HEATER & COOLING UNIT ASSEMBLYATC-155
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
4. Drain the coolant from the engine cooling system. Refer to MA-13, "DRAINING ENGINE COOLANT" .
5. Disconnect the front heater hoses from the front heater core.
6. Disconnect the high/low pressure pipes from the front expansion valve.
7. Remove the instrument panel and console panel. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
8. Remove the steering column. Refer to PS-10, "
STEERING COLUMN" .
9. Disconnect the instrument panel wire harness at the RH and LH in-line connector brackets, and the fuse block (J/B) electrical connectors. Refer to PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .
10. Disconnect the steering member from each side of the vehicle body.
11. Remove the front heater and cooling unit assembly with it attached to the steering member, from the vehi- cle.
CAUTION:
Use care not to damage the seats and interior trim panels when removing the front heater and
cooling unit assembly with it attached to the steering member.
12. Remove the front heater and cooling unit assembly from the steering member.
Installation
Installation is in the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.

After charging the refrigerant, check for leaks.
NOTE:

Fill the engine cooling system with the specified coolant mixture. Refer to MA-14, "REFILLING ENGINE
COOLANT" .

Recharge the A/C system. Refer to ATC-171, "Evacuating System and Charging Refrigerant" .
REAR HEATER AND COOLING UNIT ASSEMBLY
Removal
1. Discharge the refrigerant from the A/C system. Refer to ATC-171, "Discharging Refrigerant" .
2. Drain the coolant from the engine cooling system. Refer to MA-13, "
DRAINING ENGINE COOLANT" .
3. Disconnect the rear heater core hoses from the rear heater core.
4. Disconnect the rear A/C pipes from the rear expansion valve.
5. Remove the luggage side finisher lower RH. Refer to EI-35,
"BODY SIDE TRIM" .
6. Disconnect the following electrical connectors:

Rear blower motor

Rear blower motor resistor

Rear air mix door motor
7. Disconnect the ducts from the rear heater and cooling unit assembly.
8. Remove the rear heater and cooling unit assembly.
Installation
Installation is in the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.

After charging the refrigerant, check for leaks.
NOTE:

Fill the engine cooling system with the specified coolant mixture. Refer to MA-14, "REFILLING ENGINE
COOLANT" .

Recharge the A/C system. Refer to ATC-171, "Evacuating System and Charging Refrigerant" .
LJIA0021E

DTC P0300 - P0308 MULTIPLE CYLINDER MISFIRE, NO. 1 - 8 CYLINDER MIS-FIRE
EC-331
C
D E
F
G H
I
J
K L
M A
EC
Revision: November 2009 2006 QX56
7. CHECK SPARK PLUG
Check the initial spark plug for fouling, etc.
OK or NG
OK >> Replace spark plug(s) with standard type one(s). For spark plug type, refer to EM-29, "
SPARK PLUG (PLATI-
NUM-TIPPED TYPE)" .
NG >> 1. Repair or clean spark plug.
2. GO TO 8.
8. CHECK FUNCTION OF IGNITION COIL-III
1. Reconnect the initial spark plugs.
2. Crank engine for about 3 seconds, and recheck whether spark is generated between the spark plug and the grounded portion.
OK or NG
OK >> INSPECTION END
NG >> Replace spark plug(s) with standard type one(s). For spark plug type, refer to MA-18, "
Changing
Spark Plugs" .
9. CHECK COMPRESSION PRESSURE
Check compression pressure. Refer to EM-63, "
CHECKING COMPRESSION PRESSURE" .
OK or NG
OK >> GO TO 10.
NG >> Check pistons, piston rings, valves, valve seats and cylinder head gaskets.
10. CHECK FUEL PRESSURE
1. Install all removed parts.
2. Release fuel pressure to zero. Refer to EC-80, "
FUEL PRESSURE RELEASE" .
3. Install fuel pressure gauge and check fuel pressure. Refer to EC-82, "
FUEL PRESSURE CHECK" .
OK or NG
OK >> GO TO 12.
NG >> GO TO 11.
11 . DETECT MALFUNCTIONING PART
Check the following.

Fuel pump and circuit (Refer to EC-604, "FUEL PUMP" .)

Fuel pressure regulator (Refer to EC-82, "FUEL PRESSURE CHECK" .)

Fuel lines

Fuel filter for clogging
>> Repair or replace.
SEF156I
Spark should be generated.
At idle: Approximately 350 kPa (3.57 kg/cm
2 , 51 psi)

FLOOR TRIMEI-37
C
DE
F
G H
J
K L
M A
B
EI
Revision: November 2009 2006 QX56
FLOOR TRIMPFP:74902
Removal and InstallationEIS004WS
REMOVAL
1. Remove front seats. Refer to SE-91, "FRONT SEAT" .

Remove subwoofer. Refer to AV- 5 9 , "SUBWOOFER" .

Remove navigation display control unit. Refer to AV- 1 6 7 , "DISPLAY CONTROL UNIT" .
2. Remove second row seats. Refer to SE-98, "
Second Row Outboard" and SE-98, "Second Row Center" ,
if equipped.
3. Remove third row rear seats. Refer to SE-105, "
THIRD SEAT" .
4. Remove lower seat belt anchors. Refer to SB-3, "
SEAT BELTS" .
5. Remove lower body side trim. Refer to EI-35, "
BODY SIDE TRIM" .
6. Remove luggage lower side finishers (left / right). Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
7. Remove kicking plates. Refer to EI-35, "
BODY SIDE TRIM" .
8. Remove center console. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
9. Remove rear console, if equipped. Refer to IP-19, "
DISASSEMBLY AND ASSEMBLY" .
10. Remove rear lower finisher. Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
11. Remove carpet.
12. Remove floor mat hook from front carpet.
INSTALLATION
Installation is in the reverse order of removal.
1. Carpet 2. Floor mat hook
WIIA0968E

EM-32Revision: November 2009
FUEL INJECTOR AND FUEL TUBE
2006 QX56
7. Remove the fuel injector from the fuel tube using the followingsteps.
a. Spread open and remove the clip.
b. Remove the fuel injector from the fuel tube by pulling straight out.
CAUTION:

Be careful with remaining fuel that may leak out from fuel
tube.

Do not damage injector nozzles during removal.

Do not bump or drop fuel injectors.

Do not disassemble fuel injectors.
8. Remove the fuel damper from each fuel tube.
INSTALLATION
1. Install the fuel damper to each fuel tube using the following steps.
a. Apply engine oil to the new O-ring and set it into the cup of the fuel tube.
CAUTION:

Handle O-ring with bare hands. Never wear gloves.

Lubricate new O-ring with new engine oil.

Do not clean O-ring with solvent.

Make sure that O-ring and its mating part are free of for-
eign material.

When installing O-ring, do not scratch it with tool or fin-
gernails.

Do not twist or stretch the O-ring.
b. Make sure that the backup spacer is in the O-ring connecting surface of the fuel damper. NOTE:
The backup spacer is part of the fuel damper assembly.
c. Insert the fuel damper until it seats on the fuel tube. CAUTION:

Insert straight, making sure that the axis is lined up.

Do not pressure-fit with excessive force.
d. Install the cap, and then tighten the bolts evenly.

After tightening the bolts, make sure that there is no gap between the cap and fuel tube.
2. Install new O-rings to the fuel injector paying attention to the items below. CAUTION:

Upper and lower O-rings are different colors.
KBIA2506E
Reference value :130 N (13.3 kg, 29.2 lb)
Fuel tube side : Blue
Nozzle side : Brown
KBIA2473E

CYLINDER HEADEM-67
C
DE
F
G H
I
J
K L
M A
EM
Revision: November 2009 2006 QX56
7. Remove the valve oil seal using Tool.
8. Replace the valve seat if necessary. Refer to EM-71, "
VALVE SEAT REPLACEMENT" .
9. Replace the valve guide if necessary. Refer to EM-70, "
VALVE GUIDE REPLACEMENT" .
10. Remove the spark plug tube, as necessary.

Remove the spark plug tube out of the cylinder head using suitable tool.
CAUTION:

Do not damage the cylinder head.

Do not remove the spark plug tube unless absolutely necessary. Once removed, the spark
plug tube will be deformed and cannot be reused.
ASSEMBLY
1. Install the valve guide if necessary. Refer to EM-70, "VALVE GUIDE REPLACEMENT" .
2. Install the valve seat if necessary. Refer to EM-71, "
VALVE SEAT REPLACEMENT" .
3. Install the valve oil seal using Tool.

Apply new engine oil on the new valve oil seal joint and seal
lip.

Install the valve oil seal to the specified height "H".
4. Install the valves in their original position.
5. Install the valve spring seats.
6. Install the valve springs.

Install the narrow pitch end (paint mark side) to the cylinder
head side.
7. Install the valve spring retainers. Tool number
: KV10107902 (J-38959)
WBIA0478E
Tool number : KV10115600 (J-38958)
Height "H" (without valve spring installed)
Intake and exhaust : 14.3 - 14.9 mm (0.563 - 0.587 in)
WBIA0490E
SEM085D

EM-86Revision: November 2009
CYLINDER BLOCK
2006 QX56
15. Tighten connecting rod bolts using Tool.

Apply engine oil to threads and seats of connecting rod bolts.

After tightening bolts, make sure the crankshaft rotates
smoothly.

Check connecting rod side clearance. Refer to EM-94, "CON-
NECTING ROD SIDE CLEARANCE" .
16. Install knock sensors. CAUTION:
If knock sensor is dropped, replace it with a new one.

Make sure that there is no foreign material on the cylinder
block mating surface and the back surface of knock sensor.

Install it with its connector facing the center of the cylinder
block side.

Do not tighten knock sensor bolts while holding connector.

Make sure knock sensor does not interfere with other parts.

Position the sub-harness as shown before installing intake
manifold.
17. Installation of the remaining components is in the reverse order of removal.
18. Remove engine assembly from engine stand.
19. Install drive plate.

Align dowel pin of crankshaft rear end with pin holes of each
part to install. Tool number : KV10112100 (BT-8653-A)
Connecting rod bolts
Step 1
: 19.6 N·m (1.5 kg-m, 11 ft-lb)
Step 2 : 90° clockwise
WBIA0627E
KBIA2493E
KBIA2549E
KBIA2494E

INSTRUMENT PANEL ASSEMBLYIP-17
C
DE
F
G H
J
K L
M A
B
IP
Revision: November 2009 2006 QX56
Removal
1. Move front seats forward.
2. Disconnect battery negative terminal.
3. Remove control device. Refer to AT- 2 2 6 , "
Control Device Removal and Installation" .
4. Remove glove box assembly. Refer to IP-14, "
Lower Instrument Panel RH and Glove Box" .
5. Remove center console lower cover RH.
6. Remove console cover RH screws.
7. Remove center console lower cover LH.
8. Remove console cover LH screws.
9. Disconnect center console electrical connectors.
10. Remove center console assembly in a rearward direction.
Installation
Installation is in the reverse order of removal.
Center ConsoleEIS007X7
DISASSEMBLY AND ASSEMBLY
Disassembly
1. Remove mats from storage compartment and console bin.
2. Remove latch from console lid and remove key cylinder from latch.
3. Remove console lid.
4. Remove console bin.
5. Disconnect electrical harness from DVD player (if equipped).
6. Remove hinge.
7. Remove rear upper finisher.
8. Remove rear cup holder assembly.
9. Remove rear finisher assembly.
10. Disconnect rear finisher assembly electrical connectors.
11. Remove console power socket.
12. Remove upper side finishers LH/RH.
13. Remove heat duct and console rear duct.
14. Disconnect clips and remove console covers LH/RH.
15. Remove mask and storage compartment.
16. Remove console front bracket.
17. Remove console rear bracket.
ASSEMBLY
Assembly is in the reverse order of disassembly.
1. Console lid assembly 2. A/T finisher 3. Tray
4. Storage compartment 5. Storage compartment mask 6. Console reinforcement assembly
7. Center console lower cover LH 8. Console front bracket 9. Lower side finisher LH
10. Console cover LH 11. Rear console duct 12. Power socket assembly
13. Rear cup holder assembly 14. Rear finisher assembly 15. Console rear bracket
16. Heat duct 17. Rear upper finisher 18. Console bin mat
19. Console bin 20. Console cover RH 21. Center console lower cover RH
22. Lower side finisher RH 23. A/T transmission control 24. Mask
25. Cup holder insert

RF-26
SUNROOF
Revision: November 20092006 QX56
SUNROOF UNIT
Removal
CAUTION:

Always work with a helper.

When taking sunroof unit out, use shop cloths to protect the seats and trim from damage.

After installing the sunroof unit and glass lid assembly, check gap adjustment to make sure there
is no malfunction.
1. Remove headlining. Refer to EI-38, "
HEADLINING" .
2. Remove the sunroof glass lid assembly. Refer to RF-26, "
GLASS LID ASSEMBLY" .
3. Remove overhead console bracket.
4. Disconnect front and rear drain hoses.
5. Remove front sunroof frame assembly bolts.
6. Remove rear sunroof bracket bolts.
7. Remove the sunroof frame assembly side bolts, then the sunroof unit.
Installation
1. Position the sunroof frame assembly and install the side bolts.
2. Install the sunroof brackets and bolts.
3. Install the front sunroof frame assembly bolts.
4. Connect front and rear drain hoses.
5. Install the overhead console bracket.
6. Install the sunroof glass lid assembly. Refer to RF-26, "
GLASS LID ASSEMBLY" .
NOTE:
Adjust sunroof glass lid assembly gap and height, refer to RF-23, "
Fitting Adjustment" .
7. Install headlining. Refer to EI-38, "
HEADLINING" .
GLASS LID ASSEMBLY
Removal
1. Open sunshade assembly.
NOTE:
Be sure glass lid assembly is fully closed.
2. Remove side cover LH and RH.
3. Remove the glass lid assembly screws at the sunroof frame assembly.
4. Remove the glass lid assembly.
Installation
1. Position glass lid assembly to sunroof frame assembly.
2. Install glass lid assembly screws. NOTE:
First tighten left front screw, then right rear to prevent movement while tightening the remaining screws.
1. Glass lid assembly 2. Wind deflector3. Rear drain hoses
4. Shade stoppers 5. Sunroof bracket 6. Sunshade assembly
7. Front drain hoses 8. Sunroof motor assembly9. Sunroof frame assembly
10. Overhead console bracket 11. Side cover LH 12. Side cover RH
WIIA0252E
