Page 2753 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SF130±04 B17536Tube Joint Clip B17537 Nylon Tube Fuel Tube Joint O±Ring Tube Joint Clip B17538 SST Rib ± SFIFUEL PUMP SF±11 2745 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. REMOVE FUEL TAN

Page 2754 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SF1XE±01 B17539 B17540 Unlock Slide (a) B17543 B17544 B17608 SF±12 ± SFIFUEL PUMP 2746 Author: Date: 2005 SEQUOIA (RM1146U) DISASSEMBLY 1. REMOVE FUEL SENDER GAUGE (a) Disconnect the sender ga

Page 2755 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17541 B17545 B17546 B17609 B17548 ± SFIFUEL PUMP SF±13 2747 Author: Date: 2005 SEQUOIA (RM1146U) (d) Using a screwdriver with the tip wrapped in tape, discon- nect the 3 snap±claws from the fu

Page 2756 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17549 SF±14 ± SFIFUEL PUMP 2748 Author: Date: 2005 SEQUOIA (RM1146U) 5. REMOVE FUEL SUCTION PLATE NO.2 (a) Using a screwdriver, remove the 2 E±rings from the suc- tion plate No.2. (b) Remove t

Page 2757 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17610 Ohmmeter SF131±03 B17611Battery 1 2 ± SFIFUEL PUMP SF±15 2749 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION 1. INSPECT FUEL PUMP RESISTANCE Using an ohmmeter, measure the resistance be

Page 2758 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SF1XF±01 B17549 B17548 B17609 B17546 B17542 SF±16 ± SFIFUEL PUMP 2750 Author: Date: 2005 SEQUOIA (RM1146U) REASSEMBLY 1. REMOVE FUEL SUCTION PLATE NO.2 (a) Install the 2 springs and suction pla

Page 2759 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17541 B17608 B17544 B17543 B17540 ± SFIFUEL PUMP SF±17 2751 Author: Date: 2005 SEQUOIA (RM1146U) 4. INSTALL FUEL SUB±TANK (a) Connect the fuel suction plate No.2 to the fuel sub±tank with the

Page 2760 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17539 SF±18 ± SFIFUEL PUMP 2752 Author: Date: 2005 SEQUOIA (RM1146U) (b) Connect the sender gauge connector to the fuel suction plate No.1.
