Page 3289 of 3383

INFINITI QX56 2006 Factory Service Manual TF-184
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: November 20092006 QX56
Main Oil Pump
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Control Valve
Unit

Page 3290 of 3383

INFINITI QX56 2006 Factory Service Manual WT-1
ROAD WHEELS & TIRES
E SUSPENSION
CONTENTS
C
DF
G H
I
J
K L
M
SECTION
A
B
WT
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 2
Precautio

WT-1
ROAD WHEELS & TIRES
E SUSPENSION
CONTENTS
C
DF
G H
I
J
K L
M
SECTION
A
B
WT
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 2
PREPARATION ...................................................... ..... 3
Special Service Tool ............................................ ..... 3
Commercial Service Tools ................................... ..... 3
NOISE, VIBRATION, AND HARSHNESS (NVH)
TROUBLESHOOTING ........................................... ..... 4
NVH Troubleshooting Chart ................................ ..... 4
WHEEL .................................................................. ..... 5
Inspection ............................................................ ..... 5
WHEEL AND TIRE ASSEMBLY ............................ ..... 6
Balancing Wheels ............................................... ..... 6
REMOVAL ........................................................ ..... 6
WHEEL BALANCE ADJUSTMENT ................. ..... 6
Rotation ............................................................... ..... 7
LOW TIRE PRESSURE WARNING SYSTEM ....... ..... 8
System Components ........................................... ..... 8
System Description ............................................. ..... 8
TRANSMITTER ................................................ ..... 8
REMOTE KEYLESS ENTRY RECEIVER ........ ..... 8
BCM (BODY CONTROL MODULE) ................. ..... 9
WARNING LAMP AND BUZZER ..................... ..... 9
COMBINATION METER .................................. ..... 9
DISPLAY UNIT ................................................. ..... 9
CAN COMMUNICATION ....................................... ... 10
System Description ............................................. ... 10
TROUBLE DIAGNOSES ....................................... ....11
Wiring Diagram – T/WARN – .............................. .... 11
Terminals and Reference Values for BCM .......... ... 13
ID Registration Procedure ................................... ... 14
ID REGISTRATION WITH TRANSMITTER
ACTIVATION TOOL ......................................... ... 14
ID REGISTRATION WITHOUT TRANSMITTER
ACTIVATION TOOL ......................................... ... 16
Transmitter Wake Up Operation .......................... ... 18
WITH TRANSMITTER ACTIVATION TOOL ..... ... 18
CONSULT-II Function (BCM) .............................. ... 19
Self-Diagnosis ..................................................... ... 20DESCRIPTION .................................................
... 20
FUNCTION ....................................................... ... 20
CONSULT-II ...................................................... ... 20
How to Perform Trouble Diagnosis for Quick and
Accurate Repair ................................................... ... 22
INTRODUCTION .............................................. ... 22
WORK FLOW ................................................... ... 22
Preliminary Check ............................................... ... 23
Malfunction Code/Symptom Chart ....................... ... 24
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ..................................................................... ... 26
Inspection 1: Transmitter or Control Unit (BCM) .. ... 26
MALFUNCTION CODE NO. 21, 22, 23 OR 24
(DTC C1708, C1709, C1710 OR C1711) ......... ... 26
Inspection 2: Transmitter - 1 ................................ ... 26
MALFUNCTION CODE NO. 31, 32, 33, 34, 41,
42, 43, 44, 45, 46, 47 OR 48 ............................ ... 26
Inspection 3: Transmitter - 2 ................................ ... 27
MALFUNCTION CODE NO. 35, 36, 37 OR 38 ... 27
Inspection 4: Vehicle Speed Signal ..................... ... 28
MALFUNCTION CODE NO. 52 (DTC C1729) . ... 28
TROUBLE DIAGNOSIS FOR SYMPTOMS ........... ... 29
Inspection 1: Warning Lamp Does Not Come On
When Ignition Switch Is Turned On ..................... ... 29
Inspection 2: Low Tire Pressure Warning Lamp
Stays On When Ignition Switch Is Turned On ...... ... 30
Inspection 3: Warning Lamp Flashes When Ignition
Switch Is Turned On ............................................ ... 32
Inspection 4: Hazard Warning Lamp Flashes When
Ignition Switch Is Turned On ............................... ... 33
Inspection 5: “TIRE PRESSURE” Information In
Display Unit Does Not Exist ................................. ... 34
Inspection 6: ID Registration Cannot Be Completed ... 35
REMOVAL AND INSTALLATION .......................... ... 36
Transmitter (Pressure Sensor) ............................ ... 36
REMOVAL ........................................................ ... 36
INSTALLATION ................................................ ... 36
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 38
Road Wheel ............................................................ 38
Tire ...................................................................... ... 38

Page 3291 of 3383

INFINITI QX56 2006 Factory Service Manual WT-2
PRECAUTIONS
Revision: November 20092006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EES0025O
The Supplemental Re

Page 3292 of 3383

INFINITI QX56 2006 Factory Service Manual PREPARATIONWT-3
C
DF
G H
I
J
K L
M A
B
WT
Revision: November 2009 2006 QX56
PREPARATIONPFP:00002
Special Service ToolEES001HW
The actual shapes of Kent-Moore tools may differ from those of special ser

Page 3293 of 3383

INFINITI QX56 2006 Factory Service Manual WT-4
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: November 20092006 QX56
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartEES001HY
Use the cha

Page 3294 of 3383

INFINITI QX56 2006 Factory Service Manual WHEELWT-5
C
DF
G H
I
J
K L
M A
B
WT
Revision: November 2009 2006 QX56
WHEELPFP:40300
InspectionEES001HZ
1. Check tires for wear and improper inflation.
2. Check wheels for deformation, cracks and othe

Page 3295 of 3383

INFINITI QX56 2006 Factory Service Manual WT-6
WHEEL AND TIRE ASSEMBLY
Revision: November 20092006 QX56
WHEEL AND TIRE ASSEMBLYPFP:40300
Balancing WheelsEES001I0
REMOVAL
1. Using releasing agent, remove double-faced adhesive tape from the whe

WT-6
WHEEL AND TIRE ASSEMBLY
Revision: November 20092006 QX56
WHEEL AND TIRE ASSEMBLYPFP:40300
Balancing WheelsEES001I0
REMOVAL
1. Using releasing agent, remove double-faced adhesive tape from the wheel.
CAUTION:
Be careful not to scratch the wheel during removal.
After removing double-faced adhesive tape, wipe clean traces of releasing agent from the
wheel.
WHEEL BALANCE ADJUSTMENT
If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting,
select and adjust a drive-in weight mode suitable for wheels.
1. Set wheel on wheel balancer using the center hole as a guide. Start the tire balance machine.
2. When inner and outer imbalance values are shown on the wheel balancer indicator, multiply outer imbal- ance value by 1.6 to determine balance weight that should be used. Select the outer balance weight with
a value closest to the calculated value and install it to the designated outer position of, or at the desig-
nated angle in relation to the road wheel.
CAUTION:
Do not install the inner balance weight before installing the outer balance weight.
Before installing the balance weight, be sure to clean the mating surface of the wheel.
Indicated imbalance value × 5/3 = balance weight to be installed
Calculation example:
23 g (0.81 oz) × 5/3 = 38.33 g (1.35 oz) = 40 g (1.41 oz) balance
weight (closer to calculated balance weight value)
Note that balance weight value must be closer to the calculated
balance weight value.
Example:
37.4 g = 35 g (1.23 oz)
37.5 g = 40 g (1.41 oz)
a. Install balance weight in the position shown.
b. When installing balance weight to wheels, set it into the grooved area on the inner wall of the wheel as shown so that the balance
weight center is aligned with the wheel balancer indication posi-
tion (angle).
CAUTION:
Always use Genuine NISSAN adhesion balance weights.
Balance weights are not reusable; always replace with
new ones.
Do not install more than three sheets of balance weights.
SMA054D
WDIA0060E

Page 3296 of 3383

INFINITI QX56 2006 Factory Service Manual WHEEL AND TIRE ASSEMBLYWT-7
C
DF
G H
I
J
K L
M A
B
WT
Revision: November 2009 2006 QX56
c. If calculated balance weight value exceeds 50 g (1.76 oz), install
two balance weight sheets in line with eac
