(2) Release the fitting lances and remove the holder.
(c) Install the holder.
(1) Install the connectors to the holder. (When locking,
a click sound can be heard.)
HINT:
The retainer is locked when the holder is connected.
Page 3306 of 4323
H23913
Connection is completed Lever
Holder (with connectors)
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
RS±15
3298 Author: Date:
2005 SEQUOIA (RM1146U)
21. CONNECTION OF CONNECTOR FOR AIRBAG SENSOR ASSY CENTER
(a) Firmly insert the holder (with connectors) until it can not be pushed any further.
(b) Push the lever to connect the holder (with connectors). (When locking, a click sound can be heard.)
HINT:
The holder slides when connecting. Be sure not to hold the holder while connecting, as it may result in an
insecure fit.
Page 3307 of 4323
H24685
Housing Lock (White Part) A
CPA (Yellow Part)
Connector
lock is
released
H24686
RS±16
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
3299 Author: Date:
2005 SEQUOIA (RM1146U)
22. DISCONNECTION OF CONNECTOR FOR FRONT AIRBAG SENSOR
(a) Push down the housing lock (white part) and slide the CPA (yellow part). (At this time, the connector
cannot be disconnected yet).
(b) Push down the housing lock (white part) again and disconnect the connector.
HINT:
Do not push down the A part shown in the illustration when disconnecting.
(c) After disconnecting the connector, check that the position of the housing lock (the white part) is as
shown in the illustration.
Page 3308 of 4323
H24687
H24688
Housing Lock
(White Part) A
CPA (Yellow Part)
Connection is
completed
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
RS±17
3300 Author: Date:
2005 SEQUOIA (RM1146U)
23. CONNECTION OF CONNECTOR FOR FRONT AIRBAG SENSOR
(a) Before connecting the connectors, check that the position of the housing lock (the white part) is as
shown in the illustration.
(b) Be sure to engage the connectors until they are locked. (When locking, make sure that a click sound
can be heard.)
HINT:
When connecting them, the housing lock (white part) slides. Be sure not to hold the housing lock (white part)
and A part, as it may result in an insecure fit.
Page 3309 of 4323
H01584
Slider
Disconnection is completed Slider
H01585
SliderSlider
RS±18
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
3301 Author: Date:
2005 SEQUOIA (RM1146U)
24. DISCONNECTION OF CONNECTOR FOR SIDE AIRBAG ASSEMBLY
(a) Place a finger on the slider, slide the slider to release the lock, and then disconnect the connector.
25. CONNECTION OF CONNECTOR FOR SIDE AIRBAG ASSEMBLY
(a) Connect the connector as shown in the illustration. (When locking, make sure that the slider returns
to its original position and a click sound can be heard.)
HINT:
When connecting, the slider will slide. Be sure not to touch the slider while connecting, as it may result in
an insecure fit.
Page 3310 of 4323
H02763
Outer
H02764
Lock of connector is released
Disconnection is completed
H02768
Outer
Outer
Connection is completed
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
RS±19
3302 Author: Date:
2005 SEQUOIA (RM1146U)
26. DISCONNECTION OF CONNECTORS FOR SIDE AIR-
BAG SENSOR AND CURTAIN SHIELD AIRBAG SEN-
SOR
(a) While holding both outer flank sides, slide the outer in the
direction shown by the arrow.
(b) When the connector lock is released, the connectors are
disconnected.
HINT:
Be sure to hold both outer flank sides. Holding the top and bot-
tom sides will make disconnection difficult.
27. CONNECTION OF CONNECTORS FOR SIDE AIRBAG SENSOR AND CURTAIN SHIELD AIRBAG
SENSOR
(a) Connect the connector as shown in the illustration. (When locking, make sure that the outer returns
to its original position and a click sound can be heard.)
HINT:
When connecting, the outer will slide. Be sure not to hold the outer while connecting, as it may result in an
insecure fit.
Page 3311 of 4323
RS0B8±15
H23200
Spiral Cable
Steering Column Cover Lower
Steering Wheel Pad
N´m (kgf´cm, ft´lbf): Specified torque
Steering Wheel
Steering Wheel Cover Lower No. 2
Steering Wheel Cover Lower No. 3
8.8 (90, 78 in.´lbf)
8.8 (90, 78 in.´lbf)
Torx® Screw Torx® Screw RS±20
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
3303 Author: Date:
2005 SEQUOIA (RM1146U)
STEERING WHEEL PAD AND SPIRAL CABLE
COMPONENTS
Page 3312 of 4323
RS0B9±13
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±21
3304 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
NOTICE:
If the wiring connector of the SRS is disconnected and the ignition switch is in the ON or ACC
position, DTCs will be recorded.
Never use airbag parts from another vehicle. When replacing parts, replace them with new
ones.
1. PRECAUTION (SEE PAGE RS±1 and RS±3)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
Wait for 90 seconds after disconnecting the cable to prevent the airbag working.
3. REMOVE STEERING WHEEL PAD (SEE PAGE SR±14)
4. REMOVE STEERING WHEEL (SEE PAGE SR±14)
5. REMOVE STEERING COLUMN COVER LOWER (SEE PAGE SR±14)
6. REMOVE SPIRAL CABLE (SEE PAGE SR±14)
