2006 INFINITI QX56 Factory Service Manual

sat nav technical data key battery adblue gas mileage headlamp

Page 3369 of 3383

INFINITI QX56 2006 Factory Service Manual WW-42
REAR WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
CONSULT-II Function (BCM)EKS00BEH
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSU

Page 3370 of 3383

INFINITI QX56 2006 Factory Service Manual REAR WIPER AND WASHER SYSTEMWW-43
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
4. Select the desired part to be diagnosed on the "SELECT TEST
ITEM" screen.
DATA MONITOR
Operation Proced

REAR WIPER AND WASHER SYSTEMWW-43
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
4. Select the desired part to be diagnosed on the "SELECT TEST
ITEM" screen.
DATA MONITOR
Operation Procedure
1. Touch "WIPER" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on "SELECT MONITOR ITEM" screen.
4. Touch "START".
5. When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is
selected, all the items will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".
Display Item List
ACTIVE TEST
Operation Procedure
1. Touch "WIPERS" on the "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on the "SELECT DIAG MODE" screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching "BACK" deactivates the operation.
LKIA0183E
All signals Monitors all the items.
Selection from menu Selects and monitors the individual item selected.
Monitor item name
"OPERATION OR UNIT" Contents
IGN ON SW "ON/OFF" Displays "IGN Position (ON)/OFF, ACC Position (OFF)" status as judged from ignition switch signal.
IGN SW CAN "ON/OFF" Displays "IGN Position (ON)/OFF, ACC Position (OFF)" status as judged from CAN communica-
tions.
FR WIPER INT "ON/OFF" Displays "Front Wiper INT (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WIPER LOW "ON/OFF" Displays "Front Wiper LOW (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WIPER HI "ON/OFF" Displays "Front Wiper HI (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WASHER SW "ON/OFF" Displays "Front Washer Switch (ON)/Other (OFF)" status as judged from wiper switch signal.
INT VOLUME (1 - 7) Displays intermittent operation dial position setting (1 - 7) as judged from wiper switch signal.
VEHICLE SPEED "0.0 km/h" Displays vehicle speed as received over CAN communication.
FR WIPER STOP "ON/OFF" Displays "Stopped (ON)/Operating (OFF)" status as judged from the auto stop signal.
RR WIPER INT "ON/OFF" Displays "Rear Wiper INT (ON)/Other (OFF)" status as judged from wiper switch signal.
RR WIPER ON "ON/OFF" Displays "Rear Wiper (ON)/Other (OFF)" status as judged from wiper switch signal.
RR WASHER SW "ON/OFF" Displays "Rear Washer Switch (ON)/Other (OFF)" status as judged from wiper switch signal.
RR WIPER STOP "ON/OFF" Displays "Stopped (OFF)/Operating (ON)" status as judged from the auto stop switch 1.
RR AUTO STP 2 "ON/OFF" Displays "Stopped (OFF)/Operating (ON)" status as judged from the auto stop switch 2.

Page 3371 of 3383

INFINITI QX56 2006 Factory Service Manual WW-44
REAR WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
Display Item List
Rear Wiper Does Not OperateEKS00GBJ
1. REAR WIPER ACTIVE TEST
1. Select "BCM" on CONSULT-II, and select "WIPER" o

Page 3372 of 3383

INFINITI QX56 2006 Factory Service Manual REAR WIPER AND WASHER SYSTEMWW-45
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
4. CHECK REAR WIPER MOTOR AUTO STOP CIRCUITS
1. Disconnect BCM connector M18.
2. Check continuity between

Page 3373 of 3383

INFINITI QX56 2006 Factory Service Manual WW-46
REAR WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
7. CHECK COMBINATION SWITCH INPUT SIGNAL
Select "BCM" on CONSULT-II. With "WIPER" data monitor, make
sure "RR WIPER INT", "RR WIPER

Page 3374 of 3383

INFINITI QX56 2006 Factory Service Manual REAR WIPER AND WASHER SYSTEMWW-47
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
3. CHECK REAR WIPER MOTOR AUTO STOP SWITCH GROUNDS
Check continuity between rear wiper motor harness conne

Page 3375 of 3383

INFINITI QX56 2006 Factory Service Manual WW-48
REAR WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
Only Rear Wiper Intermittent Does Not OperateEKS00BEL
1. CHECK COMBINATION SWITCH INPUT SIGNAL
Select "BCM" on CONSULT-II. With "WIP

Page 3376 of 3383

INFINITI QX56 2006 Factory Service Manual REAR WIPER AND WASHER SYSTEMWW-49
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
Rear Wiper Arm EKS00BEN
REMOVAL AND INSTALLATION
Removal
1. Remove wiper arm cover, and remove rear wiper

Load next 8 pages
