INFINITI QX56 2006 Factory Service Manual SC-24
CHARGING SYSTEM
Revision: November 20092006 QX56
DIAGNOSTIC PROCEDURE 3
Check Voltage Regulator Circuit
1. CHECK VOLTAGE REGULATOR CIRCUIT CONNECTION
1. Turn the ignition switch OFF.
2. Check to

Page 2930 of 3383

INFINITI QX56 2006 Factory Service Manual CHARGING SYSTEMSC-25
C
DE
F
G H
I
J
L
M A
B
SC
Revision: November 2009 2006 QX56
MALFUNCTION INDICATOR
The IC regulator warning function activates to illuminate “CHARGE” warning lamp, if any of th

Page 2931 of 3383

INFINITI QX56 2006 Factory Service Manual SC-26
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: November 20092006 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
BatteryEKS00B7M
StarterEKS00B7N
GeneratorEKS00B7O
Ty p eGr. 27
Capacity (20

Page 2932 of 3383

INFINITI QX56 2006 Factory Service Manual SE-1
SEAT
I BODY
CONTENTS
C
DE
F
G H
J
K L
M
SECTION
A
B
SE
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 3
Precautions for Supplemental R

SE-1
SEAT
I BODY
CONTENTS
C
DE
F
G H
J
K L
M
SECTION
A
B
SE
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 3
Precautions for Work ........................................... ..... 3
PREPARATION ...................................................... ..... 4
Special Service Tool ............................................ ..... 4
Commercial Service Tool .................................... ..... 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ................................................................ 5 CUSTOMER INTERVIEW ................................ ..... 5
DUPLICATE THE NOISE AND TEST DRIVE .. ..... 6
CHECK RELATED SERVICE BULLETINS ...... ..... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ................................................. ..... 6
REPAIR THE CAUSE ...................................... ..... 6
CONFIRM THE REPAIR .................................. ..... 7
Generic Squeak and Rattle Troubleshooting ...... ..... 7
INSTRUMENT PANEL ..................................... ..... 7
CENTER CONSOLE ........................................ ..... 7
DOORS ............................................................ ..... 7
TRUNK ............................................................. ..... 8
SUNROOF/HEADLINING ................................ ..... 8
OVERHEAD CONSOLE (FRONT AND REAR) ..... 8
SEATS .............................................................. ..... 8
UNDERHOOD .................................................. ..... 8
Diagnostic Worksheet ......................................... ..... 9
AUTOMATIC DRIVE POSITIONER ....................... ....11
Component Parts And Harness Connector Location .... 11
System Description ............................................. ... 12
FAIL-SAFE MODE ........................................... ... 12
CANCEL OF FAIL-SAFE MODE ...................... ... 13
CAN Communication System Description ........... ... 13
Schematic ........................................................... ... 14
Wiring Diagram — AUT/DP — ............................ ... 16
Terminals and Reference Values for BCM .......... ... 26
Terminals and Reference Values for Driver Seat
Control Unit ......................................................... ... 26
Terminals and Reference Values for Automatic Drive Positioner Control Unit ...............................
... 28
Work Flow ............................................................... 30
Preliminary Check ............................................... ... 31
SETTING CHANGE FUNCTION ...................... ... 31
POWER SUPPLY AND GROUND CIRCUIT
INSPECTION ................................................... ... 31
CONSULT-II Function (AUTO DRIVE POS.) ....... ... 34
CONSULT-II INSPECTION PROCEDURE ....... ... 34
SELF-DIAGNOSIS RESULTS .......................... ... 36
DATA MONITOR .............................................. ... 37
ACTIVE TEST ..................................................... 38
CAN Communication Inspection Using CONSULT-
II (Self-Diagnosis) ................................................ ... 38
Symptom Chart ....................................................... 38
Sliding Motor Circuit Inspection ........................... ... 40
Reclining Motor LH Circuit Inspection ................. ... 41
Lifting Motor (Front) Circuit Inspection ................ ... 42
Lifting Motor (Rear) Circuit Inspection ................. ... 44
Pedal Adjusting Motor Circuit Inspection ............. ... 45
Mirror Motor LH Circuit Check ................................ 46
Mirror Motor RH Circuit Check ............................ ... 48
Steering Wheel Tilt Circuit Inspection .................. ... 49
Sliding Sensor Circuit Inspection ......................... ... 51
Reclining Sensor Circuit Inspection ..................... ... 52
Lifting Sensor (Front) Circuit Inspection .............. ... 53
Lifting Sensor (Rear) Circuit Inspection ............... ... 54
Pedal Adjusting Sensor Circuit Inspection ........... ... 55
Mirror Sensor LH Circuit Check ........................... ... 56
Mirror Sensor RH Circuit Check ............................. 57
Steering Wheel Tilt Sensor Circuit Inspection ..... ... 59
Sliding Switch Circuit Inspection .......................... ... 61
Reclining Switch Inspection ................................. ... 62
Lifting Switch (Front) Circuit Inspection ............... ... 64
Lifting Switch (Rear) Circuit Inspection ................ ... 65
Power Seat Switch Ground Inspection ................ ... 66
Pedal Adjusting Switch Circuit Inspection ........... ... 67
Door Mirror Remote Control Switch (Changeover
Switch) Circuit Check ............................................. 69
Door Mirror Remote Control Switch (Mirror Switch)
Circuit Check ....................................................... ... 70

Page 2933 of 3383

INFINITI QX56 2006 Factory Service Manual SE-2Revision: November 20092006 QX56
Door Mirror Remote Control Switch Ground Circuit
Inspection ............................................................
... 72
Seat Memory Switch Circuit Inspect

SE-2Revision: November 20092006 QX56
Door Mirror Remote Control Switch Ground Circuit
Inspection ............................................................
... 72
Seat Memory Switch Circuit Inspection ............... ... 72
Seat Memory Indicator Lamp Circuit Inspection .. ... 74
Door Mirror Sensor Power Supply and Ground Cir-
cuit inspection ...................................................... ... 75
A/T Device (Park Position Switch) Circuit Inspection ... 76
Steering Wheel Tilt Switch Circuit Inspection ...... ... 77
Front Door Switch LH Circuit Inspection .............. ... 79
UART Communication Line Circuit Inspection ..... ... 80
Removal and Installation ..................................... ... 82
POWER SEAT ........................................................ ... 83
Wiring Diagram — SEAT — for Passenger Seat . ... 83
HEATED SEAT ....................................................... ... 84
Description ........................................................... ... 84
Schematic ............................................................ ... 85
Wiring Diagram — HSEAT — .............................. ... 86
FRONT SEAT ......................................................... ... 91
Removal and Installation ..................................... ... 91
REMOVAL ........................................................ ... 94INSTALLATION .................................................
... 94
Disassembly and Assembly ................................. ... 94
SEATBACK TRIM AND PAD ............................ ... 94
REMOVAL OF SEATBACK ASSEMBLY .......... ... 96
INSTALLATION OF SEATBACK ASSEMBLY .. ... 96
SEAT CUSHION TRIM AND PAD (DRIVER) OR
SEAT CUSHION ASSEMBLY (PASSENGER) .. ... 96
SECOND SEAT ...................................................... ... 98
Removal and Installation ...................................... ... 98
SECOND ROW OUTBOARD ........................... ... 98
SECOND ROW CENTER ................................. ... 98
Disassembly and Assembly ................................. ... 99
THIRD SEAT ........................................................... .105
LH Side Seat ........................................................ .105
REMOVAL ......................................................... .105
INSTALLATION ................................................. .105
DISASSEMBLY AND ASSEMBLY .................... .106
RH Side Seat ....................................................... .107
REMOVAL ......................................................... .107
INSTALLATION ................................................. .108
DISASSEMBLY AND ASSEMBLY .................... .109

Page 2934 of 3383

INFINITI QX56 2006 Factory Service Manual PRECAUTIONSSE-3
C
DE
F
G H
J
K L
M A
B
SE
Revision: November 2009 2006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EI

PRECAUTIONSSE-3
C
DE
F
G H
J
K L
M A
B
SE
Revision: November 2009 2006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EIS004X5
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for WorkEIS004X6
When removing or disassembling each component, be careful not to damage or deform it. If a component
may be subject to interference, be sure to protect it with a shop cloth.
When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the compo-
nent with a shop cloth or vinyl tape to protect it.
Protect the removed parts with a shop cloth and keep them.
Replace a deformed or damaged clip.
If a part is specified as a non-reusable part, always replace it with new one.
Be sure to tighten bolts and nuts securely to the specified torque.
After re-installation is completed, be sure to check that each part works normally.
Follow the steps below to clean components.
–Water soluble foul: Dip a soft cloth into lukewarm water, and wring the water out of the cloth to wipe the
fouled area.
Then rub with a soft and dry cloth.
–Oily foul: Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%), and wipe
the fouled area.
Then dip a cloth into fresh water, and wring the water out of the cloth to wipe the detergent off. Then rub
with a soft and dry cloth.
Do not use organic solvent such as thinner, benzene, alcohol, or gasoline.
For genuine leather seats, use a genuine leather seat cleaner.

Page 2935 of 3383

INFINITI QX56 2006 Factory Service Manual SE-4
PREPARATION
Revision: November 20092006 QX56
PREPARATIONPFP:00002
Special Service ToolEIS004X7
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated her

Page 2936 of 3383

INFINITI QX56 2006 Factory Service Manual SQUEAK AND RATTLE TROUBLE DIAGNOSESSE-5
C
DE
F
G H
J
K L
M A
B
SE
Revision: November 2009 2006 QX56
SQUEAK AND RATTLE TROUBLE DIAGNOSESPFP:00000
Work FlowEIS00508
CUSTOMER INTERVIEW
Interview the cust

SQUEAK AND RATTLE TROUBLE DIAGNOSESSE-5
C
DE
F
G H
J
K L
M A
B
SE
Revision: November 2009 2006 QX56
SQUEAK AND RATTLE TROUBLE DIAGNOSESPFP:00000
Work FlowEIS00508
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to SE-9, "
Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.
The customer may not be able to provide a detailed description or the location of the noise. Attempt to
obtain all the facts and conditions that exist when the noise occurs (or does not occur).
If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
is concerned about. This can be accomplished by test driving the vehicle with the customer.
After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
are provided so the customer, service adviser and technician are all speaking the same language when
defining the noise.
Squeak —(Like tennis shoes on a clean floor)
Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
faces = higher pitch noise/softer surfaces = lower pitch noises/edge to surface = chirping.
Creak —(Like walking on an old wooden floor)
Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
dependent on materials/often brought on by activity.
Rattle —(Like shaking a baby rattle)
Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
clip or fastener/incorrect clearance.
Knock —(Like a knock on a door)
Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
Tick —(Like a clock second hand)
Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
action or road conditions.
Thump —(Heavy, muffled knock noise)
Thump characteristics include softer knock/dead sound often brought on by activity.
Buzz —(Like a bumble bee)
Buzz characteristics include high frequency rattle/firm contact.
Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
judge as acceptable may be very irritating to the customer.
Weather conditions, especially humidity and temperature, may have a great effect on noise level.
SBT842

Load next 8 pages
