Page 2761 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SF1XG±01 B17551 KeywayKey B17552 ºSº Mark Triangle Mark B17553 SST Rib ºMAX.º Mark ºAº Mark Triangle Mark B17489Tube Joint Clip ± SFIFUEL PUMP SF±19 2753 Author: Date: 2005 SEQUOIA (RM114

Page 2762 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SF±20 ± SFIFUEL PUMP 2754 Author: Date: 2005 SEQUOIA (RM1146U) NOTICE: Check that there are no scratches or foreign objects on the connecting part. Check that the fuel tube joint is inserted s

Page 2763 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SF0XZ±14 B17758 Vacuum Hose Fuel Pressure Regulator N´m (kgf´cm, ft´lbf)  Non±reusable part: Specified torque  O±RingFuel Return Hose 7.5 (80, 66 in.´lbf) ± SFIFUEL PRESSURE REGULATOR SF±21

Page 2764 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B07053 Vacuum Hose Fuel Return Hose SF0Y0±10 B17759 SF±22 ± SFIFUEL PRESSURE REGULATOR 2756 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL REMOVE FUEL PRESSURE REGULATOR (a) Disconnect the vacuum

Page 2765 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17760 Install Turn SF0Y1±13 B07053 Vacuum Hose Fuel Return Hose ± SFIFUEL PRESSURE REGULATOR SF±23 2757 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION 1. INSTALL FUEL PRESSURE REGULATOR (a)

Page 2766 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SF0OR±12 B04442 Ohmmeter SF±24 ± SFIINJECTOR 2758 Author: Date: 2005 SEQUOIA (RM1146U) INJECTOR ON±VEHICLE INSPECTION 1. REMOVE THROTTLE BODY COVER 2. REMOVE INTAKE AIR CONNECTOR 3. INSPECT IN

Page 2767 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SF0OS±16 B17459 Throttle Body Cover PS Air Hose Intake Air Connector Suction Hose MAF Meter Wire PCV Hose Vacuum Hose ± SFIINJECTOR SF±25 2759 Author: Date: 2005 SEQUOIA (RM1146U) COMPONENTS

Page 2768 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17460 Engine Wire Clamp Fuel Pressure Regulator  Gasket Upper Gasket  Lower Gasket RH Delivery Pipe Front Fuel Pipe  Grommet Injector  Insulator Fuel Main Hose VSV for EVAPFuel Pressure Pulsatio
