Differential Assembly
1. Install side gear thrust washers with the same thickness as the
ones installed prior to disassembly, or reinstall the old ones on
the side gears.
2. Install the side gears and side gear thrust washers into the dif- ferential case.
CAUTION:
Make sure that the circular clip is installed to side gears.
3. Install the pinion mate thrust washers to the two pinion mate gears. Then install the pinion mate gears with the pinion mate
thrust washers by aligning them in diagonally opposite positions
and rotating them into the differential case.
4. Align the lock pin hole on the differential case with the lock pin hole on the pinion mate shaft, and install the pinion mate shaft.
5. Measure the side gear end play. If necessary, select the appro- priate side gear thrust washers. Refer to RFD-32, "
SIDE GEAR
CLEARANCE" .
6. Drive a new lock pin into the pinion mate shaft until it is flush with the differential case using suitable tool.
CAUTION:
Do not reuse lock pin.
SDIA0193J
SDIA2025E
SDIA0195J
WDIA0131E
Page 2834 of 3383

REAR FINAL DRIVE ASSEMBLYRFD-29
CE F
G H
I
J
K L
M A
B
RFD
Revision: November 2009 2006 QX56
7. Align the matching mark of the differential case with the mark of
the drive gear, then place the drive gear onto the differential
case.
8. Apply thread locking sealant into the threaded holes of the drive gear and install the bolts.
Use Genuine Medium Strength Thread Locking Sealant or
equivalent. Refer to GI-46, "
Recommended Chemical Prod-
ucts and Sealants" .
CAUTION:
Make sure the drive gear back and threaded holes are
clean.
9. Tighten the drive gear bolts to the specified torque. Refer to RFD-15, "
COMPONENTS" . After tightening the drive gear bolts
to the specified torque, tighten an additional 34 ° using Tool.
CAUTION:
Always use Tool. Avoid tightening based on visual check
alone.
Tighten drive gear bolts in a crisscross pattern.
10. Press the side bearing inner races into the differential case using Tools.
CAUTION:
Do not reuse side bearing inner race.
11. Install the differential case assembly with the side bearing outer races into the gear carrier.
12. Measure the side bearing preload torque. If necessary, select the appropriate side bearing adjusting washers. Refer to RFD-
24, "Side Bearing Preload Torque" .
SDIA2593E
SDIA2594E
Tool number : KV10112100-A (BT-8653-A)
SDIA0247J
Tool number A: KV38100200 (J-26233)
B: ST33081000 ( — )
SPD353
SPD919
Page 2835 of 3383

RFD-30
REAR FINAL DRIVE ASSEMBLY
Revision: November 20092006 QX56
13. Insert the selected left and right side bearing adjusting washers
in place between the side bearings and gear carrier.
14. Install the side bearing caps with the matching marks aligned and tighten the side bearing cap bolts to the specified torque.
Refer to RFD-15, "
COMPONENTS" .
15. Check and adjust the drive gear runout, tooth contact, drive gear to drive pinion backlash, and total pre- load torque. Refer to RFD-17, "
Drive Gear Runout" , RFD-17, "Tooth Contact" , RFD-18, "Backlash" and
RFD-16, "
Total Preload Torque" .
Recheck the above items.
16. Install the side flanges. Refer to RFD-30, "
Side Flange" .
17. Apply a 3.2mm (0.126 in) bead of sealant to the mating surface of the carrier cover.
Use Genuine Silicone RTV or equivalent. Refer to GI-46,
"Recommended Chemical Products and Sealants" .
CAUTION:
Remove any old sealant adhering to the mating surfaces.
Also remove any moisture, oil, or foreign material adhering
to the application and mating surfaces.
18. Install the carrier cover to the gear carrier. Tighten the bolts to the specified torque. Refer to RFD-15, "
COMPONENTS" .
19. Install the side flange. Refer to RFD-30, "
Side Flange" .
Side Flange
1. Apply multi-purpose grease to the lips of the new side oil seal. Then drive the new side oil seal in evenly until it becomes flush
with the gear carrier using Tool.
CAUTION:
Do not reuse side oil seal.
Do not incline the new side oil seal when installing.
Apply multi-purpose grease to the lips of the new side oil
seal.
SPD924
SPD889
WDIA0282E
Tool number : ST35271000 ( — )
SPD560
Page 2836 of 3383
REAR FINAL DRIVE ASSEMBLYRFD-31
CE F
G H
I
J
K L
M A
B
RFD
Revision: November 2009 2006 QX56
2. Install the side flange using Tool.
a. Install the Tool to the side oil seal as shown.
b. Insert the side flange until the serrated part of the side flange
has engaged the serrated part of the side gear and remove the
To o l .
c. Drive in the side flange using suitable tool. NOTE:
Installation is completed when the driving sound of the side
flange turns into a sound which seems to affect the whole rear
final drive assembly.Tool number : KV38107900 (J-39352)
SDIA0822E
Page 2837 of 3383

RFD-32
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: November 20092006 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsEDS0044V
Inspection and AdjustmentEDS0044W
DRIVE GEAR RUNOUT
Unit: mm (in)
SIDE GEAR CLEARANCE
Unit: mm (in)
PRELOAD TORQUE
Unit: N·m (kg-m, in-lb)
BACKLASH
Unit: mm (in)
COMPANION FLANGE RUNOUT
Unit: mm (in)
SELECTIVE PARTS
Side Gear Thrust Washer
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information. Applied model
VK56DE
2WD 4WD
Final drive model R230
Gear ratio 2.9373.357
Number of teeth (Drive gear/Drive pinion) 47 / 1647 / 14
Oil capacity (Approx.) 1.75 (3 3/4 US pt, 3 1/8 Imp pt)
Number of pinion gears 2
Drive pinion adjustment spacer type Collapsible
ItemRunout limit
Drive gear back face 0.05 (0.0020) or less
ItemSpecification
Side gear back clearance
(Clearance limit between side gear and differential case for adjusting
side gear backlash) 0.20 (0.0079) or less
(Each gear should rotate smoothly without excessive resis- tance during differential motion.)
Item Specification
Drive pinion bearing preload torque 1.77 − 2.64 N·m (0.18 − 0.26 kg−m, 16 − 23 in-lb)
Side bearing preload torque (reference value determined by drive
gear bolt pulling force) 0.20
− 0.52 N·m (0.02 − 0.05 kg −m, 2 − 4 in-lb)
Drive gear bolt pulling force (by spring gauge) 34.2 − 39.2 N (3.5 − 4 kg, 7.7 − 8.8 lb)
Total preload torque
(Total preload torque = drive pinion bearing preload torque + Side
bearing preload torque) 2.05
− 4.11 N·m (0.21 − 0.42 kg −m, 19 − 36 in-lb)
Item Specification
Drive gear to drive pinion gear 0.13 − 0.18 (0.0051 − 0.0070)
Item Runout limit
Outer side of the companion flange 0.08 (0.0031) or less
ThicknessPart number*
1.75 (0.0688)
1.80 (0.0708)
1.85 (0.0728) 38424 7S000
38424 7S001
38424 7S002
Page 2838 of 3383

SERVICE DATA AND SPECIFICATIONS (SDS)RFD-33
CE F
G H
I
J
K L
M A
B
RFD
Revision: November 2009 2006 QX56
Drive Pinion Height Adjusting Washer
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Side Bearing Adjusting Washer
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information. Thickness
Part number* ThicknessPart number*
2.59 (0.1020)
2.61 (0.1028)
2.63 (0.1035)
2.65 (0.1043)
2.67 (0.1051)
2.69 (0.1059)
2.71 (0.1067)
2.73 (0.1075)
2.75 (0.1083)
2.77 (0.1091) 38154 40P00
38154 40P01
38154 40P02
38154 40P03
38154 40P04
38154 40P05
38154 40P06
38154 40P07
38154 40P08
38154 40P092.79 (0.1098)
2.81 (0.1106)
2.83 (0.1114)
2.85 (0.1122)
2.87 (0.1130)
2.89 (0.1138)
2.91 (0.1146)
2.93 (0.1154)
2.95 (0.1161)
2.97 (0.1169) 38154 40P10
38154 40P11
38154 40P12
38154 40P13
38154 40P14
38154 40P15
38154 40P16
38154 40P17
38154 40P18
38154 40P19
Thickness Part number* ThicknessPart number*
2.00 (0.0787)
2.05 (0.0807)
2.10 (0.0827)
2.15 (0.0846)
2.20 (0.0866)
2.25 (0.0886)
2.30 (0.0906) 38453 40P00
38453 40P01
38453 40P02
38453 40P03
38453 40P04
38453 40P05
38453 40P06
2.35 (0.0925)
2.40 (0.0945)
2.45 (0.0965)
2.50 (0.0984)
2.55 (0.1004)
2.60 (0.1024)
38453 40P07
38453 40P08
38453 40P09
38453 40P10
38453 40P11
38453 40P12
Page 2839 of 3383
RFD-34
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: November 20092006 QX56
Page 2840 of 3383
