Page 3305 of 3383

INFINITI QX56 2006 Factory Service Manual WT-16
TROUBLE DIAGNOSES
Revision: November 20092006 QX56
ID REGISTRATION WITHOUT TRANSMITTER ACTIVATION TOOL
NOTE:
This procedure must be done after replacement of a low tire pressure warning transmit

Page 3306 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSESWT-17
C
DF
G H
I
J
K L
M A
B
WT
Revision: November 2009 2006 QX56
8. Inflate all tires to proper pressure. Refer to WT-38, "Tire" .
Activation tire position CONSULT-II
Front LH “YE

Page 3307 of 3383

INFINITI QX56 2006 Factory Service Manual WT-18
TROUBLE DIAGNOSES
Revision: November 20092006 QX56
Transmitter Wake Up OperationEES001I8
WITH TRANSMITTER ACTIVATION TOOL
NOTE:
This procedure must be done after replacement of a low tire pressu

Page 3308 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSESWT-19
C
DF
G H
I
J
K L
M A
B
WT
Revision: November 2009 2006 QX56
CONSULT-II Function (BCM)EES001Q2
CONSULT-II can display each diagnostic item using the diagnostic test modes shown f

Page 3309 of 3383

INFINITI QX56 2006 Factory Service Manual WT-20
TROUBLE DIAGNOSES
Revision: November 20092006 QX56
Self-DiagnosisEES001I9
DESCRIPTION
During driving, the low tire pressure warning system receives the signal transmitted from the transmitter
in

WT-20
TROUBLE DIAGNOSES
Revision: November 20092006 QX56
Self-DiagnosisEES001I9
DESCRIPTION
During driving, the low tire pressure warning system receives the signal transmitted from the transmitter
installed in each wheel, and gives alarms when the tire pressure becomes low. The control unit (BCM) for this
system has pressure judgement and trouble diagnosis functions.
FUNCTION
When the low tire pressure warning system detects low inflation pressure or another unusual symptom, the
warning lamp in the combination meter comes on. To start the self-diagnostic results mode, ground the tire
pressure warning check terminal. The malfunction location is indicated by the low tire pressure warning lamp
flashing and the buzzer sounds.
CONSULT-II
CONSULT-II Application to Low Tire Pressure Warning System
× : Applicable
– : Not applicable
Self-Diagnostic Results Mode
NOTE:
Before performing the self-diagnosis, be sure to register the ID or the actual malfunction location may be different from that displayed on
CONSULT-II. ITEM
SELF-DIAGNOSTIC RESULTS DATA MONITOR
Front - Left transmitter ××
Front - Right transmitter ××
Rear - Left transmitter ××
Rear - Right transmitter ××
Warning lamp —×
Vehicle speed ××
Buzzer (in combination meter) —×
CAN Communication ××
Diagnostic itemDiagnostic item is detected when ···
FLAT - TIRE - FL [C1704]
FLAT - TIRE - FR [C1705]
FLAT - TIRE - RR [C1706]
FLAT - TIRE - RL [C1707] Front-left tire pressure drops to 193 kPa (2.0 kg/cm
2 , 28 psi) or less
Front-right tire pressure drops to 193 kPa (2.0 kg/cm2 , 28 psi) or less
Rear-right tire pressure drops to 193 kPa (2.0 kg/cm2 , 28 psi) or less
Rear-left tire pressure drops to 193 kPa (2.0 kg/cm2 , 28 psi) or less
[NO-DATA] - FL [C1708]
[NO-DATA] - FR [C1709]
[NO-DATA] - RR [C1710]
[NO-DATA] - RL [C1711] Data from front-left transmitter cannot be received.
Data from front-right transmitter cannot be received.
Data from rear-right transmitter cannot be received.
Data from rear-left transmitter cannot be received.
[CHECKSUM- ERR] - FL
[CHECKSUM- ERR] - FR
[CHECKSUM- ERR] - RR
[CHECKSUM- ERR] - RL Checksum data from front-left transmitter is malfunctioning.
Checksum data from front-right transmitter is malfunctioning.
Checksum data from rear-right transmitter is malfunctioning.
Checksum data from rear-left transmitter is malfunctioning.
[PRESSDATA- ERR] - FL
[PRESSDATA- ERR] - FR
[PRESSDATA- ERR] - RR
[PRESSDATA- ERR] - RL Air pressure data from front-left transmitter is malfunctioning.
Air pressure data from front-right transmitter is malfunctioning.
Air pressure data from rear-right transmitter is malfunctioning.
Air pressure data from rear-left transmitter is malfunctioning.
[CODE- ERR] - FL
[CODE- ERR] - FR
[CODE- ERR] - RR
[CODE- ERR] - RL Function code data from front-left transmitter is malfunctioning.
Function code data from front-right transmitter is malfunctioning.
Function code data from rear-right transmitter is malfunctioning.
Function code data from rear-left transmitter is malfunctioning.
[BATT - VOLT - LOW] - FL
[BATT - VOLT - LOW] - FR
[BATT - VOLT - LOW] - RR
[BATT - VOLT - LOW] - RL Battery voltage of front-left transmitter drops.
Battery voltage of front-right transmitter drops.
Battery voltage of rear-right transmitter drops.
Battery voltage of rear-left transmitter drops.
VHCL_SPEED_SIG_ERR [C1729] Vehicle speed signal is in error.

Page 3310 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSESWT-21
C
DF
G H
I
J
K L
M A
B
WT
Revision: November 2009 2006 QX56
Data Monitor Mode
NOTE:
Before performing the self-diagnosis, be sure to register the ID, or the actual malfunction l

Page 3311 of 3383

INFINITI QX56 2006 Factory Service Manual WT-22
TROUBLE DIAGNOSES
Revision: November 20092006 QX56
How to Perform Trouble Diagnosis for Quick and Accurate RepairEES001IA
INTRODUCTION
Before troubleshooting, verify customer complaints.
If a

Page 3312 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSESWT-23
C
DF
G H
I
J
K L
M A
B
WT
Revision: November 2009 2006 QX56
Preliminary CheckEES001IB
BASIC INSPECTION
1. CHECK ALL TIRE PRESSURES
Check all tire pressures. Refer to WT-38, "
T
