INFINITI QX56 2006 Factory Service Manual BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
Display Item List
Self-diagnostic itemMalfunction detecting condition Check system
FR LH SENSOR 1
[C1104] Circuit of front LH wh

BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
Display Item List
Self-diagnostic itemMalfunction detecting condition Check system
FR LH SENSOR 1
[C1104] Circuit of front LH wheel sensor is open, shorted or sensor power
voltage is unusual.
BRC-38, "
Wheel Sensor
System Inspection"
(Note 1)
RR RH SENSOR 1
[C1101]
Circuit of rear RH wheel sensor is open, shorted or sensor power
voltage is unusual.
FR RH SENSOR 1
[C1103] Circuit of front RH wheel sensor is open, shorted or sensor power
voltage is unusual.
RR LH SENSOR 1
[C1102] Circuit of rear LH wheel sensor is open, shorted or sensor power
voltage is unusual.
FR LH SENSOR 2
[C1108] ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
RR RH SENSOR 2
[C1105] ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
FR RH SENSOR 2
[C1107] ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
RR LH SENSOR 2
[C1106] ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
ABS SENSOR
[C1115] Wheel sensor input is abnormal.
STOP LAMP SW
[C1116] Stop lamp switch or circuit malfunction. BRC-45, "
Stop Lamp
Switch System Inspec-
tion"
DECEL G SEN SET
[C1160]
ABS decel sensor adjustment is incomplete. BRC-55, "Inspection For
Self-diagnosis Result
"DECEL G SEN SET""
ST ANGL SEN SAFE
[C1163]
When steering angle sensor is in safe mode. BRC-53, "Steering Angle
Sensor Safe Mode
Inspection"
ST ANG SEN CIRCUIT
[C1143]
Neutral position of steering angle sensor is dislocated, or steer-
ing angle sensor is malfunctioning. BRC-40, "Steering Angle
Sensor System"
YAW RATE SENSOR
[C1145]Yaw rate sensor has generated an error, or yaw rate sensor sig-
nal line is open or shorted. BRC-41, "Yaw Rate/
Side/Decel G Sensor
System Inspection"

Page 1058 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSISBRC-31
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
FR LH IN ABS SOL
[C1120]Circuit of front LH IN ABS solenoid is open or shorted, or control
line is o

TROUBLE DIAGNOSISBRC-31
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
FR LH IN ABS SOL
[C1120]Circuit of front LH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
BRC-43, "
Solenoid and
VDC Change-Over Valve
System Inspection"
FR LH OUT ABS SOL
[C1121]Circuit of front LH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
RR RH IN ABS SOL
[C1126] Circuit of rear RH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
RR RH OUT ABS SOL
[C1127] Circuit of rear RH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
FR RH IN ABS SOL
[C1122] Circuit of front RH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
FR RH OUT ABS SOL
[C1123] Circuit of front RH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
RR LH IN ABS SOL
[C1124] Circuit of rear LH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
RR LH OUT ABS SOL
[C1125] Circuit of rear LH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
CV1
[C1164] Front side VDC switch-over solenoid valve (cut valve) is open or
shorted, or control line is open or shorted to power supply or
ground.
CV2
[C1165] Rear side VDC switch-over solenoid valve (cut valve) is open or
shorted, or control line is open or shorted to power supply or
ground.
SV1
[C1166] Front side VDC switch-over solenoid valve (suction valve) is
open or shorted, or control line is open or shorted to power sup-
ply or ground.
SV2
[C1167] Rear side VDC switch-over solenoid valve (suction valve) is open
or shorted, or control line is open or shorted to power supply or
ground.
PUMP MOTOR
[ C 1111 ] During actuator motor operation with ON, when actuator motor
turns OFF or when control line for actuator motor relay is open.
BRC-44, "
Actuator
Motor, Motor Relay, and
Circuit Inspection"During actuator motor operation with OFF, when actuator motor
turns ON or when control line for relay is shorted to ground.
BATTERY VOLTAGE
[ABNORMAL]
[C1109] ABS actuator and electric unit (control unit) power voltage is too
low. BRC-46, "
ABS/TCS/
VDC Control Unit Power
and Ground Systems
Inspection"
ST ANG SEN SIGNAL
[C1144]
Neutral position correction of steering angle sensor is not fin-
ished. BRC-55, "Inspection For
Self-diagnosis Result
"ST ANG SEN SIGNAL""
ST ANG SEN COM CIR
[C1156]
CAN communication line or steering angle sensor has generated
an error. BRC-40, "Steering Angle
Sensor System"
G-SENSOR
[C1113]Longitudinal G-sensor is malfunctioning, or signal line of longitu-
dinal G-sensor is open or shorted. BRC-41, "Yaw Rate/
Side/Decel G Sensor
System Inspection"
CONTROLLER FAILURE
[C1110]
Internal malfunction of ABS actuator and electric unit (control
unit) BRC-40, "ABS/TCS/
VDC Control Unit
Inspection"
CAN COMM CIRCUIT
[U1000]
CAN communication line is open or shorted.
ABS actuator and electric unit (control unit) internal malfunc-
tion
Battery voltage for ECM is suddenly interrupted for approxi-
mately 0.5 second or more.BRC-54, "
CAN Commu-
nication System Inspec-
tion" (Note 2)
SIDE G-SEN CIRCUIT
[C1146] Lateral G-sensor is malfunctioning, or signal line of lateral G-sen-
sor is open or shorted. BRC-41, "
Yaw Rate/
Side/Decel G Sensor
System Inspection"
Self-diagnostic item
Malfunction detecting condition Check system

Page 1059 of 3383

INFINITI QX56 2006 Factory Service Manual BRC-32
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
Note 1. If wheel sensor 2 for each wheel is indicated, check ABS actuator and electric unit (control unit) power
supply voltage

BRC-32
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
Note 1. If wheel sensor 2 for each wheel is indicated, check ABS actuator and electric unit (control unit) power
supply voltage in addition to wheel sensor circuit check.
Note 2. If multiple malfunctions are detected including CAN communication line [U1000], perform diagnosis for
CAN communication line first.
DATA MONITOR
Operation Procedure
1. After turning OFF the ignition switch, connect CONSULT-II and the CONSULT-II CONVERTER to the data
link connector.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
2. Touch “START (NISSAN BASED VHCL) ”, “ABS”, “DATA MONITOR ” in order on the CONSULT-II screen.
If “ABS” is not indicated, go to GI-40, "
CONSULT-II Data Link Connector (DLC) Circuit" .
BR FLUID LEVEL LOW
[C1155] Brake fluid level drops or circuit between ABS actuator and elec-
tric unit (control unit) and brake fluid level switch is open or
shorted. BRC-47, "Brake Fluid
Level Switch System
Inspection"
ENGINE SIGNAL 1
[C1130]
Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
BRC-39, "
Engine Sys-
tem Inspection"
ENGINE SIGNAL 2
[C1131]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
ENGINE SIGNAL 3
[C1132] Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
ENGINE SIGNAL 4
[C1133] Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
ENGINE SIGNAL 6
[C1136] Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
ACTUATOR RLY
[C1140] ABS actuator relay or circuit malfunction. BRC-44, "
Actuator
Motor, Motor Relay, and
Circuit Inspection"
PRESS SEN CIRCUIT
[C1142]
ABS pressure sensor circuit malfunction.
BRC-51, "Pressure Sen-
sor System Inspection"
VARIANT CODING
[C1170]V coding is not malfunctioning. BRC-40, "ABS/TCS/
VDC Control Unit
Inspection"
ABS ACTIVE BOOSTER SV NG
[C1178]Active booster solenoid is malfunctioning, or signal line of active
booster servo is open or shorted. BRC-48, "Active Booster
System Inspection"
ABS DELTA S SEN NG
[C1179]Delta stroke sensor malfunctioning, or signal line of delta stroke
sensor is open or shorted. BRC-49, "Delta Stroke
Sensor System Inspec-
tion"
ABS ACTIVE BOOSTER
RESPONSE NG
[C1181]Active booster response is malfunctioning, or signal line of active
booster response is open or shorted.
BRC-48, "Active Booster
System Inspection"
ABS BRAKE RELEASE SW NG
[C1184]Brake release switch is malfunctioning, or signal line of brake
release switch is open or shorted. BRC-48, "Active Booster
System Inspection"
ABS ACC CU INTERNAL NG
[C1185]
ICC control unit internal malfunction.
BRC-54, "ICC System
Inspection"
ABS BRAKE BOOSTER DEFECT
[C1189]Brake booster is defective or malfunctioning. BRC-48, "Active Booster
System Inspection"
Self-diagnostic item
Malfunction detecting condition Check system

Page 1060 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSISBRC-33
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
CAUTION:
When “START (NISSAN BASED VHCL)” is touched immediately after starting the engine or tur

TROUBLE DIAGNOSISBRC-33
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
CAUTION:
When “START (NISSAN BASED VHCL)” is touched immediately after starting the engine or turning
on the ignition switch, “ABS” might not be displayed in the SELECT SYSTEM screen. In this case,
repeat the operation from step 2.
3. Return to the SELECT MONITOR ITEM screen, and touch “ECU INPUT SIGNALS”, “MAIN SIGNALS ”, or
“SELECTION FROM MENU ”. Refer to the following information.
4. When “START” is touched, the data monitor screen is displayed.
Display Item List
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
GEAR ××× Gear position judged by PNP
switch signal is displayed.
FR RH SENSOR
(km/h, MPH) ××× Wheel speed calculated by front
RH wheel sensor signal is dis-
played.
FR LH SENSOR
(km/h, MPH) ××× Wheel speed calculated by front LH
wheel sensor signal is displayed.
RR RH SENSOR
(km/h, MPH) ××× Wheel speed calculated by rear RH
wheel sensor signal is displayed.
RR LH SENSOR
(km/h, MPH) ×××
Wheel speed calculated by rear LH
wheel sensor signal is displayed.
BATTERY VOLT
(V) ××× Voltage supplied to ABS actuator
and electric unit (control unit) is dis-
played.
N POSI SIG ––× Shift position judged by PNP switch
signal.
P POSI SIG ––× Shift position judged by PNP switch
signal.
ACCEL POS SIG
(%) ×
–×Throttle valve open/close status
judged by CAN communication sig-
nal is displayed.
ENGINE SPEED
(rpm) ××× Engine speed judged by CAN com-
munication signal is displayed.
STR ANGLE SIG
(deg) ×
–×Steering angle detected by steering
angle sensor is displayed.
YAW R AT E S E N
(d/s) ×××
Yaw rate detected by yaw rate sen-
sor is displayed.
DECEL G-SEN
(d/s) ××× Longitudinal acceleration detected
by decel G-sensor is displayed.
SIDE G-SENSOR
(m/s
2 ) ×
– × Transverse acceleration detected
by side G-sensor is displayed.
STOP LAMP SW
(ON/OFF) ××× Stop lamp switch (ON/OFF) status
is displayed.
OFF SW
(ON/OFF)
×× × VDC OFF switch (ON/OFF) status
is displayed.
ABS WARN LAMP
(ON/OFF) –
×× ABS warning lamp (ON/OFF) status
is displayed.
SLIP LAMP
(ON/OFF) –
×× SLIP indicator lamp (ON/OFF) sta-
tus is displayed.
FR LH IN SOL
(ON/OFF) –
×× Front LH IN ABS solenoid (ON/
OFF) status is displayed.
FR LH OUT SOL
(ON/OFF) –
×× Front LH OUT ABS solenoid (ON/
OFF) status is displayed.

Page 1061 of 3383

INFINITI QX56 2006 Factory Service Manual BRC-34
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
RR RH IN SOL
(ON/OFF)–
×× Rear RH IN ABS solenoid (ON/
OFF) status is displayed.
RR RH OUT SOL
(ON/OFF) –
×× Rear RH OU

BRC-34
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
RR RH IN SOL
(ON/OFF)–
×× Rear RH IN ABS solenoid (ON/
OFF) status is displayed.
RR RH OUT SOL
(ON/OFF) –
×× Rear RH OUT ABS solenoid (ON/
OFF) status is displayed.
FR RH IN SOL
(ON/OFF) –
×× Front RH IN ABS solenoid (ON/
OFF) status is displayed.
FR RH OUT SOL
(ON/OFF) –
×× Front RH OUT ABS solenoid (ON/
OFF) status is displayed.
RR LH IN SOL
(ON/OFF) –
×× Rear LH IN ABS solenoid (ON/
OFF) status is displayed.
RR LH OUT SOL
(ON/OFF) –
×× Rear LH OUT ABS solenoid (ON/
OFF) status is displayed.
OFF LAMP
(ON/OFF) –
×× OFF Lamp (ON/OFF) status is dis-
played.
MOTOR RELAY
(ON/OFF) –
×× ABS motor relay signal (ON/OFF)
status is displayed.
ACTUATOR RLY
(ON/OFF) –
×× ABS actuator relay signal (ON/
OFF) status is displayed.
CV1
(ON/OFF) ––
×Front side switch-over solenoid
valve (cut valve) (ON/OFF) status is
displayed.
CV2
(ON/OFF) ––
×Rear side switch-over solenoid
valve (cut-valve) (ON/OFF) status
is displayed.
SV1
(ON/OFF) ––
×Front side switch-over solenoid
valve (suction valve) (ON/OFF) sta-
tus is displayed.
SV2
(ON/OFF) ––
×Rear side switch-over solenoid
valve (suction valve) (ON/OFF) sta-
tus is displayed.
VDC FAIL SIG
(ON/OFF) ––
×VDC fail signal (ON/OFF) status is
displayed.
TCS FAIL SIG
(ON/OFF) ––
×TCS fail signal (ON/OFF) status is
displayed.
ABS FAIL SIG
(ON/OFF) ––
×ABS fail signal (ON/OFF) status is
displayed.
EBD FAIL SIG
(ON/OFF) ––
×EBD fail signal (ON/OFF) status is
displayed.
FLUID LEV SW
(ON/OFF) ×
– ×Brake fluid level switch (ON/OFF)
status is displayed.
EBD SIGNAL
(ON/OFF) ––
×EBD operation (ON/OFF) status is
displayed.
ABS SIGNAL
(ON/OFF) ––
×ABS operation (ON/OFF) status is
displayed.
TCS SIGNAL
(ON/OFF) ––
×TCS operation (ON/OFF) status is
displayed.
VDC SIGNAL
(ON/OFF) ––
×VDC operation (ON/OFF) status is
displayed.
EBD WARN LAMP ––×Brake warning lamp (ON/OFF) sta-
tus is displayed.
SLCT LVR POSI ××× Shift position judged by PNP switch
signal.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU

Page 1062 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSISBRC-35
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
×: Applicable
– : Not applicable
ACTIVE TEST
CAUTION:
Do not perform active test while driving.

Page 1063 of 3383

INFINITI QX56 2006 Factory Service Manual BRC-36
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
Operation Procedure
1. Connect the CONSULT-II and CONSULT-II CONVERTER to the data link connector and start the engine.
CAUTION:

Page 1064 of 3383

INFINITI QX56 2006 Factory Service Manual TROUBLE DIAGNOSISBRC-37
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
ABS Motor
Touch “ON” and “OFF ” on the screen. Check that ABS motor relay
operates as shown i

Load next 8 pages

Page: < prev 1-10 ... 1025-1032 1033-1040 1041-1048 1049-1056 1057-1064 1065-1072 1073-1080 1081-1088 1089-1096 ... 3384 next >

diagnostic menu glove box reset infotainment system drain bolt wiper blades recommended oil
