system TBI system Fuel injection control
Throttle position TPThrottle position
Throttle position sensor TPSThrottle sensor
Throttle position switch TP switchThrottle switch
Torque converter clutch solenoid valve TCC solenoid valve Lock-up cancel solenoid
Lock-up solenoid
NEW TERM
NEW ACRONYM /
ABBREVIATION OLD TERM
