TF-56
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
2. CHECK GROUND CIRCUIT
1. Turn ignition switch “ OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector.
3. Check continuity between transfer control unit harness connec- tor E142 terminals 3, 6, E143 terminal 45 and ground.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-35, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> GO TO 4.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
4. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> Inspection End.
NG >> Replace transfer control unit. Refer to TF-132, "
Removal and Installation" .
Continuity should exist.
SDIA2691E
Page 3162 of 3383

TROUBLE DIAGNOSIS FOR SYSTEMTF-57
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
COMPONENT INSPECTION
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Remove transfer shut off relay. Refer to TF-22, "
Location of Electrical Parts" .
3. Apply 12V direct current between transfer shut off relay termi- nals 1 and 2.
4. Check continuity between relay terminals 3 and 5.
5. If NG, replace the transfer shut off relay. Refer to TF-22, "
Loca-
tion of Electrical Parts" .
Transfer Control UnitEDS002I5
DIAGNOSTIC PROCEDURE
1. INSPECTION START
Do you have CONSULT-II?
YES or NO
YES >> GO TO 2.
NO >> GO TO 3.
2. PERFORM SELF-DIAGNOSIS (WITH CONSULT-II)
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “SELF-DIAG RESULTS ” mode for “ALL MODE AWD/4WD ” with CONSULT-II.
3. Touch “ERASE”.
4. Turn ignition switch “OFF” and wait at least 10 seconds.
5. Perform the self-diagnosis again.
Is the
“CONTROL UNIT 1 [P1802]”, “CONTROL UNIT 2 [P1803]”, “CONTROL UNIT 3 [P1804]” or “CONTROL
UNIT 4 [P1809]” displayed?
YES >> Replace transfer control unit. Refer to TF-132, "Removal and Installation" .
NO >> Inspection End.
3. PERFORM SELF-DIAGNOSIS (WITHOUT CONSULT-II)
Without CONSULT-II
1. Perform the self-diagnosis and then erase self-diagnostic results. Refer to TF-50, "
SELF-DIAGNOSTIC
PROCEDURE (WITHOUT CONSULT-II)" and TF-53, "ERASE SELF-DIAGNOSIS" .
2. Perform the self-diagnosis again.
Do the self-diagnostic results indicate AD converter?
YES >> Replace transfer control unit. Refer to TF-132, "Removal and Installation" .
NO >> Inspection End.
Condition Continuity
12V direct current supply between terminals 1 and 2 Yes
OFF No
SCIA1245E
Page 3163 of 3383

TF-58
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
Output Shaft Revolution Signal (TCM)EDS002I6
DIAGNOSTIC PROCEDURE
1. CHECK DTC WITH TCM
Perform self-diagnosis with TCM. Refer to TF-50, "
SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II)" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 2.
2. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-54, "
TRANSFER CONTROL UNIT TERMINALS
AND REFERENCE VALUE" .
OK or NG
OK >> GO TO 3.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
3. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> Inspection End.
NG >> Perform self-diagnosis with TCM again. Refer to TF-50, "
SELF-DIAGNOSTIC PROCEDURE
(WITH CONSULT-II)" .
Vehicle Speed Sensor (ABS)EDS002I7
DIAGNOSTIC PROCEDURE
1. CHECK DTC WITH ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Perform self-diagnosis with ABS actuator and electric unit (control unit). Refer to BRC-29, "
SELF-DIAGNO-
SIS" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 2.
2. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-54, "
TRANSFER CONTROL UNIT TERMINALS
AND REFERENCE VALUE" .
OK or NG
OK >> GO TO 3.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
3. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> Inspection End.
NG >> Perform self-diagnosis with ABS actuator and electric unit (control unit) again. Refer to BRC-29,
"SELF-DIAGNOSIS" .
Page 3164 of 3383

TROUBLE DIAGNOSIS FOR SYSTEMTF-59
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
Neutral-4LO SwitchEDS002I8
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.Monitored item
Content ConditionDisplay value
N POSI SW TF [ON/
OFF] Condition of neutral-4LO
switch
Vehicle stopped
Engine running
A/T selector lever “
N”
position
Brake pedal depressed 4WD shift switch: 2WD,
AUTO or 4H
OFF
4WD shift switch: 4H to
4LO (While actuator
motor is operating.) OFF
→ ON
4WD shift switch: 4LO to
4H (While actuator motor
is operating.) ON →
OFF
4WD shift switch: 4LO ON
TerminalWire
color Item
ConditionData (Approx.)
25 V Neutral-4LO switch
Vehicle stopped
Engine running
A/T selector
lever “N ” position
Brake pedal
depressed 4WD shift switch: 2WD, AUTO or 4H Battery voltage
4WD shift switch: 4H to 4LO (While actua-
tor motor is operating.)
Battery volt-
age
→ 0V
4WD shift switch: 4LO to 4H (While actua-
tor motor is operating.) 0V
→ Battery
voltage
4WD shift switch: 4LO 0V
Page 3165 of 3383

TF-60
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
DIAGNOSTIC PROCEDURE
1. CHECK 4LO POSITION SWITCH SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR ” mode for “ALL MODE AWD/4WD ” with CONSULT-II.
3. Read out the value of “N POSI SW TF”.
Without CONSULT-II
1. Start engine.
2. Check voltage between transfer control unit harness connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND NEUTRAL-4LO SWITCH
1. Turn ignition switch “ OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and the neutral-4LO switch harness connector.
3. Check continuity between transfer control unit harness connec- tor E143 terminal 25 and neutral-4LO switch harness connector
F60 terminal 13.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
Condition Display value
Vehicle stopped
Engine running
A/T selector lever “N ” position
Brake pedal depressed 4WD shift switch: 2WD,
AUTO or 4H
OFF
4WD shift switch: 4H to
4LO (While actuator
motor is operating.) OFF →
ON
4WD shift switch: 4LO to
4H (While actuator motor
is operating.) ON
→ OFF
4WD shift switch: 4LO ON
SDIA2692E
ConnectorTerminal
(Wire
color) Condition
Voltage
(Approx.)
E143 25 -
Ground
Vehicle stopped
Engine running
A/T selector lever
“ N ” position
Brake pedal
depressed 4WD shift switch:
2WD, AUTO or 4H
Battery
voltage
4WD shift switch: 4H
to 4LO (While actuator
motor is operating.) Battery
voltage
→
0V
4WD shift switch: 4LO
to 4H (While actuator
motor is operating.) 0V
→
Battery
voltage
4WD shift switch: 4LO 0V
SDIA2693E
Continuity should exist.
SDIA2694E
Page 3166 of 3383

TROUBLE DIAGNOSIS FOR SYSTEMTF-61
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
3. CHECK GROUND CIRCUIT
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect neutral-4LO switch harness connector.
3. Check continuity between neutral-4LO switch harness connec- tor F60 terminal 12 and ground.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK 4LO SWITCH
1. Turn ignition switch “OFF”.
2. Disconnect neutral-4LO switch harness connector.
3. Remove neutral-4LO switch. Refer to TF-22, "
Location of Electrical Parts" .
4. Push and release neutral-4LO switch and check continuity between neutral-4LO switch terminals 12 and 13.
OK or NG
OK >> GO TO 5.
NG >> Replace neutral-4LO switch. Refer to TF-22, "
Location
of Electrical Parts" .
5. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-54, "
TRANSFER CONTROL UNIT TERMINALS
AND REFERENCE VALUE" .
OK or NG
OK >> GO TO 6.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
6. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> Inspection End.
NG >> Replace transfer control unit. Refer to TF-132, "
Removal and Installation" .
Continuity should exist.
SDIA2695E
Terminal
Condition Continuity
12 - 13 Push neutral-4LO switch
Yes
Release neutral-4LO switch No
SDIA2696E
Page 3167 of 3383

TF-62
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
COMPONENT INSPECTION
1. Turn ignition switch “OFF ”. (Stay for at least 5 seconds.)
2. Disconnect neutral-4LO switch harness connector.
3. Remove neutral-4LO switch. Refer to TF-22, "
Location of Electrical Parts" .
4. Push and release neutral-4LO switch and check continuity between neutral-4LO switch terminals 12 and 13.
5. If NG, replace the neutral-4LO switch. Refer to TF-22, "
Location
of Electrical Parts" .
4WD Shift SwitchEDS002I9
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.Terminal
Condition Continuity
12 - 13 Push neutral-4LO switch
Yes
Release neutral-4LO switch No
SDIA2696E
Monitored item [Unit]Content ConditionDisplay value
2WD SWITCH [ON/
OFF] Input condition from 4WD
shift switch 4WD shift switch: 2WD
ON
4WD shift switch: AUTO, 4H or 4LO OFF
AUTO SWITCH [ON/
OFF] Input condition from 4WD
shift switch 4WD shift switch: AUTO
ON
4WD shift switch: 2WD, 4H or 4LO OFF
LOCK SWITCH [ON/
OFF] Input condition from 4WD
shift switch 4WD shift switch: 4H
ON
4WD shift switch: 2WD, AUTO or 4LO OFF
4L SWITCH [ON/OFF] Input condition from 4WD
shift switch 4WD shift switch: 4LO
ON
4WD shift switch: 2WD, AUTO or 4H OFF
4WD MODE [AUTO/
LOCK/2WD/4L] Control status of 4WD
(Output condition of 4WD
shift indicator lamp and
4LO indicator lamp)
Vehicle stopped
Engine running
A/T selector lever
“N ”
position
Brake pedal depressed 4WD shift switch: 2WD
2WD
4WD shift switch: AUTO AUTO
4WD shift switch: 4H LOCK
4WD shift switch: 4LO 4L
Te r m i n a lWire
color Item
ConditionData (Approx.)
9G/W 4WD shift switch
(2WD) Ignition switch: ON4WD shift switch: 2WD
Battery voltage
4WD shift switch: AUTO, 4H or 4LO 0V
18 O 4WD shift switch
(4H) Ignition switch: ON4WD shift switch: 4H
Battery voltage
4WD shift switch: 2WD, AUTO or 4LO 0V
23 R 4WD shift switch
(4LO) Ignition switch: ON4WD shift switch: 4LO
Battery voltage
4WD shift switch: 2WD, AUTO or 4H 0V
24 LG/R 4WD shift switch
(AUTO) Ignition switch: ON4WD shift switch: AUTO
Battery voltage
4WD shift switch: 2WD, 4H or 4LO 0V
Page 3168 of 3383

TROUBLE DIAGNOSIS FOR SYSTEMTF-63
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
DIAGNOSTIC PROCEDURE
1. CHECK 4WD SHIFT SWITCH SIGNAL
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR ” mode for “ALL MODE AWD/4WD ” with CONSULT-II.
3. Read out ON/OFF switching action of the “2WD SWITCH”,
“AUTO SWITCH”, “LOCK SWITCH”, “4L SWITCH ” with operat-
ing 4WD shift switch.
Without CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Check voltage between transfer control unit harness connector terminals and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
SDIA2697E
Connector Terminal ConditionVoltage
(Approx.)
E142 9 - ground
4WD shift switch: 2WD
Battery voltage
4WD shift switch: AUTO, 4H or 4LO 0V
18 - ground 4WD shift switch: 4H
Battery voltage
4WD shift switch: 2WD, AUTO or
4LO 0V
23 - ground 4WD shift switch: 4LO
Battery voltage
4WD shift switch: 2WD, AUTO or
4H 0V
24 - ground 4WD shift switch: AUTO
Battery voltage
4WD shift switch: 2WD, 4H or 4LO 0V
WDIA0148E
