2001 TOYOTA SEQUOIA Service Repair Manual

ESP fuel tank removal set clock spare tire location key fob keyless

Load previous 8 pages

Page 4249 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
390
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
When storing the spare tire, put it in
place with the outer side of the wheel
facing up. Then secure the tire, taking
care that

Page 4250 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
391
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
3. Remove the wheel ornament.
Pry off the wheel ornament, using the
beveled end of the wheel nut wrench
as shown.
Type A onlyÐT

Page 4251 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
392
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Front Rear
5. Position the jack at the correct
jack point as shown.
Make sure the jack is positioned on
a level and solid place.

Page 4252 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
393
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
To raise the vehicle, insert the jack
handle extension in to the jack (it is
a loose fit) and turn it clockwise with
the handle,

Page 4253 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
394
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
8. Reinstall all the wheel nuts fin-
ger tight.
Reinstall the wheel nuts (tapered end
inward) and tighten them as much as
you ca

Page 4254 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
395
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Tighten each nut a little at a time in
the order shown. Repeat the process
until all the nuts are tight.
CAUTION
When lowering

Page 4255 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
396
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
11. Check the air pressure of the re-
placed tire.
Adjust the air pressure to the specifi-
cation designated on page 458 in
Sect

05_SEQUOIA_U (L/O 0408)
396
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
11. Check the air pressure of the re-
placed tire.
Adjust the air pressure to the specifi-
cation designated on page 458 in
Section 8. If the pressure is lower,
drive slowly to the nearest service
station and fill to the correct pressure.
Do not forget to reinstall the tire infla-
tion valve cap as dirt and moisture
could get into the valve core and
possibly cause air leakage. If the cap
is missing, have a new one put on as
soon as possible.
12.Restow all the tools, jack and
flat tire securely.
With a spare tire of the same wheel
type as the installed tiresÐ
As soon after changing wheels as
possible, tighten the wheel nuts to the
torque specified on page 458 in Sec-
tion 8 with a torque wrench. Have a
technician repair the flat tire.With a spare tire of different wheel
type from the installed tiresÐ
As soon after changing wheels as
possible, tighten the wheel nuts to the
torque specified on page 458 in Sec-
tion 8 with a torque wrench. Have a
technician repair the flat tire and re-
place the spare tire with it.
Initial adjustment of the tire pres-
sure warning system is necessary
after you have replaced your tires
or wheels. See ªTire pressure
warning systemº on page 198 in
Section 1±7.
CAUTION
Before driving, make sure all the
tools, jack and flat tire are se-
curely in place in their storage
location to reduce the possibility
of personal injury during a colli-
sion or sudden braking.
If your vehicle becomes stuck in snow,
mud, sand, etc., then you may attempt
to rock the vehicle free by moving it
forward and backward.
Two±wheel drive modelsÐTurn off the
traction control system to become un-
stuck to allow the tires to spin enough
to remove the vehicle from the obstruc-
tion. (For details, see ªTraction control
systemº on page 182 in Section 1±7.)
CAUTION
Do not attempt to rock the vehicle
free by moving it forward and back-
ward if people or objects are any-
where near the vehicle. During the
rocking operation the vehicle may
suddenly move forward or backward
as it becomes unstuck, causing injury
or damage to nearby people or ob-
jects.
ÐAfter changing wheels If your vehicle becomes stuck

Page 4256 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
397
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
NOTICE
If you rock your vehicle, observe the
following precautions to prevent dam-
age to the transmission and other
parts.
Do
