Page 4081 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
222
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
TEXT
Radio
This button is operational only in RDS
mode.
When an RDS radio station transmits a
text message, ªTEXTº will be dis

05_SEQUOIA_U (L/O 0408)
222
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
TEXT
Radio
This button is operational only in RDS
mode.
When an RDS radio station transmits a
text message, ªTEXTº will be displayed. At
this time, push the ªTEXTº button to view
the text message. The message display
will be canceled if any button that affects
the display is pushed. To view the mes-
sage again, push this button again. After
the entire message has been displayed,
the message will disappear.
The RDS audio system has memory to
store three 64±character messages. To
store a message in memory, push and
hold the ªTEXTº button until you hear a
beep.
If three messages are already stored in
memory, the oldest message will be over-
written by the new message.
To recall a radio text message, push the
ªTEXTº button momentarily. This will dis-
play the most recent message. Each push
of the button will display messages in the
order of most to least recent.If no messages have been stored, or if
there are no more messages to be re-
called, ªNO MESSAGEº will appear on the
display, and the message display will be
canceled.
The message display will be canceled if
you activate any function that affects the
display.
Compact disc player
This button is used to change the display
for the compact disc that contains text
data.
To change the display, quickly push and
release the ªTEXTº button while the com-
pact disc is playing. The display changes
in the order from the elapsed time to disc
title to track title, then back to the
elapsed time.
If this button is pushed while a compact
disc that does not contain text data is
playing, ªNO TITLEº will appear on the
display.
If the entire disc or track title does not
appear on the display, push and hold the
button until you hear a beep. The rest of
the title will appear.TRAF (Traffic)
This button turns the traffic announcement
(TA) feature on and off. This button is
operational only in FM mode.
By pushing the ªTRAFº button, ªTRAF
SEEKº will flash on the display and the
radio will start seeking any traffic program
station.
When a traffic program station is found,
ªTRAFº will be displayed and you will hear
a beep.
After the traffic announcement program is
over, the display returns to the previous
mode.
If no traffic program station is found, ªNO
TRAF INFOº appears on the display for a
few seconds and the display returns to
the previous mode.
To cancel the traffic announcement, push
this button again.
TUNE (Tuning)
Turn the ªTUNEº knob clockwise to step
up the frequency. Turn the knob counter-
clockwise to step down the frequency.

Page 4082 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
223
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
TYPE (Program Types)
When you push the ªTYPEº button while
receiving an RDS station, the current pro-
gram type appears on th

Page 4083 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
224
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Some parts of the audio system can be
adjusted using the switches on the steer-
ing wheel.
Details of the specific switches, con

Page 4084 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
225
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
1. Volume control switch
Push ª+º to increase the volume. The vol-
ume continues to increase while the
switch is being pushed.

05_SEQUOIA_U (L/O 0408)
225
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
1. Volume control switch
Push ª+º to increase the volume. The vol-
ume continues to increase while the
switch is being pushed.
Push ª±º to decrease the volume. The
volume continues to decrease while the
switch is being pushed.
2. ªº switch
Radio
This switch has the following featuresÐ
To select a preset station:
Quickly push and release the ªº or ªº
side of the switch. Do this again to select
the next preset station.
To seek a station:
Push and hold the ªº or ªº side of the
switch until you hear a beep. Do this
again to find the next station. If you push
the switch on either side during the seek
mode, seeking will be cancelled.
Cassette player
This switch has the following featuresÐ
To skip to a different track in either direc-
tion:
Quickly push and release the ªº or ªº
side of the switch. ªFF 1º or ªREW 1º will
appear on the display.Next, push either side of the track switch
until the track you want to listen to is set.
If you push the switch ten times, the skip
function will turn off. (You can skip up to
nine tracks at a time.)
When counting the number of the tracks
you want to rewind, remember to count
the current track as well. For example, if
you want to rewind to a song that is two
tracks before the song you are listening
to, push the ªº side of the switch three
times.
If you push the track switch further than
you wanted to, push the other side of the
switch. The track number will be in-
creased or reduced.
The track number you select is not valid
if it is higher than the number of the
tracks remaining on the current side of
the cassette.
When the tape reaches to the begin-
ning, the player will automatically start
playing that side.
After the tape reaches to the end, the
player will automatically reverse and
start playing the other side.There must be at least 3 seconds of blank
space between tracks for the track switch
to work correctly. In addition, the feature
may not work well with some spoken, live,
or classical recordings.
To fast forward or reverse:
Push and hold the ªº side of the switch
to fast forward a cassette tape. ªFFº will
appear on the display. Push and hold the
ªº side of the switch to rewind a tape.
ªREWº will appear on the display.
To stop the tape while it is fast forward-
ing, push the ªº side of the switch. To
stop the tape while it is rewinding, push
the ªº side of the switch.
If a tape rewinds completely, the cassette
player will stop and then play that same
side. If a tape fast forwards completely,
the cassette will play the other side of the
tape using the auto±reverse feature.
Compact disc player
Use this switch to skip up or down to a
different track in either direction.
Quickly push and release the ªº or ªº
side of the switch until the track you want
to listen to is set. If you want to return
to the beginning of the current track, push
the ªº side of the switch once, quickly.

Page 4085 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
226
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Vehicles with rear seat entertainment sys-
temÐ
While the DVD player is in operation, the
chapter or track can be changed by pu

05_SEQUOIA_U (L/O 0408)
226
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Vehicles with rear seat entertainment sys-
temÐ
While the DVD player is in operation, the
chapter or track can be changed by push-
ing the ªº or ªº side of the switch.
3. ªMODEº switch
Push the ªMODEº switch to select an au-
dio mode. Each push changes the mode
sequentially if the desired mode is ready
to use. The DVD player will be selectable
if a rear seat entertainment system is
installed in your vehicle.
To turn the audio system on, push the
ªMODEº switch.
To turn the audio system off, push and
hold the ªMODEº switch until the system
turns off.The rear seat audio system is designed
for the rear seat passengers to enjoy the
audio sound separately between the front
seats and the rear seats.
The rear seat audio system can be turned
on with the rear audio system controller
even if the front audio system is off.
When the front audio is turned off, the
rear audio system will be turned off simul-
taneously.
The rear passengers can enjoy all the
modes (AM and FM radio, cassette tape
player and compact disc player with
changer) with the rear seat audio system
when a cassette tape and a compact disc
are loaded in the front audio system.
When the same mode is selected on the
front and rear audio systems at the same
time, the system can be operated on the
front audio system.
If the radio mode is selected on the front
and rear audio systems at the same time,
AM and FM modes cannot be changed on
the rear seat audio system.You can enjoy the rear seat entertainment
system with commercial headphone. See
ªÐHeadphone input jacksº on page 234 in
this Section for details.
You can also enjoy the rear seat enter-
tainment system with a wireless head-
phone. The wireless headphone can be
used within rear seat. If the signal be-
comes weak, the headphone will mute.
For details, refer to the manufacturer 's
instructions.
With some wireless headphone generally
available in the market, it may be difficult
to catch sound properly. Toyota recom-
mends the use of Toyota genuine wireless
headphone.
You can purchase a wireless headphone
at a Toyota dealer.
CAUTION
Do not drive with using the head-
phone. Otherwise, you may be hard
to hear the sound from the outside
while using the headphone and may
cause an accident.
Rear seat audio systemÐ

Page 4086 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
227
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
The rear seat audio system consists of
following components.
1. Front audio system
2. Rear seat audio system display
3. Rear sea

Page 4087 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
228
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
BEFORE USING THE CONTROLLER
(for new vehicle owners)
A battery is already set in the control-
ler with an insulating sheet, whi

Page 4088 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
229
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
CONTROLLER HOLDER
The controller can be stowed in the
holder when it is not in use. The holder
can be hooked on the back of the
