TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±823
1017 Author: Date:
2005 SEQUOIA (RM1146U)Item
Measurement item/
Range (Display)Normal ConditionDiagnostic Note
TIRE TEMP1
ID1 temperature in tire

Page 1026 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±824
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
1018 Author: Date:
2005 SEQUOIA (RM1146U) INIT THRESHOLD5
ID5 initial threshold of low±pres-
sure/
min.: 0 kpa (0 kgf´cm, 0 psi),
max.: 637.5

Page 1027 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDK6±01
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±825
1019 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
HINT:
If no abnormality is found when the parts are inspected,

DIDK6±01
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±825
1019 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
HINT:
If no abnormality is found when the parts are inspected, inspect the tire pressure monitor ECU.
If a malfunction code is displayed during the DTC check, inspect the circuit listed for that code. For
details of each code, refer to the ºSee pageº under respective ºDTC No.º in the DTC chart.
DTC chart of Tire Pressure Warning:
DTC No.
(See Page)Detection ItemTrouble Area
C2111/11
(DI±827)Transmitter ID1 operation stop
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
C2112/12
(DI±827)Transmitter ID2 operation stop
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
C2113/13
(DI±827)Transmitter ID3 operation stop
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
C2114/14
(DI±827)Transmitter ID4 operation stop
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
C2115/15
(DI±827)Transmitter ID5 operation stop
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
C2121/21
(DI±834)Transmitter ID1 not received
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
Wire harness
C2122/22
(DI±834)Transmitter ID2 not received
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
Wire harness
C2123/23
(DI±834)Transmitter ID3 not received
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
Wire harness
C2124/24
(DI±834)Transmitter ID4 not received
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
Wire harness
C2125/25
(DI±834)Transmitter ID5 not received
Tire pressure monitor valve sub±assy
Tire pressure monitor receiver assy
Tire pressure monitor ECU
Wire harness
C2141/41
(DI±842)Transmitter ID1 error
Tire pressure monitor valve sub±assy
Tire pressure monitor ECU
Tire pressure monitor receiver assy
C2142/42
(DI±842)Transmitter ID2 error
Tire pressure monitor valve sub±assy
Tire pressure monitor ECU
Tire pressure monitor receiver assy
C2143/43
(DI±842)Transmitter ID3 error
Tire pressure monitor valve sub±assy
Tire pressure monitor ECU
Tire pressure monitor receiver assy
C2144/44
(DI±842)Transmitter ID4 error
Tire pressure monitor valve sub±assy
Tire pressure monitor ECU
Tire pressure monitor receiver assy
C2145/45
(DI±842)Transmitter ID5 error
Tire pressure monitor valve sub±assy
Tire pressure monitor ECU
Tire pressure monitor receiver assy

Page 1028 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±826
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
1020 Author: Date:
2005 SEQUOIA (RM1146U)C2165/65
(DI±847)
Abnormal temperature inside ID1 tire
Tire pressure monitor valve sub±assy
Tire pre

Page 1029 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDK7±01
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±827
1021 Author: Date:
2005 SEQUOIA (RM1146U)
CIRCUIT INSPECTION
DTC C2111/11 Transmitter ID1 Operation Stop
DTC C2112/12 Transmitter ID2 O

Page 1030 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±828
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
1022 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
NOTICE:
It is necessary to register an ID code after replacing the tire pressure m

Page 1031 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±829
1023 Author: Date:
2005 SEQUOIA (RM1146U)
4 Forcibly transmit transmitter ID.
PREPARATION:
(a) Forcibly transmit the transmitter ID by performing

Page 1032 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19136
Tire Pressure Monitor ECU:
T17
RF5V
GND2RDA
F19137
Tire Pressure Monitor Receiver Assy:
T19
+5V
GNDRDA
F19138
Tire Pressure Monitor ECU:
T17
RF5V
GND2
DI±830
± DIAGNOSTICSTIRE PRESSURE WARNIN
