Page 401 of 4323

A23476
ECM EB4
EB4
Female
Connector Male
Connector Knock Sensor
83 4
783 4
7 2 1
2 1
E7
E7
E7
E728
21
20KNK1
EKNK
KNK2
EKN2 29
± DIAGNOSTICSENGINE
DI±207
401 Author: Date:
2005 SEQUOIA (RM1146U)
1 Connect hand±held tester, and check knock sensor circuit.
PREPARATION:
(a) Disconnect the EB4 connector.
(b) Using lead wires, connect the EB4 connectors as follows.
Male Connector ± Female Connector
Terminal 4 ± Terminal 8
Terminal 3 ± Terminal 7
Terminal 8 ± Terminal 4
Terminal 7 ± Terminal 3
(c) Warm up the engine.
(d) Run the engine at 3,000 rpm for 10 seconds or more.
CHECK:
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch to ON and turn the hand±held tes-
ter ON.
(c) Select the item: DIAGNOSIS / ENHANCED OBD II / DTC
INFO / CURRENT CODES.
(d) Read DTCs.
Result :
DisplayProceed to
DTCs same as when vehicle brought in
P0325, P0327, P0328 " P0325, P0327, P0328
or
P0330, P0332, P0333 " P0330, P0332, P0333
A
DTC different from when vehicle brought in
P0325 " P0330
or
P0330 " P0325
B
DTCs different from when vehicle brought in
P0327, P0328 " P0332, P0333
or
P0332, P0333 " P0327, P0328
C
(e) Reconnect the EB4 connector.
B Go to step 4.
C Go to step 5.
A
Page 402 of 4323
B17411
KNK1
KNK2EKN2
EKNK E7
DI±208
± DIAGNOSTICSENGINE
402 Author: Date:
2005 SEQUOIA (RM1146U)
2 Check for open and short in harness and connector between EB4 connector and
ECM (See page IN±35).
NG Repair or replace harness or connector.
OK
3 Measure voltage between terminals KNK1 and EKNK, KNK2 and EKN2 of ECM.
PREPARATION:
(a) Disconnect the E7 ECM connector.
(b) Turn the ignition switch to ON.
CHECK:
(a) Measure the voltage between the specified ECM termi-
nals.
OK:
Standard:
Tester ConnectionSpecified Condition
KNK1 (E7±29) ± EKNK (E7±28)4.5 to 5.5 V
KNK2 (E7±21) ± EKN2 (E7±20)4.5 to 5.5 V
(b) Reconnect the ECM connector.
NG Replace ECM (See page SF±80).
OK
Check for intermittent problems
(See page DI±11).
4 Check knock sensor installation.
CHECK:
Check the knock sensor installation.
OK:
Torque: 20 NVm (204 kgfVcm, 15 ftVlbf)
NG Tighten the sensor.
OK
Page 403 of 4323
A23513
Male Connector
EB4
Wire Harness Side:
Front View
± DIAGNOSTICSENGINE
DI±209
403 Author: Date:
2005 SEQUOIA (RM1146U)
Replace knock sensor (See page SF±66).
5 Check knock sensor.
PREPARATION:
(a) Disconnect the EB4 connector.
CHECK:
(a) Check the resistance between the terminals of the EB4
male connector.
OK:
Standard:
Tester ConnectionSpecified Condition
EB4 male connector 3 ±4120 to 280 kW
EB4 male connector 7 ± 8120 to 280 kW
(b) Reconnect the EB4 connector.
OK Check for intermittent problems
(See page DI±11).
NG
6 Check for open and short in harness and connector between EB4 connector and
knock sensor (See page IN±35).
HINT:
If DTC P0327 or P0328 has changed to P0332 or P0333, check the knock sensor circuit on the right
bank side.
If DTC P0332 or P0333 has changed to P0327 or P0328, check the knock sensor circuit on the left
bank side.
NG Repair or replace harness or connector.
OK
Replace knock sensor.
Page 404 of 4323

FI7059
FI7060A00069
G2 and NE Signal Waveforms
20 msec./Division (Idling)
10 msec./Division (Idling)5 V
/Division
G2
NE
5 V
/Division
G2
NE DI±210
± DIAGNOSTICSENGINE
404 Author: Date:
2005 SEQUOIA (RM1146U)
DTC P0335 Crankshaft Position Sensor ºAº Circuit
DTC P0339 Crankshaft Position Sensor ºAº Circuit In-
termittent
CIRCUIT DESCRIPTION
The crankshaft position sensor system consists of a crankshaft position sensor plate and a pick±up coil.
The sensor plate has 32 teeth and is installed on the crankshaft. The pick±up coil is made of an iron core
and magnet. The sensor plate rotates and as each tooth passes through the pick±up coil, a pulse signal is
created. The pick±up coil generates 32 signals for each engine revolution. Based on these signals, the ECM
calculates the crankshaft position and engine RPM. Using these calculations, the fuel injection time and igni-
tion timing are controlled.
DTC No.DTC Detecting ConditionTrouble Area
P0335
No crankshaft position sensor signal to ECM during crank-
ing (2 trip detection logic)Open or short in crankshaft position sensor circuit
Crankshaft position sensor
P0335No crankshaft position sensor signal to ECM with engine
speed 450 rpm or more (1 trip detection logic)
Crankshaft osition sensor
Signal plate
ECM
P0339
In condition (a), (b) and (c), when no crankshaft position
sensor (NE) signal is input for 0.05 sec. or more. :
(1 trip detection logic)
(c) Engine revolution 1,000 rpm or more
(d) STA signal is OFF
(e) 3 sec. or more has lapsed after STA signal is switched
from ON to OFF.
Open or short in crankshaft position sensor circuit
Crankshaft position sensor
Signal plate
ECM
Reference: Inspection using the oscilloscope.
The correct waveform is as shown in the illustration.
Tester ConnectionSpecified Condition
VV1+ (E6±25) ± VV1± (E6±24)
VV2+ (E6±18) ± VV2± (E6±28)Correct waveform is as shown
NE+ (E6±21) ± NE± (E6±20)
Correct waveform is as shown
DID86±01
Page 405 of 4323

± DIAGNOSTICSENGINE
DI±211
405 Author: Date:
2005 SEQUOIA (RM1146U)
MONITOR DESCRIPTION
If there are no signals from the crankshaft sensor even though the engine is revolving, the ECM interprets
this as a malfunction of the sensor.
MONITOR STRATEGY
Related DTCsP0335Crankshaft position sensor range check or ratio-
nality
Rid / tMain sensors/componentsCrankshaft position sensorRequired sensors/componentsRelated sensors/componentsEngine speed sensor
Frequency of operationContinuous
DurationCase 1: 0.016 sec.
Case 2: 3 times
MIL operationImmediate
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever this DTC is
not presentSee page DI±18
Case 1:
Engine speed450 rpm±
StarterOFF
Time after starter ON to OFF3 sec.±
Case 2:
Time after starter ON to OFF0.3 sec.±
Number of camshaft position sensor sig-
nal pulse3±
Battery voltage7 V±
Ignition switchON
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Case 1:
Engine speed signalNo signal for 0.016 sec.
Case 2:
Number of crankshaft position sensor signal pulse44 or less, or 58 or more
Page 406 of 4323
A19690
C1
Camshaft Position Sensor
C2
Crankshaft Position SensorLECM
NE+
NE±
E2 27
2 12 1
25
24 Y
R GE6
G2+
G2±
32
E6
E6
E6
*1: ShieldedE6E1
EC (*1) (*1)
J42 J/C
A
AA
BR
BR
BR1 DI±212
± DIAGNOSTICSENGINE
406 Author: Date:
2005 SEQUOIA (RM1146U)
WIRING DIAGRAM
Page 407 of 4323

A21026
Component Side
C2
Crankshaft Position Sensor
± DIAGNOSTICSENGINE
DI±213
407 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
HINT:
Read freeze frame data using the hand±held tester. Freeze frame records the engine conditions when
a malfunction is detected. When troubleshooting it is useful for determining whether the vehicle was
running or stopped. the engine was warmed up or not, the air±fuel ratio lean or rich, etc. at the time
of the malfunction.
READ VALUE ON HAND±HELD TESTER
(a) Connect the hand±held tester to the DLC3.
(b) Start the engine and push the hand±held tester tool main switch ON.
(c) When using hand±held tester, enter the following menu: ºDIAGNOSIS / ENHANCED OBD II / DATA
LIST / ALL / ENGINE SPDº.
The engine speed can be confirmed in DATA LIST using the hand±held tester. If there are no NE sig-
nals from the crankshaft position sensor despite the engine revolving, the engine speed will be indi-
cated as zero. If voltage output of the crankshaft position sensor is insufficient, the engine speed will
be indicated as lower RPM (than the actual RPM).
1 Check resistance of crankshaft position sensor.
PREPARATION:
Disconnect the C2 crankshaft position sensor connector.
CHECK:
Measure the resistance between terminals 1 and 2.
OK:
Standard:
Tester ConnectionSpecified Condition
1 ± 2985 to 1,600 W at cold
1 ± 21,265 to 1,890 W at hot
NOTICE:
º Coldº and ºHotº shown above mean the temperature of
the coils themselves. ºColdº is form ±10°C (14°F) to 50°C
(122°F) and ºHotº is from 50°C (122°F) to 100°C (212°F).
NG Replace crankshaft position sensor.
OK
Page 408 of 4323

A21027
Wire Harness Side
Crankshaft Position Sensor C2
B17414
E6ECM Connector
NE± NE+
BR3795OK NGClearance
DI±214
± DIAGNOSTICSENGINE
408 Author: Date:
2005 SEQUOIA (RM1146U)
2 Check for open and short in harness and connector between ECM and
crankshaft position sensor.
PREPARATION:
(a) Disconnect the C2 crankshaft position sensor connector.
(b) Disconnect the E6 ECM connector.
CHECK:
Measure the resistance between the wire harness side connec-
tors.
OK:
Standard:
Tester ConnectionSpecified Condition
Crankshaft position sensor (C2±1) ±
NE+ (E6±21)Below 1 W
Crankshaft position sensor (C2±2) ±
NE± (E6±20)Below 1 W
Crankshaft position sensor (C2±1) or
NE+ (E6±21) ± Body ground10 kW or higher
Crankshaft position sensor (C2±2) or
NE± (E6±20) ± Body ground10 kW or higher
NG Repair or replace harness or connector.
OK
3 Check sensor installation (crankshaft position sensor).
CHECK:
Check the crankshaft position sensor installation.
OK:
The crankshaft position sensor is installed properly.
NG Tighten sensor installation bolt.
OK
