Page 1145 of 3383

DI-24
COMBINATION METERS
Revision: November 20092006 QX56
Fuel Gauge Fluctuates, Indicates Wrong Value, or VariesEKS00BCA
1. CHECK FUEL GAUGE FLUCTUATION
Test drive vehicle to see if gauge fluctuates only during driving or just before or just after stopping.
Does the indication value vary only during driving or just before or just after stopping?
YES >> The fluctuation may be caused by fuel level change in the fuel tank. Condition is normal.
NO >> Ask the customer about the situation when the symptom occurs in detail, Refer to DI-22, "
Fuel
Level Sensor Unit Inspection" .
Fuel Gauge Does Not Move to Full-positionEKS00BCB
1. CHECK POINTER MOVEMENT TO FULL-POSITION
Does it take a long time for the pointer to move to full-position?
YES or NO
YES >> GO TO 2.
NO >> GO TO 3.
2. CHECK IGNITION SWITCH POSITION
Was the vehicle fueled with the ignition switch ON?
YES or NO
YES >> Be sure to fuel the vehicle with the ignition switch OFF. Otherwise, it will take a long time for the pointer to move to full-position because of the characteristic of the fuel gauge.
NO >> GO TO 3.
3. OBSERVE VEHICLE POSITION
Is the vehicle parked on an incline?
YES or NO
YES >> Check the fuel level indication with vehicle on a level surface.
NO >> GO TO 4.
4. CHECK POINTER MOVEMENT TO EMPTY-POSITION
During driving, does the fuel gauge move gradually toward empty-position?
YES or NO
YES >> Check the fuel level sensor unit. Refer to DI-25, "FUEL LEVEL SENSOR UNIT CHECK" .
NO >> Check fuel level sensor unit installation, and determine whether the float arm interferes or binds with any of the internal components in the fuel tank.
Page 1146 of 3383
COMBINATION METERSDI-25
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
Electrical Components InspectionEKS00BCC
FUEL LEVEL SENSOR UNIT CHECK
For removal, refer to FL-6, "Removal and Installation" .
Check Fuel Level Sensor Unit and Fuel Pump
Check resistance between fuel level sensor unit and fuel pump con-
nector terminals 2 and 5.
*1 and *2: When float rod is in contact with stopper.
Removal and Installation of Combination MeterEKS00BCD
Refer to IP-13, "COMBINATION METER" for removal and installation procedures.
Terminals Float position mm (in) Resistance
value Ω
(Approx.)
25 *1 Empty 25.86 (1.02) 81.66
*2 Full 254.6 (10.02) 6.98
LKIA0402E
Page 1147 of 3383
DI-26
COMPASS AND THERMOMETER
Revision: November 20092006 QX56
COMPASS AND THERMOMETERPFP:24835
System DescriptionEKS00GBU
This unit displays the following items:
Earth magnetism and heading direction of vehicle.
Outside air temperature.
Caution for frozen road surfaces.
OUTSIDE TEMPERATURE DISPLAY
Push the mode (N) switch when the ignition switch is in the ON position. The outside temperature will be dis-
played in “°F”. To change the indication from “° F” to “° C”, push and hold the mode (N) switch for about 3 sec-
onds until the display begins to flash. Press the mode (N) switch again to toggle between “°F” and “° C”.
DIRECTION DISPLAY
Push the mode (N) switch when the ignition switch is in the ON position. The direction will be displayed.
LKIA0447E
Page 1148 of 3383
COMPASS AND THERMOMETERDI-27
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
Wiring Diagram — COMPAS —EKS00GBV
WKWA3618E
Page 1149 of 3383

DI-28
COMPASS AND THERMOMETER
Revision: November 20092006 QX56
Trouble DiagnosesEKS00GBW
PRELIMINARY CHECK FOR THERMOMETER
1. COOL DOWN CHECK
1. Turn the ignition switch to the ON position.
2. Cool down ambient sensor 2 with water or ice.
Does the indicated temperature drop?
YES >> GO TO 2.
NO >> The system is malfunctioning. Check the system following “INSPECTION/COMPASS AND THER-
MOMETER ”. Refer to DI-28, "
INSPECTION/COMPASS AND THERMOMETER" .
2. WARM UP CHECK
1. Leave the vehicle for 10 minutes.
2. With the ignition switch in the ON position, disconnect and reconnect ambient sensor 2 connector.
Does the indicated temperature rise?
YES >> The system is OK.
NO >> The system is malfunctioning. Check the system following “INSPECTION/COMPASS AND THER-
MOMETER ”. Refer to DI-28, "
INSPECTION/COMPASS AND THERMOMETER" .
INSPECTION/COMPASS AND THERMOMETER
Symptom Possible causes Repair order
No display at all 1. 10A fuse. 2. Ground circuit.
3. auto anti-dazzling inside mirror. 1. Check 10A fuse [No. 12, located in fuse block (J/B)].
Turn the ignition switch ON and verify that battery positive volt-
age is at terminal 6 of auto anti-dazzling inside mirror.
2. Check ground circuit for auto anti-dazzling inside mirror.
3. Replace auto anti-dazzling inside mirror.
Forward direction indi-
cation slips off the mark
or incorrect. 1. In manual correction mode (Bar and
display vanish).
2. Zone variation change is not done. 1. Drive the vehicle and turn at an angle of 90
°.
2. Perform the zone variation change.
Displays wrong tem-
perature when ambient
temperature is between
− 40 °C ( −40° F) and
55 °C (130 °F) 1. Check operation.
2. Ambient sensor 2 circuit.
3. Ambient sensor 2.
4. Auto anti-dazzling inside mirror.
1. Perform preliminary check shown above.
2. Check harness for open or short between ambient sensor 2 and
auto anti-dazzling inside mirror.
3. Replace ambient sensor 2.
4. Replace auto anti-dazzling inside mirror.
Displays SC or OC 1. Ambient sensor 2 circuit. 2. Ambient sensor 2.
3. Auto anti-dazzling inside mirror. 1. Check harness for open or short between ambient sensor 2 and
auto anti-dazzling inside mirror.
2. Replace ambient sensor 2.
3. Replace auto anti-dazzling inside mirror.
Page 1150 of 3383

COMPASS AND THERMOMETERDI-29
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
Calibration Procedure for CompassEKS00GBX
The difference between magnetic North and geographical North can sometimes be great enough to cause
false compass readings. In order for the compass to operate accurately in a particular zone, it must be cali-
brated using the following procedure.
Zone Variation Chart
1. Determine your location on the zone map.
2. Turn the ignition switch to the ON position.
3. Press and hold the mode (N) switch for about 8 seconds. The current zone number will appear in the dis-
play.
4. Press the mode (N) switch repeatedly until the desired number appears in the display.
Once the desired zone number is displayed, stop pressing the mode (N) switch and the display will show a
compass direction after a few seconds.
NOTE:
Use zone number 5 for Hawaii.
CORRECTION FUNCTIONS OF COMPASS
The direction display is equipped with automatic correction function.
If the direction is not shown correctly, carry out initial correction.
WKIA4148E
LKIA0447E
Page 1151 of 3383
DI-30
COMPASS AND THERMOMETER
Revision: November 20092006 QX56
INITIAL CORRECTION PROCEDURE FOR COMPASS
1. Pushing the mode (N) switch for about 10 seconds will enter the initial correction mode. The “CAL ” icon
will illuminate.
2. Turn the vehicle slowly in an open, safe place. The initial correction is completed in approximately one and a half turns.
NOTE:
In places where the terrestrial magnetism is extremely disturbed, the initial correction may start automatically.
Page 1152 of 3383
WARNING LAMPSDI-31
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
WARNING LAMPSPFP:24814
SchematicEKS00BCI
WKWA3619E
