Page 2633 of 3383
PB-2
PREPARATION
Revision: November 20092006 QX56
PREPARATIONPFP:00002
Commercial Service ToolsEFS0068I
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool nameDescription
—
(J-21177-A)
Brake drum clearence gauge Measuring rear rotor drum to parking
brake shoe clearance
Power tool Loosening bolts and nuts
WFIA0167E
PBIC0190E
Page 2634 of 3383

PARKING BRAKE SYSTEMPB-3
C
DE
G H
I
J
K L
M A
B
PB
Revision: November 2009 2006 QX56
PARKING BRAKE SYSTEMPFP:36010
On-Vehicle ServiceEFS0068J
PEDAL STROKE
When parking brake pedal is operated with the specified force, make sure the stroke is within the specified
number of notches. Check by listening and counting the ratchet clicks.
INSPECTION
Make sure the components are attached properly, checking for looseness or backlash.
Check parking brake pedal assembly for bends, damage and cracks, and replace if necessary.
Check cable for wear and damage, and replace if necessary.
Check parking brake warning lamp switch for malfunction, and replace if necessary. Refer to DI-32, "Wir-
ing Diagram — WARN —" .
ADJUSTMENT
1. Remove the lower instrument panel LH. Refer to IP-13, "INSTRUMENT LOWER COVER LH" .
2. Partially engage parking brake pedal to access adjusting nut.
3. Insert a deep socket wrench to rotate adjusting nut and loosen cable sufficiently. Then, disengage the parking brake pedal.
4. Remove the wheel and tire using power tool.
5. Remove the disc rotor and measure inner diameter at widest point using Tool.
6. Transfer measurement less 0.6 mm to the parking brake shoes and adjust accordingly.
7. Using wheel nuts, secure the disc to the hub to prevent it from tilting.
8. Rotate the disc rotor to make sure there is no drag.
9. Adjust cable as follows:
a. Operate pedal 10 or more times with a force of 490 N (50 kg-f, 110 lb-f).
b. Rotate adjusting nut with deep socket to adjust pedal stroke to specification.
c. With parking brake pedal completely disengaged, make sure there is no drag on the parking brake.
10. Install the disc rotor.
11. Install the wheel and tire using power tool.
12. Install the lower instrument panel LH. Refer to IP-13, "
INSTRU-
MENT LOWER COVER LH" .
Pedal stroke : 3
− 4 notches [under force of 196 N (20.0 kg-f, 44.1 lb-f)]
WFIA0165E
Tool number : — (J-21177-A)
Pedal stroke : 3 − 4 notches [under force of
196 N (20.0 kg-f, 44.1 lb-f)]
WFIA0166E
Page 2635 of 3383

PB-4
PARKING BRAKE CONTROL
Revision: November 20092006 QX56
PARKING BRAKE CONTROLPFP:36010
ComponentsEFS0068K
Removal and InstallationEFS0068L
REMOVAL
1. Remove the lower instrument panel LH and center console. Refer to IP-14, "Lower Instrument Panel RH
and Glove Box" and IP-16, "Center Console" .
2. Remove the floor trim. Refer to EI-37, "
Removal and Installation" .
3. Disconnect the parking brake warning lamp switch.
4. Remove the adjusting nut. CAUTION:
Do not reuse adjusting nut after removing it.
5. Remove the lock plate from the front cable.
6. Remove front cable bolts and nut.
7. Disconnect return spring from equalizer.
8. Disconnect the front cable from the equalizer and remove front cable.
9. Remove the rear disc rotors. Refer to BR-28, "
Removal and Installation of Brake Caliper and Disc Rotor" .
10. Remove shoes, and remove left and right rear cables from toggle levers. Refer to PB-6, "
Removal and
Installation" .
11. Remove equalizer from right and left rear cables.
1. Pedal assembly 2. Front cable 3. Right rear cable
4. Left rear cable 5. Return spring 6. Equalizer
7. Adjusting nut 8. Lock plate
WFIA0163E
Page 2636 of 3383
PARKING BRAKE CONTROLPB-5
C
DE
G H
I
J
K L
M A
B
PB
Revision: November 2009 2006 QX56
12. Remove right and left rear cable bolts and nuts, then remove right and left rear cables.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Do not reuse adjusting nut after removing it.
Adjust parking brake. Refer to PB-3, "ADJUSTMENT" .
Page 2637 of 3383
PB-6
PARKING BRAKE SHOE
Revision: November 20092006 QX56
PARKING BRAKE SHOEPFP:44060
Removal and InstallationEFS0068M
COMPONENTS
REMOVAL
WARNING:
Clean the brakes with a vacuum dust collector to minimize the hazard of airborne particles or other
materials.
NOTE:
Remove the disc rotor only with the parking brake pedal completely disengaged.
1. Remove wheel hub and bearing assembly. Refer to FAX-5, "
Removal and Installation" .
Disconnect the wheel sensor at the harness connector. It is not necessary to remove the wheel sensor
from the wheel hub and bearing assembly.
2. Remove the return springs.
3. Remove the adjuster.
4. Remove the retainers, anti-rattle pins and shoes.
5. Disconnect the rear cable from the toggle lever.
6. Remove the back plate.
1. Back plate 2. Shoes 3. Toggle lever
4. Return springs 5. Retainers 6. Adjuster
7. Anti-rattle pins
WFIA0164E
Page 2638 of 3383

PARKING BRAKE SHOEPB-7
C
DE
G H
I
J
K L
M A
B
PB
Revision: November 2009 2006 QX56
INSPECTION AFTER REMOVAL
Lining Thickness Inspection
Check thickness of lining.
Drum Inner Diameter Inspection
Check drum inner diameter.
Other Inspections
Check shoe sliding surface for excessive wear and damage.
Check anti-rattle pins for excessive wear and corrosion.
Check return springs for sagging.
Check adjuster for rough operation.
When disassembling adjuster, apply PBC (Poly Butyl Cuprysil) grease or equivalent to the adjuster
threads. Refer to MA-11, "
RECOMMENDED FLUIDS AND LUBRICANTS" .
Check either visually or with a vernier caliper to see if there is any excessive wear, cracks, or damage
inside drum.
INSTALLATION
Installation is in the reverse order of removal.
Apply brake grease to the specified points during assembly. Refer to PB-4, "Components" .
Install adjuster so that threaded part expands when rotating it in
the direction shown by the arrow.
Shorten adjuster by rotating it in the oposite direction as shown
by the arrow.
NOTE:
After replacing brake shoes or disc rotors, or if parking brake does
not function well, perform break-in operation as follows.
1. Adjust parking brake pedal stroke. Refer to PB-3, "
ADJUST-
MENT" .
2. Perform parking brake burnishing operation by driving the vehicle forward under the following conditions: Standard thickness "A" : 5.15
± 0.25 mm
(0.203 ± 0.010 in)
Wear limit thickness "A" : 0.5 mm (0.020 in)
SBR021A
Standard inner diameter : 205 ± 0.13 mm
(8.07 ± 0.01 in)
Wear limit of inner diameter : 205.7 mm (8.10 in)
SBR768A
SFIA0153E
Vehicle speed 40 km/h (25 mph) set (forward)
Parking brake operating force 196 N (20.0 kg-f, 44.1 lb-f) set
Apply time 30 sec.
Page 2639 of 3383
PB-8
PARKING BRAKE SHOE
Revision: November 20092006 QX56
CAUTION:
To prevent lining from getting too hot, allow a cool off period of approximately 5 minutes after
every break-in operation.
Do not perform excessive break-in operations, because it may cause uneven or early wear of
lining.
3. After burnishing operation, check parking brake pedal stroke. Readjust if it is now longer than the speci- fied stroke. Refer to PB-3, "
ADJUSTMENT" .
Page 2640 of 3383
SERVICE DATA AND SPECIFICATIONS (SDS)PB-9
C
DE
G H
I
J
K L
M A
B
PB
Revision: November 2009 2006 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Parking Drum Brake EFS0068N
Unit: mm (in)
Parking Brake ControlEFS0068O
Ty p e Drum
Brake lining Standard thickness (new)
5.15 ± 0.25 (0.203 ± 0.010)
Wear limit thickness 0.5 (0.020)
Drum inner diameter (disc) Standard inner diameter (new)
205 ± 0.13 (8.07 ± 0.01)
Wear limit of inner diameter 205.7 (8.10)
Control type Foot pedal
Number of notches [under force of 196 N (20.0 kg-f, 44.1 lb-f)] 3 – 4 notches
Number of notches when parking brake warning lamp switch comes on 1 notch
