Page 2273 of 3383

INFINITI QX56 2006 Factory Service Manual LAN-4 [CAN] PRECAUTIONS Revision: November 20092006 QX56 Precautions For Harness RepairUKS0017L CAN SYSTEM Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm

Page 2274 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSES WORK FLOWLAN-5 [CAN] C DE F G H I J L M A B LAN Revision: November 2009 2006 QX56 TROUBLE DIAGNOSES WORK FLOWPFP:00004 When Displaying CAN Communication System ErrorsUKS004SS WHEN A

Page 2275 of 3383

INFINITI QX56 2006 Factory Service Manual LAN-6 [CAN] TROUBLE DIAGNOSES WORK FLOW Revision: November 20092006 QX56 TROUBLE DIAGNOSIS FLOW CHART Depending on the control unit which performs CAN communication, “U1010” may be indicated as th

Page 2276 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSES WORK FLOWLAN-7 [CAN] C DE F G H I J L M A B LAN Revision: November 2009 2006 QX56 Diagnosis ProcedureUKS004ST SELECTING CAN SYSTEM TYPE (HOW TO USE SPECIFICATION TABLE) Determine CAN

Page 2277 of 3383

INFINITI QX56 2006 Factory Service Manual LAN-8 [CAN] TROUBLE DIAGNOSES WORK FLOW Revision: November 20092006 QX56 ACQUISITION OF DATA BY CONSULT-II Attach the data acquired by CONSULT-II on the check sheet determined according to CAN system

Page 2278 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSES WORK FLOWLAN-9 [CAN] C DE F G H I J L M A B LAN Revision: November 2009 2006 QX56 HOW TO USE CHECK SHEET TABLE 1. Unit names displayed on CONSULT-II 2.“No indication ”: Put a che

Page 2279 of 3383

INFINITI QX56 2006 Factory Service Manual LAN-10 [CAN] TROUBLE DIAGNOSES WORK FLOW Revision: November 20092006 QX56 Example of Filling in Check Sheet When Initial Conditions Are Reproduced 1. Put a check mark to “No indication” if some of

Page 2280 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSES WORK FLOWLAN-11 [CAN] C DE F G H I J L M A B LAN Revision: November 2009 2006 QX56 4. Display control unit reads the CAN diagnosis support monitor check sheet (B) AV- 1 4 0 , "CAN
