INFINITI QX56 2006 Factory Service Manual GW-64
POWER WINDOW SYSTEM
Revision: November 20092006 QX56
3. CHECK REAR POWER VENT WINDOW RELAY (CLOSE) GROUND CIRCUIT
Check continuity between rear power vent window relay (CLOSE)
connector M89 term

Page 2210 of 3383

INFINITI QX56 2006 Factory Service Manual FRONT DOOR GLASS AND REGULATORGW-65
C
DE
F
G H
J
K L
M A
B
GW
Revision: November 2009 2006 QX56
FRONT DOOR GLASS AND REGULATORPFP:80300
Removal and InstallationEIS00621
FRONT DOOR GLASS
Removal
1. Rem

Page 2211 of 3383

INFINITI QX56 2006 Factory Service Manual GW-66
FRONT DOOR GLASS AND REGULATOR
Revision: November 20092006 QX56
Fitting Inspection
Check that the glass is securely fit into the glass run groove.
Lower the glass slightly [approximately 10 to

GW-66
FRONT DOOR GLASS AND REGULATOR
Revision: November 20092006 QX56
Fitting Inspection
Check that the glass is securely fit into the glass run groove.
Lower the glass slightly [approximately 10 to 20 mm (0.39 to 0.79 in)] and check that the clearance to the
sash is parallel. If the clearance between the glass and sash is not parallel, loosen the regulator bolts,
guide rail bolts, and glass and guide rail bolts to correct the glass position.
FRONT DOOR GLASS REGULATOR
Removal
1. Remove the front door finisher. Refer to EI-32, "DOOR FINISHER" .
2. Remove the hole cover over rear glass bolt.
3. Temporarily reconnect the power window switch.
4. Operate the power window main switch to raise/lower the door window until the glass bolts can be seen.
5. Remove the inside seal.
6. Remove the glass bolts.
7. Raise the front door glass and hold it in place with suitable tool.
8. Disconnect the harness connector from the regulator assembly.
9. Remove the bolts and the regulator assembly.
Disassembly And Assembly
Remove the regulator motor from the regulator assembly.
Inspection After Removal
Check the regulator assembly for the following items. If a malfunc-
tion is detected, replace or grease it.
Wire wear
Regulator deformation
Grease condition for each sliding part
The arrows in the figure show the application points of the body
grease.
Installation
1. Install the regulator assembly. Refer to GW-66, "FRONT DOOR GLASS REGULATOR" .
2. Connect the harness connector to the regulator assembly.
3. Align the glass and install the glass bolts.
4. Reset the limit switch. Refer to GW-66, "
Setting of Limit Switch" .
5. Install front door finisher. Refer to EI-32, "
DOOR FINISHER" .
SETTING AFTER INSTALLATION
Setting of Limit Switch
If any of the following work has been done, set the limit switch (integrated in the motor).
Removal and installation of the regulator.
Removal and installation of the motor from the regulator.
Removal and installation of the glass.
Removal and installation of the glass run.
Resetting
After installing each component, perform the following procedure to reset the limit switch.
LIIA0670E
Glass bolts: 6.1 N·m (0.62 kg-m, 54 in-lb)

Page 2212 of 3383

INFINITI QX56 2006 Factory Service Manual FRONT DOOR GLASS AND REGULATORGW-67
C
DE
F
G H
J
K L
M A
B
GW
Revision: November 2009 2006 QX56
1. Raise the glass to the top position.
2. While pressing and holding the reset switch, lower the glass

Page 2213 of 3383

INFINITI QX56 2006 Factory Service Manual GW-68
REAR DOOR GLASS AND REGULATOR
Revision: November 20092006 QX56
REAR DOOR GLASS AND REGULATORPFP:82300
Removal and InstallationEIS0062O
REAR DOOR GLASS
Removal
1. Remove the rear door finisher. R

Page 2214 of 3383

INFINITI QX56 2006 Factory Service Manual REAR DOOR GLASS AND REGULATORGW-69
C
DE
F
G H
J
K L
M A
B
GW
Revision: November 2009 2006 QX56
REAR DOOR GLASS REGULATOR
Removal
1. Remove the rear door finisher. Refer to EI-33, "REMOVAL" .
2. Tempor

Page 2215 of 3383

INFINITI QX56 2006 Factory Service Manual GW-70
REAR DOOR GLASS AND REGULATOR
Revision: November 20092006 QX56
2. Install the glass from outside to ensure that it is in both the front
and rear glass channels. Tighten glass bolts to the specif

Page 2216 of 3383

INFINITI QX56 2006 Factory Service Manual SIDE WINDOW GLASSGW-71
C
DE
F
G H
J
K L
M A
B
GW
Revision: November 2009 2006 QX56
SIDE WINDOW GLASSPFP:83300
Removal and InstallationEIS004US
REMOVAL
1. Remove the rear lower and upper finisher. Refe
