± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
3337 Author: Date:
2005 SEQUOIA (RM1146U)
(2) Wind the wire harness around the stud bolts of the
side airbag assembly as shown in the illustration.
(3) Position the side airbag assembly inside the tire
with the airbag deployment direction facing inside.
Tire size: Must exceed the following dimensions:
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Make sure that the wire harness is tight. If there is
slack in wire harness, the side airbag assembly may
become loose due to the shock when the airbag is
deployed.
Always tie down the side airbag assembly with the
airbag deployment side facing inside the tire.
NOTICE:
The tire will be marked by the airbag deployment, so use an
extra tire.
(f) Install the SST.
(1) Connect the SST connector to the side airbag as-
sembly connector.
SST 09082±00750
(g) Place the tires.
(1) Place at least 2 tires under the tire which the front
seat airbag assembly is tied to.
(2) Place at least 2 tires over the tire which the front
seat airbag assembly is tied to. The top tire should
have the disc wheel installed.
NOTICE:
Do not place the SST connector under the tire because it
could be damaged.
Page 3346 of 4323

H23917
H1749610 m (33 ft) or more SSTBattery
Side Airbag
Assembly
H00544
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS±55
3338 Author: Date:
2005 SEQUOIA (RM1146U)
(3) Tie the tires together with 2 wire harness.
CAUTION:
Make sure that the wire harness is tight. Looseness in the
wire harness results in the tires coming free due to the
shock when the airbag is deployed.
(h) Install the SST.
Connect the connectors of the 2 SST to the side airbag
assembly connector.
SST 09082±00700
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock. Also, se-
cure some slack for the SST wire harness inside the tire.
(i) Deploy the airbag.
(1) Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip of the SST to the
battery negative (±) terminal.
(2) Check that no one is within a 10 m (33 ft) radius of
the tire which the front seat airbag assembly LH is
tied to.
(3) Press the SST activation switch and deploy the air-
bag.
CAUTION:
When deploying the airbag, make sure that no one is near
the tire.
HINT:
The airbag deploys as the LED of the SST activation switch
comes on.
Page 3347 of 4323

RS0LD±06
RS±56
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
3339 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the seat frame assembly or seatback cover with a new one.
CaseReplacing part
The side airbag has been deployed.Seat assembly
The side airbag assembly has been found to be faulty in troubleshooting.Seat frame assembly
The side airbag assembly has been found to have cuts while checking items
(see page RS±49).Seat frame assembly
The seatback cover has been found to have cuts and frayed seams while
checking items
(see page RS±49).
Seatback cover
The side airbag assembly has been found to be faulty while checking items
(See page RS±49).Seat frame assembly
The seatback cover has been found to be faulty while checking items
(see page RS±49).Seatback cover
The seatback assembly has been dropped.Seat frame assembly
CAUTION:
For removal and installation of the seat frame assembly, see page RS±46 and RS±57. Be sure to fol-
low the correct procedure.
Page 3348 of 4323

RS11C±01
H24319
H24318Hog Ring
H24321Hog Ring
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS±57
3340 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
HINT:
Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
NOTICE:
If the side airbag assembly has been dropped, or
there are cracks, dents or other defects in the case or
connector, replace the side airbag assembly with a
new one.
When installing the side airbag assembly, take care
it is not pinched between other parts.
Never use airbag parts from another vehicle. When
replacing parts, replace them with new ones.
1. INSTALL SEATBACK COVER
(a) Install the seatback cover to the seatback pad.
(b) Install the 2 headrest supports.
(c) Turn up the seatback cover and install the hog rings.
2. INSTALL SEATBACK COVER AND PAD
(a) Install the seatback cover and pad to the seat frame as-
sembly.
(b) Install the 2 headrest supports to the seat frame assem-
bly.
(c) Install the hog rings to the seat frame assembly.
(d) Install the hog rings to the seat frame assembly.
Page 3349 of 4323

H24861
H24317
H24316
H24315
RS±58
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
3341 Author: Date:
2005 SEQUOIA (RM1146U)
(e) w/ Side airbag:
Connect the seatback cover bracket to the seat frame as-
sembly with the nut.
Torque: 5.5 N´m (56 kgf´cm, 49 in.´lbf)
(f) Close the fastener.
(g) Install the hog rings to the seat frame assembly.
3. INSTALL ARMREST ASSEMBLY
(a) Install the spacer to the armrest assembly.
(b) Install the armrest assembly, armrest lock plate and arm-
rest spacer with the bolt.
Torque: 37 N´m (377 kgf´cm, 27 ft´lbf)
HINT:
Install the armrest lock plate as shown in the illustration.
(c) Install the armrest cap.
4. INSTALL POWER SWITCH
Install the power switch with the 3 screws.
5. INSTALL LUMBAR SWITCH
Install the lumbar switch with the 2 screws to the seat cushion
outer shield.
6. INSTALL FRONT SEAT INNER BELT
(a) Install the front seat inner belt with the nut.
Torque: 42 N´m (428 kgf´cm, 31 ft´lbf)
(b) Connect the connectors and wire harness clamps.
7. INSTALL SEAT CUSHION LOWER SHIELD, SEAT
CUSHION OUTER SHIELD AND SEAT CUSHION IN-
NER SHIELD
(a) Assemble the seat cushion lower shield and seat cushion
outer shield with the screw.
(b) Perform the same procedure on the other side.
(c) Connect the lumbar switch connector to the lumbar
switch, and install the seat cushion lower shield, outer
shield and inner shield.
Page 3350 of 4323

H24314
H24313
H24312
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS±59
3342 Author: Date:
2005 SEQUOIA (RM1146U)
(d) Install the 2 screws to the seat cushion lower shield.
(e) Install the 2 screws to the seat cushion inner shield.
(f) Install the 2 screws to the seat cushion outer shield.
(g) Install the screw to the seat cushion outer shield.
8. INSTALL SLIDE KNOB AND RECLINING KNOB
9. INSTALL HEADREST
10. INSTALL FRONT SEAT
Mount the front seat to the vehicle.
NOTICE:
Be careful not to damage the body.
(a) w/ Side airbag:
Connect the connectors.
(b) Connect the connectors.
(c) Slide the front seat to the rearmost position.
(d) Tighten the bolts on the front side temporarily, starting
from the bolt on the inner side.
(e) Tighten them completely.
Torque: 37 N´m (377 kgf´cm, 27 ft´lbf)
(f) Slide the front seat to the foremost position.
(g) Tighten the bolts on the rear side temporarily, starting
from the bolt on the inner side.
(h) Tighten them completely.
Torque: 37 N´m (377 kgf´cm, 27 ft´lbf)
11. INSTALL SEAT TRACK COVERS
12. CONNECT CABLE TO NEGATIVE BATTERY TERMI-
NAL
13. PERFORM INITIALIZATION (SEE PAGE BE±77)
Some system need initialization when disconnecting the cable
from the negative battery terminal.
14. INSPECT SRS WARNING LIGHT (SEE PAGE DI±1137)
Page 3351 of 4323
RS0TD±04
H24667
42 (428, 31)
37 (377, 27)
8.0 (82, 72 in.´lbf)
37 (377, 27)
37 (377, 27)
37 (377, 27)
37 (377, 27)
Seatback CoverSeatback Pad
Front Seat Inner Belt Seat Cushion Inner Shield
Seat Cushion Outer ShieldArmrest CapArmrest SpacerArmrest Lock Plate
Headrest
Headrest Support
Armrest Assembly
Seat Track Cover
Seat Track Cover
Seat Position
Sensor Protector
Driver's seat:
Seat Position Sensor
Driver's seat:
Torx) Screw Seat Frame Assembly Hog Ring
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable part Spacer
Reclining Adjuster Release Handle
Vertical Adjuster Handle Cap
Vertical Adjuster Handle
w/ Side Airbag:
5.5 (56, 49 in.´lbf)
RS±60
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
3343 Author: Date:
2005 SEQUOIA (RM1146U)
SIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
COMPONENTS
Page 3352 of 4323

RS11D±01
H24331ClawClip
H24332
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
RS±61
3344 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
HINT:
Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
NOTICE:
If the wiring connector of the SRS is disconnected
and the ignition switch is in the ON or ACC position,
DTCs will be recorded.
Never use airbag parts from another vehicle. When
replacing parts, replace them with new ones.
1. PRECAUTION (SEE PAGE RS±1 and RS±3)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
Wait for 90 seconds after disconnecting the cable to prevent the
airbag working.
3. REMOVE SEAT TRACK COVERS
Using a screwdriver, remove the 2 seat track covers.
HINT:
Tape the screwdriver tip before use.
4. REMOVE FRONT SEAT
(a) Remove the 4 bolts.
(b) Disconnect the connectors.
(c) w/ Side airbag:
Disconnect the airbag connector.
(d) Remove the front seat.
NOTICE:
Be careful not to damage the body.
5. REMOVE HEADREST
6. REMOVE SEAT CUSHION OUTER SHIELD
(a) Remove the screw from the seat cushion outer shield.
(b) Using a screwdriver, remove the seat cushion outer
shield.
HINT:
Tape the screwdriver tip before use.
7. REMOVE RECLINING ADJUSTER RELEASE HANDLE
8. REMOVE VERTICAL ADJUSTER HANDLE
(a) Using a screwdriver, remove the vertical adjuster handle
cap.
HINT:
Tape the screwdriver tip before use.
