Page 937 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F16806 High (45°)Low (±45°) Normal (0°) Connector Front View: SHG SHRLSHB ± DIAGNOSTICSAIR SUSPENSION SYSTEM DI±735 929 Author: Date: 2005 SEQUOIA (RM1146U) 5 Inspect height control sensor s

Page 938 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19442 Suspension Control ECU H16 Gate Solenoid Valve (Height Control Valve) W±L8 BM1SLRL 114 IN14 S25 BI W±B 2W±LW±L DI±736 ± DIAGNOSTICSAIR SUSPENSION SYSTEM 930 Author: Date: 2005 SEQUOIA

Page 939 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSAIR SUSPENSION SYSTEM DI±737 931 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION PROCEDURE HINT: If DTC C1761/61 (ECU malfunction) and/or C1774/74 (power source circuit) is display

Page 940 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19437 Connector Front View: 32 1 DI±738 ± DIAGNOSTICSAIR SUSPENSION SYSTEM 932 Author: Date: 2005 SEQUOIA (RM1146U) 2 Inspect gate solenoid valve (height control valve). PREPARATION: Disconnect

Page 941 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F16805 Suspension Control ECU Wire Harness View: S25 SLRL F19436 Height Control Valve Wire Harness View: H16 321 ± DIAGNOSTICSAIR SUSPENSION SYSTEM DI±739 933 Author: Date: 2005 SEQUOIA (RM11

Page 942 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19454 Suspension Control ECU H16 Leveling Solenoid Valve (Height Control Valve) LG±R4 BM1SLRR 313 IN13 S25 BI W±B 2LG±R LG±R DI±740 ± DIAGNOSTICSAIR SUSPENSION SYSTEM 934 Author: Date: 2005

Page 943 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSAIR SUSPENSION SYSTEM DI±741 935 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION PROCEDURE HINT: If DTC C1761/61 (ECU malfunction) and/or C1774/74 (power source circuit) is display

Page 944 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19437 Connector Front View: 32 1 DI±742 ± DIAGNOSTICSAIR SUSPENSION SYSTEM 936 Author: Date: 2005 SEQUOIA (RM1146U) 2 Inspect leveling solenoid valve (height control valve). PREPARATION: Discon
Load next 8 pages
