Page 2849 of 3573

ISUZU TROOPER 1998 Service Repair Manual 8DÐ256 WIRING SYSTEM Diagnosis Quick Chart for Check Points Trouble modeCheck point All the doors do not lock and unlock by door lock SW-Drivers sideFuse (C-18 20A)FRT Door lock (& power window) S

Page 2850 of 3573

ISUZU TROOPER 1998 Service Repair Manual WIRING SYSTEM 8DÐ257 1. All The Doors Do Not Lock And Unlock By Door Lock SW-DriverÕs Side YES ·IS B-18 GROUNDED SECURELY? YES REPLACE THE FUSE NO ·IS FUSE C-18 (20A) NORMAL? · ·DISCONNECT THE

Page 2851 of 3573

ISUZU TROOPER 1998 Service Repair Manual 8DÐ258 WIRING SYSTEM 2. All The Doors Do Not Get Locked (Or Unlocked) By FRT Door Lock SW-PassengerÕs Side YES ·CHECK THE DOOR LOCKING CONDITION BY DOOR LOCK SW-DRIVERS SIDE ·IS THE CONTINUITY IN

Page 2852 of 3573

ISUZU TROOPER 1998 Service Repair Manual WIRING SYSTEM 8DÐ259 8. Door Lock Does Not Operate When Operated From The Door Lock Key SW-DriverÕs Side YES ·IS THE CONTINUITY IN THE DOOR LOCK KEY SW-DRIVER’S SIDE NORMAL? YES REFER TO ITEM 1 I

Page 2853 of 3573

ISUZU TROOPER 1998 Service Repair Manual 8DÐ260 WIRING SYSTEM 9. Door Lock Does Not Operate When Operated From The Door Lock Key SW-PassengerÕs Side YES ·IS THE CONTINUITY IN THE DOOR LOCK KEY SW- PASSENGER’S SIDE YES REFER TO ITEM 1 IN

Page 2854 of 3573

ISUZU TROOPER 1998 Service Repair Manual WIRING SYSTEM 8DÐ261 Power Window General Description The circuit consists of (door lock &) power window switch for each of front windows, power window switch for rear doors and power window motors.

Page 2855 of 3573

ISUZU TROOPER 1998 Service Repair Manual 8DÐ262 WIRING SYSTEM Circuit Diagram (RHD) B-371 B-372 B-37 3 B-37 4A A B-19 H-234D-570.3 R/Y0.3 R/Y2.0 L/B 1.25 B 1.25 B BODY-RH BODY-RH2.0 L/B 2.0 L/B 2.0 L/W 1.25 B 0.3 B 0.5 L/W0.5 L/W3.0 B/Y STA

Page 2856 of 3573

ISUZU TROOPER 1998 Service Repair Manual WIRING SYSTEM 8DÐ263 Parts Location (RHD) Legend (1) D-27 (2) D-20 (3) R-3 (4) D-22 (5) H-28, H-29 (6) D-11 (7) D-14 (8) H-46 (9) H-18, H-19 (10) B-1, B-2(11) B-26 (12) H-34, H-35 (13) H-47 (14) D-2
