DI-48
WARNING CHIME
Revision: November 20092006 QX56
Terminals and Reference Value for BCMEKS00BCS
Terminal
No. Wire
color Item Condition
Reference value (V)
(Approx.)
Ignition
switch Measurement method
2 SB Combination switch input 5 ON
Light switch and wiper switch
OFF
Wiper dial position 4
3 G/Y Combination switch input 4 ON
Light switch and wiper switch
OFF
Wiper dial position 4
4 Y Combination switch input 3 ON
Light switch and wiper switch
OFF
Wiper dial position 4
5 G/B Combination switch input 2 ON
Light switch and wiper switch
OFF
Wiper dial position 4
6 V Combination switch input 1
32 R/G Combination switch output 5 ON
Light switch and wiper switch
OFF
Wiper dial position 4
33 R/Y Combination switch output 4 ON
Light switch and wiper switch
OFF
Wiper dial position 4
34 L Combination switch output 3 ON
Light switch and wiper switch
OFF
Wiper dial position 4
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E
Page 1170 of 3383

WARNING CHIMEDI-49
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
Terminals and Reference Value for Combination MeterEKS00BCT
How to Proceed With Trouble DiagnosisEKS00BCU
1. Confirm the symptom or customer complaint.
2. Understand operation description and function description. Refer to DI-44, "
System Description" .
3. Perform the preliminary check. Refer to DI-50, "
Preliminary Check" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the warning chime operate properly? If so, go to 6. If not, go to 3.
6. Inspection End.
35 O/B Combination switch output 2
ON
Light switch and wiper switch
OFF
Wiper dial position 4
36 R/W Combination switch output 1
37 B/R Key switch signal
OFFKey is removed
0
Key is inserted Battery voltage
38 W/L Ignition switch ON or START ON —Battery voltage
39 L CAN-H —— —
40 P CAN-L —— —
47 SB Front door switch LH signal OFF ON (open)
0
OFF (closed) 5
67 B Ground OFF— 0
70 W/B Battery power supply OFF— Battery voltage
Terminal
No. Wire
color Item Condition
Reference value (V)
(Approx.)
Ignition
switch Measurement method
SKIA5292E
Terminal
No. Wire
color Item Condition
Reference value (V)
(Approx.)
Ignition
switch Measurement method
11 L C A N - H —— —
12 P CAN-L —— —
17 B Ground OFF— 0
24 O/L Ignition switch ON or START ON —Battery voltage
27 O/B Seat belt buckle pre-ten-
sioner assembly (seat belt
buckle switch) LH
ONUnfastened (ON)
0
Fastened (OFF) Battery voltage
Page 1171 of 3383

DI-50
WARNING CHIME
Revision: November 20092006 QX56
Preliminary CheckEKS00BCV
INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT
1. CHECK FUSE AND FUSIBLE LINK
Check for blown BCM fuse or fusible link.
Refer to DI-46, "Wiring Diagram — CHIME —" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
4, "POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connectors M18 and M20.
2. Check voltage between BCM harness connector terminals and ground.
OK or NG
OK >> GO TO 3.
NG >> Check harness for open between BCM and fuse.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between BCM harness connector M20 terminal 67 and ground.
OK or NG
OK >> Inspection End.
NG >> Repair harness or connector.
Unit Power source Fuse or fusible link No.
BCM Battery
f
Ignition switch ON or START 59
TerminalsIgnition switch position
(+) (– )O FFO N
Connector Terminal
M20 70
GroundBattery volt-
age Battery volt-
age
M18 38 0VBattery volt-
age
WKIA2072E
Continuity should exist.
LIIA0915E
Page 1172 of 3383

WARNING CHIMEDI-51
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
CONSULT-II Function (BCM)EKS00BCW
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II BASIC OPERATION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-
SULT-II CONVERTER to the data link connector, and turn igni-
tion switch ON.
2. Touch “START (NISSAN BASED VHCL) ”.
3. Touch “BCM” on “SELECT SYSTEM ” screen. If “BCM” is not
indicated, go to GI-40, "
CONSULT-II Data Link Connector (DLC)
Circuit" .
BCM
diagnostic test item Diagnostic mode
Description
Inspection by part WORK SUPPORT
Supports inspections and adjustments. Commands are transmitted to the BCM
for setting the status suitable for required operation, input/output signals are
received from the BCM and received data is displayed.
DATA MONITOR Displays BCM input/output data in real time. ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read. ECU PART NUMBER BCM part number can be read.CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E
Page 1173 of 3383

DI-52
WARNING CHIME
Revision: November 20092006 QX56
4. Touch “BUZZER” or “BCM”.
5. Select “DATA MONITOR ”, “ACTIVE TEST ” or “SELF-DIAG
RESULTS ”.
DATA MONITOR
Operation Procedure
1. Touch “BUZZER” on “SELECT TEST ITEM ” screen.
2. Touch “DATA MONITOR” on “SELECT DIAG MODE ” screen.
3. Touch “ALL SIGNALS ” or “SELECTION FROM MENU ” on “DATA MONITOR” screen.
4. If “SELECTION FROM MENU” is selected, touch the item you desire to monitor. If “ALL SIGNALS” is
selected, all control items are monitored.
5. Touch “START”.
6. During monitoring, touching “RECORD” can start recording the monitored item status.
Display Item List
ACTIVE TEST
Operation Procedure
1. Touch “BUZZER” on “SELECT TEST ITEM ” screen.
2. Touch “ACTIVE TEST ” on “SELECT DIAG MODE ” screen.
3. Touch the item to be tested, and check the operation.
4. During the operation check, touching “OFF” deactivates the operation.
SKIA5788E
BCIA0031E
ALL SIGNALS Monitors main items.
SELECTION FROM MENU Selects and monitors items.
Monitored item Description
IGN ON SW Indicates [ON/OFF] condition of ignition switch.
KEY ON SW Indicates [ON/OFF] condition of key switch.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch (driver side).
LIGHT SW 1ST Indicates [ON/OFF] condition of lighting switch.
Page 1174 of 3383

WARNING CHIMEDI-53
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
Display Item List
SELF-DIAGNOSTIC RESULTS
Operation Procedure
1. Touch “BCM” on “SELECT TEST ITEM ” screen.
2. Touch “SELF-DIAG RESULTS ” on “SELECT DIAG MODE ” screen.
3. Self-diagnostic results are displayed.
Display Item List
All Warning Chimes Do Not OperateEKS00BCX
1. CHECK BCM CHIME OPERATION
Select “BUZZER ” on CONSULT-II, and perform “LIGHT WARN
ALM ”, "IGN KEY WARN ALM", OR "SEAT BELT WARN TEST"
active test.
Does chime sound?
YES >> Replace the BCM. Refer to BCS-20, "BCM" .
NO >> Replace the combination meter. Refer to IP-13, "
COM-
BINATION METER" .
Test item Malfunction is detected when
LIGHT WARN ALM This test is able to check light warning chime operation. Light warning chime sounds for 2 sec-
onds after touching
“ON ” on CONSULT-II screen.
IGN KEY WARN ALM This test is able to check key warning chime operation. Key warning chime sounds for 2 seconds
after touching
“ON ” on CONSULT-II screen.
SEAT BELT WARN TEST This test is able to check seat belt warning chime operation. Seat belt warning chime sounds for 2
seconds after touching
“ON ” on CONSULT-II screen.
Monitored Item CONSULT-II display Description
CAN communication CAN communication [U1000] Malfunction is detected in CAN communication.
CAN communication system CAN communication system 1 to 6 [U1000] Malfunction is detected in CAN system.
SKIA6331E
Page 1175 of 3383

DI-54
WARNING CHIME
Revision: November 20092006 QX56
Key Warning Chime and Light Warning Chime Do Not Operate (Seat Belt Warn-
ing Chime Does Operate)
EKS00BCY
1. CHECK BCM INPUT SIGNAL
With CONSULT-II
1. Select "BCM" on CONSULT-II.
2. With "DATA MONITOR" of "BUZZER", confirm "DOOR SW-DR" changes with the status of front door LH.
Without CONSULT-II
Check voltage between BCM harness connector M19 terminal 47
and ground.
OK or NG
OK >> Replace the BCM. Refer to BCS-20, "BCM" .
NG >> GO TO 2.
2. CHECK FRONT DOOR SWITCH LH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector M19 and front door switch LH con- nector B8.
3. Check continuity between BCM harness connector M19 terminal 47 and front door switch LH harness connector B8 terminal 2.
4. Check continuity between BCM harness connector M19 terminal 47 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector. When front door LH is
opened
: DOOR SW-DR ON
When front door LH is
closed : DOOR SW-DR OFF
LKIA0335E
When front door LH is
opened: Approx. 0V
When front door LH is
closed : Approx. 5V
WKIA1515E
Continuity should exist.
Continuity should not exist.
WKIA1516E
Page 1176 of 3383

WARNING CHIMEDI-55
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
3. CHECK FRONT DOOR SWITCH LH
Check continuity between front door switch LH terminal 2 and
exposed metal of switch while pressing and releasing switch.
OK or NG
OK >> Replace the BCM. Refer to BCS-20, "BCM" .
NG >> Replace the front door switch LH.
Key Warning Chime Does Not OperateEKS00BCZ
1. CHECK FUSE
Check if the key switch fuse [No. 19, located in the fuse block (J/B)] is blown. Refer to DI-46, "
Wiring Diagram
— CHIME —" .
Is the fuse blown?
YES >> Replace the fuse. Be sure to repair the cause of malfunction before installing new fuse.
NO >> GO TO 2.
2. CHECK WARNING CHIME OPERATION
With key removed from the ignition key cylinder and the front door LH open, turn the lighting switch to 1st or
2nd position.
Does warning chime sound?
YES >> GO TO 3.
NO >> Go to DI-53, "
All Warning Chimes Do Not Operate" or DI-54, "Key Warning Chime and Light
Warning Chime Do Not Operate (Seat Belt Warning Chime Does Operate)" .
When front door switch
LH is released
: Continuity should exist.
When front door switch
LH is pressed : Continuity should not
exist.
WKIA2023E
