EC-462Revision: November 2009
DTC P0643 SENSOR POWER SUPPLY
2006 QX56
Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
TER-
MINAL NO. WIRE
COLOR ITEM
CONDITION DATA (DC Voltage)
48 SB Sensor power supply
(EVAP control system
pressure sensor)
[Ignition switch: ON]
Approximately 5V
49 R/Y Sensor power supply
(Refrigerant pressure
sensor) [Ignition switch: ON]
Approximately 5V
68 W/L Sensor power supply
(Power steering pressure
sensor) [Ignition switch: ON]
Approximately 5V
82 B/R Sensor ground
(APP sensor 1) [Engine is running]
Warm-up condition
Idle speed
Approximately 0V
83 G/W Sensor ground
(APP sensor 2) [Engine is running]
Warm-up condition
Idle speed
Approximately 0V
90 L Sensor power supply
(APP sensor 1)
[Ignition switch: ON]
Approximately 5V
91 W/R Sensor power supply
(APP sensor 2) [Ignition switch: ON]
Approximately 5V
98 G/R Accelerator pedal position
sensor 2 [Ignition switch: ON]
Engine: Stopped
Accelerator pedal: Fully released
0.25 - 0.50V
[Ignition switch: ON]
Engine: Stopped
Accelerator pedal: Fully depressed 2.0 - 2.5V
106 BR/W Accelerator pedal position
sensor 1 [Ignition switch: ON]
Engine: Stopped
Accelerator pedal: Fully released
0.5 - 1.0V
[Ignition switch: ON]
Engine: Stopped
Accelerator pedal: Fully depressed 4.2 - 4.8V
Page 1674 of 3383
DTC P0643 SENSOR POWER SUPPLYEC-463
C
DE
F
G H
I
J
K L
M A
EC
Revision: November 2009 2006 QX56
Diagnostic ProcedureUBS00H9E
1. CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Loosen and retighten three ground screws on the body. Refer to EC-150, "
Ground Inspection" .
OK or NG
OK >> GO TO 2.
NG >> Repair or replace ground connections.
2. CHECK APP SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check voltage between APP sensor terminal 7 and ground with CONSULT-II or tester.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
BBIA0354E
BBIA0361E
Voltage: Approximately 5V
PBIB2070E
Page 1675 of 3383

EC-464Revision: November 2009
DTC P0643 SENSOR POWER SUPPLY
2006 QX56
3. CHECK SENSOR POWER SUPPLY CIRCUITS
Check harness for short to power and short to ground, between the following terminals
OK or NG
OK >> GO TO 4.
NG >> Repair short to ground or short to power in harness or connectors.
4. CHECK COMPONENTS
Check the following.
EVAP control system pressure sensor (Refer to EC-410, "Component Inspection" .)
Power steering pressure sensor (Refer to EC-452, "Component Inspection" .)
Refrigerant pressure sensor (Refer to EC-630, "REFRIGERANT PRESSURE SENSOR" .)
OK or NG
OK >> GO TO 7.
NG >> Replace malfunctioning components.
5. CHECK ACCELERATOR PEEDAL POSITION SENSOR
Refer to EC-574, "
Component Inspection" .
OK or NG
OK >> GO TO 7.
NG >> GO TO 6.
6. REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal position assembly.
2. Perform EC-78, "
Accelerator Pedal Released Position Learning" .
3. Perform EC-78, "
Throttle Valve Closed Position Learning" .
4. Perform EC-78, "
Idle Air Volume Learning" .
>> INSPECTION END
7. CHECK INTERMITTENT INCIDENT
Refer to EC-144, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
>> INSPECTION END
ECM terminal Sensor terminal Reference Wiring Diagram
48 EVAP control system pressure sensor terminal 3 EC-407
49Refrigerant pressure sensor terminal 1 EC-631
68Power steering pressure sensor terminal 1 EC-449
90APP sensor terminal 7 EC-461
Page 1676 of 3383

DTC P0850 PNP SWITCHEC-465
C
DE
F
G H
I
J
K L
M A
EC
Revision: November 2009 2006 QX56
DTC P0850 PNP SWITCHPFP:23006
Component DescriptionUBS00HBQ
When the gear position is P or N, park/neutral position (PNP) switch is ON.
TCM detects the position because the continuity of the line (the ON signal) exists.
Then the TCM sends the PNP switch signal to the ECM via combination meter.
CONSULT-II Reference Value in Data Monitor ModeUBS00HBR
Specification data are reference values.
On Board Diagnosis LogicUBS00HBS
DTC Confirmation ProcedureUBS00HBT
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
WITH CONSULT-II
1. Turn ignition switch ON.
2. Select “P/N POSI SW ” in “DATA MONITOR ” mode with CON-
SULT-II. Then check the “P/N POSI SW ” signal under the follow-
ing conditions.
If NG, go to EC-468, "
Diagnostic Procedure" .
If OK, go to following step.
3. Select “DATA MONITOR ” mode with CONSULT-II.
4. Start engine and warm it up to normal operating temperature.
5. Maintain the following conditions for at least 60 consecutive sec- onds.
6. If 1st trip DTC is detected, go to EC-468, "
Diagnostic Procedure" .
MONITOR ITEM CONDITION SPECIFICATION
P/N POSI SW
Ignition switch: ON Selector lever: P or N
ON
Selector lever: Except above OFF
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0850
0850 Park/neutral position
switch The signal of the park/neutral position (PNP)
switch is not changed in the process of engine
starting and driving.
Harness or connectors
[The park/neutral position (PNP) switch
circuit is open or shorted.]
Park/neutral position (PNP) switch
Combination meter
TCM
Position (Selector lever)
Known-good signal
N or P position ON
Except the above position OFF
SEF212Y
ENG SPEEDMore than 1,000 rpm
COOLAN TEMP/S More than 70°C (158 °F)
B/FUEL SCHDL More than 2.0 msec
VHCL SPEED SE More than 64 km/h (40 MPH)
Selector lever Suitable position
SEF213Y
Page 1677 of 3383
EC-466Revision: November 2009
DTC P0850 PNP SWITCH
2006 QX56
Overall Function CheckUBS00HBU
Use this procedure to check the overall function of the park/neutral position (PNP) switch circuit. During this
check, a 1st trip DTC might not be confirmed.
WITH GST
1. Turn ignition switch ON.
2. Check voltage between ECM terminal 102 (PNP switch signal)and ground under the following conditions.
3. If NG, go to EC-468, "
Diagnostic Procedure" .
Condition (Gear position) Voltage V (Known-good data)
P or N position Approx. 0
Except the above position BATTERY VOLTAGE
(11 - 14V)
MBIB0043E
Page 1678 of 3383
DTC P0850 PNP SWITCHEC-467
C
DE
F
G H
I
J
K L
M A
EC
Revision: November 2009 2006 QX56
Wiring DiagramUBS00HBV
