Page 1097 of 3383

INFINITI QX56 2006 Factory Service Manual BRC-70
[VDC/TCS/ABS]
G SENSOR
Revision: November 20092006 QX56

Page 1098 of 3383

INFINITI QX56 2006 Factory Service Manual CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
DE
F
G H
I
J
K L
M
SECTION
A
CO
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 2
Precautions

CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
DE
F
G H
I
J
K L
M
SECTION
A
CO
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 2
Precautions for Liquid Gasket ............................. ..... 2
REMOVAL OF LIQUID GASKET SEALING ..... ..... 2
LIQUID GASKET APPLICATION PROCEDURE ..... 2
PREPARATION ...................................................... ..... 4
Special Service Tools .......................................... ..... 4
Commercial Service Tools ................................... ..... 4
OVERHEATING CAUSE ANALYSIS ..................... ..... 6
Troubleshooting Chart ......................................... ..... 6
COOLING SYSTEM ............................................... ..... 8
Cooling Circuit .......................................................... 8
System Drawing ....................................................... 9
ENGINE COOLANT ............................................... ... 10
Inspection ............................................................ ... 10
LEVEL CHECK ................................................ ... 10
CHECKING COOLING SYSTEM FOR LEAKS ... 10
CHECKING RESERVOIR CAP ........................ ... 10
CHECKING RADIATOR CAP ........................... ... 10
Changing Engine Coolant ................................... ... 10
DRAINING ENGINE COOLANT ...................... .... 11
REFILLING ENGINE COOLANT ..................... .... 11
FLUSHING COOLING SYSTEM ...................... ... 12
RADIATOR ............................................................. ... 14
Removal and Installation ..................................... ... 14
REMOVAL ........................................................ ... 14
INSTALLATION ................................................ ... 16INSPECTION AFTER INSTALLATION .............
... 16
Checking Radiator ............................................... ... 16
ENGINE COOLING FAN ........................................ ... 17
Removal and Installation (Crankshaft Driven Type) ... 17
REMOVAL ........................................................ ... 17
INSPECTION AFTER REMOVAL .................... ... 17
INSTALLATION ................................................ ... 17
INSPECTION AFTER INSTALLATION ............. ... 17
Removal and Installation (Motor Driven Type) .... ... 18
REMOVAL ........................................................ ... 18
INSTALLATION ................................................ ... 18
WATER PUMP ....................................................... ... 19
Removal and Installation ..................................... ... 19
REMOVAL ........................................................ ... 19
INSPECTION AFTER REMOVAL .................... ... 19
INSTALLATION ................................................ ... 19
INSPECTION AFTER INSTALLATION ............. ... 20
THERMOSTAT AND WATER PIPING ................... ... 21
Removal and Installation ..................................... ... 21
REMOVAL ........................................................ ... 21
INSPECTION AFTER REMOVAL .................... ... 22
INSTALLATION ................................................ ... 22
INSPECTION AFTER INSTALLATION ............. ... 22
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 23
Standard and Limit ............................................... ... 23
ENGINE COOLANT CAPACITY (APPROXI-
MATE) ............................................................... ... 23
THERMOSTAT ................................................. ... 23
RADIATOR ....................................................... ... 23

Page 1099 of 3383

INFINITI QX56 2006 Factory Service Manual CO-2Revision: November 2009
PRECAUTIONS
2006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EBS00RE2
The Supplemental Re

CO-2Revision: November 2009
PRECAUTIONS
2006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EBS00RE2
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Liquid GasketEBS00RE3
REMOVAL OF LIQUID GASKET SEALING
After removing the bolts and nuts, separate the mating surface
and remove the old liquid gasket sealing using Tool.
CAUTION:
Do not damage the mating surfaces.
Tap the seal cutter to insert it.
In areas where the Tool is difficult to use, lightly tap to slide it.
LIQUID GASKET APPLICATION PROCEDURE
1. Remove the old liquid gasket adhering to the gasket application surface and the mating surface using suitable tool.
Remove the liquid gasket completely from the groove of the
liquid gasket application surface, bolts, and bolt holes.
2. Thoroughly clean the mating surfaces and remove adhering moisture, grease and foreign material.Tool number
: KV10111100 (J-37228)
WBIA0566E
PBIC0003E

Page 1100 of 3383

INFINITI QX56 2006 Factory Service Manual PRECAUTIONSCO-3
C
DE
F
G H
I
J
K L
M A
CO
Revision: November 2009 2006 QX56
3. Attach the liquid gasket tube to the Tool.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-46, "
Recommended

Page 1101 of 3383

INFINITI QX56 2006 Factory Service Manual CO-4Revision: November 2009
PREPARATION
2006 QX56
PREPARATIONPFP:00002
Special Service ToolsEBS00RE4
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated he

Page 1102 of 3383

INFINITI QX56 2006 Factory Service Manual PREPARATIONCO-5
C
DE
F
G H
I
J
K L
M A
CO
Revision: November 2009 2006 QX56
Tool nameDescription
Power tool Loosening bolts and nuts
Radiator cap tester Checking radiator and radiator cap
Coolant syst

Page 1103 of 3383

INFINITI QX56 2006 Factory Service Manual CO-6Revision: November 2009
OVERHEATING CAUSE ANALYSIS
2006 QX56
OVERHEATING CAUSE ANALYSISPFP:00012
Troubleshooting ChartEBS00RE6
SymptomCheck items
Cooling sys-
tem parts
malfunction Poor heat tran

Page 1104 of 3383

INFINITI QX56 2006 Factory Service Manual OVERHEATING CAUSE ANALYSISCO-7
C
DE
F
G H
I
J
K L
M A
CO
Revision: November 2009 2006 QX56
Except cool-
ing system
parts mal-
function—
Overload on engine Abusive driving
High engine rpm under no

Load next 8 pages
