INFINITI QX56 2006 Factory Service Manual AV-16 AUDIO Revision: November 20092006 QX56 WKWA3586E

Page 610 of 3383

INFINITI QX56 2006 Factory Service Manual AUDIOAV-17 C DE F G H I J L M A B AV Revision: November 2009 2006 QX56 BKWA0849E

Page 611 of 3383

INFINITI QX56 2006 Factory Service Manual AV-18 AUDIO Revision: November 20092006 QX56 BKWA0850E

Page 612 of 3383

INFINITI QX56 2006 Factory Service Manual AUDIOAV-19 C DE F G H I J L M A B AV Revision: November 2009 2006 QX56 BKWA0851E

Page 613 of 3383

INFINITI QX56 2006 Factory Service Manual AV-20 AUDIO Revision: November 20092006 QX56 BKWA0852E

Page 614 of 3383

INFINITI QX56 2006 Factory Service Manual AUDIOAV-21 C DE F G H I J L M A B AV Revision: November 2009 2006 QX56 BKWA0853E

Page 615 of 3383

INFINITI QX56 2006 Factory Service Manual AV-22 AUDIO Revision: November 20092006 QX56 Terminals and Reference Value for Audio UnitEKS00BIB Terminal (Wire color) ItemSignal input/ output Condition Reference value (Approx.) Example of sympto

Page 616 of 3383

INFINITI QX56 2006 Factory Service Manual AUDIOAV-23 C DE F G H I J L M A B AV Revision: November 2009 2006 QX56 21 (V) GroundRemote control A Output ON Audio unit ON 5VRear audio remote control unit does not operate properly. 22 (P) Groun
