TOYOTA SEQUOIA 2001 Service Repair Manual DIDCV±01
C00083
DLC3
CG TS
F16800
Height
Control
Manual
Indicator
Lamp
± DIAGNOSTICSAIR SUSPENSION SYSTEM
DI±711
905 Author: Date:
2005 SEQUOIA (RM1146U)
TEST MODE PROCEDURE
1. INPUT SIGNAL

Page 914 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual C00083
DLC3
CG TC
TS
F16800
Height
Control
Manual
Indicator
Lamp
DI±712
± DIAGNOSTICSAIR SUSPENSION SYSTEM
906 Author: Date:
2005 SEQUOIA (RM1146U)
The TS terminal circuit uses CAN (Control

Page 915 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F16802
0.25 sec. 0.5 sec.
ON
OFF
0.25 sec.4.5 sec.
ON
OFF1.5 sec. Normal:
Code 82:
0.5 sec.
Repeat
± DIAGNOSTICSAIR SUSPENSION SYSTEM
DI±713
907 Author: Date:
2005 SEQUOIA (RM1146U)
HINT:
As ex

Page 916 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual A08841
Hand±held
Tester
DLC3
DI±714
± DIAGNOSTICSAIR SUSPENSION SYSTEM
908 Author: Date:
2005 SEQUOIA (RM1146U)
DTC of air suspension system test mode (input signal check) function:
If a troubl

A08841
Hand±held
Tester
DLC3
DI±714
± DIAGNOSTICSAIR SUSPENSION SYSTEM
908 Author: Date:
2005 SEQUOIA (RM1146U)
DTC of air suspension system test mode (input signal check) function:
If a trouble code is displayed during the test mode DTC check, check the circuit listed for that code. For details
of each code, refer to ºSee pageº under the respective DTC No. in the chart.
DTC No.
(See Page)Detection ItemTrouble Area
C1782/82
(DI±767)Stop light switch circuit malfunction
Stop light switch assy
Stop light switch circuit
Suspension control ECU
C1783/83
(DI±770)Door courtesy switch circuit malfunction
Door courtesy light switch assy
W/ Motor back door assy
Door courtesy light switch circuit
Body ECU
Back door ECU
Suspension control ECU
C1786/86
(DI±774)Height control switch circuit malfunction
Height control switch
Height control switch circuit
Suspension control ECU
C1788/88
(DI±778)Height control mode select switch circuit malfunction
Height control mode select switch
Height control mode select switch circuit
Suspension control ECU
2. INPUT SIGNAL CHECK (Using Hand±held Tester)
HINT:
This function checks if signals from the stop light switch
assy and the door courtesy lamp switch, etc. are being in-
put normally to the ECU.
When entering test mode, the suspension control ECU
sets all the test mode DTCs first.
After completing the test mode for each check item, the
test mode DTCs that are determined normal by the sus-
pension control ECU will be erased.
The test mode DTCs for other check items may not be
erased when only a certain signal is inspected.
When the test mode returns back to normal mode, all the
test mode DTCs will be erased.
(a) Procedure for Test Mode (Input signal check).
(1) Make sure that the ignition switch is off.
(2) Set each of the check items to the condition shown
under Operation (A) in the test mode table on the
next page.
(3) Connect the hand±held tester to the DLC3.
(4) Turn the ignition switch to the ON position.
(5) Select TEST MODE mode on the hand±held tester.
(6) Set each of the check items to the condition shown
under Operation (B) in the test mode table below.

Page 917 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSAIR SUSPENSION SYSTEM
DI±715
909 Author: Date:
2005 SEQUOIA (RM1146U)
Test mode (input signal check) table:
Check ItemOperation (A)Operation (B)
Stop light switch signalOFF (Brake p

Page 918 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDCZ±01
DI±716
± DIAGNOSTICSAIR SUSPENSION SYSTEM
910 Author: Date:
2005 SEQUOIA (RM1146U)
PROBLEM SYMPTOMS TABLE
HINT:
If a normal system code is displayed during the DTC check but the probl

DIDCZ±01
DI±716
± DIAGNOSTICSAIR SUSPENSION SYSTEM
910 Author: Date:
2005 SEQUOIA (RM1146U)
PROBLEM SYMPTOMS TABLE
HINT:
If a normal system code is displayed during the DTC check but the problem still occurs, check the cir-
cuits for each problem symptom in the order given in the table below and proceed to the relevant trou-
bleshooting page.
Inspect the fuse before inspecting the suspected areas as shown in the chart below.
Inspect each malfunction circuit in numerical order for the corresponding symptom.
If the malfunction still exists even after checking and confirming that all the circuits are normal, replace
the suspension control ECU.
SymptomSuspected AreaSee page
Vehicle height control function does not operate.
If the compressor remains on for an excessive period of
time or turns on and off repeatedly, the system control will
be halted for up to 70 minutes, after which the system will
return to normal operation.
1. Air tube is seized
2. Power source circuit
3. IG signal circuit
4. Crankshaft position sensor circuit
5. Height control mode select switch circuit
6. Height control switch circuit
7. Height control sensor circuit
8. Leveling solenoid valve circuit
9. Gate solenoid valve circuit
10.Exhaust solenoid valve circuit
11. AIR SUS relay circuit
12.Height control compressor circuit
13.Suspension control ECU
±
DI±761
DI±793
DI±210
DI±778
DI±774
DI±731
DI±740
DI±736
DI±744
DI±747
DI±752
IN±35
Illuminated position of height control indicator lamp does not
change by the height control switch operation.
1. Power source circuit
2. Crankshaft position sensor circuit
3. Height control mode select switch circuit
4. Height control switch circuit
5. Height control sensor circuit
6. Leveling solenoid valve circuit
7. Gate solenoid valve circuit
8. Exhaust solenoid valve circuit
9. AIR SUS relay circuit
10.Height control compressor circuit
11. Speed sensor circuit
12.CAN communication circuit
13.Suspension control ECUDI±763
DI±761
DI±793
DI±210
DI±778
DI±774
DI±731
DI±740
DI±736
DI±744
DI±783
DI±1065
IN±35
Hunting of vehicle height occurs.
1. Air leakage (Height control cylinder assy rear)
2. Height control sensor circuit
3. Suspension control ECUSA±156
DI±731
IN±35
Vehicle height control operates, but vehicle height is uneven.
1. Air leakage
2. Clogging of the air tube
3. Height control sensor link sub±assy
4. Height control sensor circuit
5. Gate solenoid valve circuit
6. Suspension control ECUSA±156
±
SA±156
DI±731
DI±736
IN±35
Vehicle height control operates, but vehicle height is high or
low (Vehicle height in NORMAL mode differs from the standard
value).1. Height control sensor link sub±assy
2. Height control sensor circuit
3. Suspension control ECUSA±156
DI±731
IN±35
When vehicle height control is adjusted, it stops at extremely high
or low position.1. Height control sensor circuit
2. Height control sensor link sub±assy
3. Suspension control ECUDI±731
SA±156
IN±35

Page 919 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSAIR SUSPENSION SYSTEM
DI±717
911 Author: Date:
2005 SEQUOIA (RM1146U) Height control manual indicator lamp condition is abnormal.
1. Power source circuit
2. Height control mode sele

Page 920 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDD3±01
F16803
S25
DI±718
± DIAGNOSTICSAIR SUSPENSION SYSTEM
912 Author: Date:
2005 SEQUOIA (RM1146U)
TERMINALS OF ECU
Symbols (Terminal No.)Wiring ColorTerminal
DescriptionConditionSpecified

DIDD3±01
F16803
S25
DI±718
± DIAGNOSTICSAIR SUSPENSION SYSTEM
912 Author: Date:
2005 SEQUOIA (RM1146U)
TERMINALS OF ECU
Symbols (Terminal No.)Wiring ColorTerminal
DescriptionConditionSpecified Condition
SLEX (S25±1) ± LR WB
Exhaust Sole-
id V l Si
IG switch ON "
E i idli b tt f h i ht t l it h i h dBelow 1.0 V "SLEX (S25 1)
GND (S25±22)L±R ± W±Bnoid Valve Sig-
nalEngine idling, button of height control switch is pushed
from ºUPº to ºDOWNºBelow 1.0 V "
9 V or more
SLRR (S25±3) ± LG R W B
Leveling Sole-
id V l Si
IG switch ON "
E i idli b tt f h i ht t l it h i h dBelow 1.0 V "SLRR (S25 3)
GND (S25±22)LG±R ± W±Bnoid Valve Sig-
nalEngine idling, button of height control switch is pushed
from ºDOWNº to ºUPºBelow 1.0 V "
9 V or more
SLRL (S25±4) ± WL WBGate SolenoidIG switch ON "
E i idli b tt f h i ht t l it h i h dBelow 1.0 V "SLRL (S25 4)
GND (S25±22)W±L ± W±BGate Solenoid
Valve SignalEngine idling, button of height control switch is pushed
from ºDOWNº to ºUPºBelow 1.0 V "
9 V or more
RC (S25±5) ± GY WBAIR SUS RelayIG switch ON "
E i idli b tt f h i ht t l it h i h dBelow 1.0 V "RC (S25 5)
GND (S25±22)G±Y ± W±BAIR SUS Relay
SignalEngine idling, button of height control switch is pushed
from ºNº to ºUPºBelow 1.0 V "
9 V or more
HI (S25±8) ± GR R W B
Height Control
I di t ºHIº
Engine idling, vehicle height is ºNORMALº "
P i th ºUPº b tt f th t l it h t10 V or more "HI (S25 8)
GND (S25±22)GR±R ± W±BIndicator ºHIº
SignalPressing the ºUPº button of the control switch turns on
the ºHIº indicator lamp (*1)10 V or more "
Below 5 V
NR (S25±9) ± BL WB
Height Control
I di t ºNº
Engine idling, vehicle height is ºNORMALº "
P i th ºUPº b tt f th t l it h tBelow 5 V "NR (S25 9)
GND (S25±22)B±L ± W±BIndicator ºNº
SignalPressing the ºUPº button of the control switch turns on
the ºHIº indicator lamp (*1)Below 5 V "
10 V or more
IG (S25±10) ±
GND (S25±22)B±R ± W±BIgnition SwitchIG switch ON10 to 14 V
VN (S25±11) ± LG W B
Height Control
MlIdi
IG switch ON, height control manual indicator lamp ON
" Pressin
g and releasing the height control mode selectBelow 5 V "VN (S25 11)
GND (S25±22)LG ± W±BManual Indica-
tor Lamp Signal" Pressing and releasing the height control mode select
switch turns off the height control manual indicator lamp
(*1)
Below 5 V "
10 V or more
TD (S25±12) ± BR B W B
Height Control
Md Sl t
IG switch ON, height control mode select switch pushed
iBelow 1.5 V "TD (S25 12)
GND (S25±22)BR±B ± W±BMode Select
Switchin
" Height control select switch releasedBelow 1.5 V "
10 to 14 V
UPSW (S25±13) ± LB WB
Height Control
S it h ºUPº
IG switch ON, ºUPº button of height control switch
hdiBelow 1.5 V "UPSW (S25 13)
GND (S25±22)L±B ± W±BSwitch ºUPº
Signalpushed in "
ºUPº button of height control switch releasedBelow 1.5 V "
10 to 14 V
SBL (S25±15) ±
SGL (S25±19)G±O ± L±R
Height Control
Sensor Power
Source
IG switch ON4.5 to 5.5 V
SHRL (S25±17) ± GR L L R
Height Control
SIt
IG switch ON "
E i idli hi l h i ht i h d f ºHIGHº t0.5 to 4.5 V "SHRL (S25 17)
SGL (S25±19)GR±L ± L±RSensor Input
SignalEngine idling, vehicle height is changed from ºHIGHº to
ºNORMALº by pressing the height control switch0.5 to 4.5 V "
Approx. 2.5 V
SGL (S25±19) ±
GND (S25±22)L±R ± W±BHeight Control
Sensor GroundAlwaysBelow 1.0 V
