Page 633 of 4323

A16555
AIR INJ CHECK
AIR PUMP............................ON
EASV ............................OPEN
ASV1. .............................OPEN
ASV2...............................OPEN
A/F BANK1.......................19.05
A/F BANK2.........................14.5
PRESSURE....................17 kPa
PULSATION..............25.39 kPa
AI STATUS...........................OK
Remaining Time 05 sec.
Press [EXIT] to quit
± DIAGNOSTICSENGINE
DI±431
625 Author: Date:
2005 SEQUOIA (RM1146U)
2 Check air injection system pressure.
PREPARATION:
(a) Start the engine and warm it up.
(b) Turn the ignition switch to OFF.
(c) Connect the hand±held tester to the DLC3.
(d) Turn the ignition switch to ON and push the hand±held
tester main switch ON.
(e) Start the engine.
CHECK:
(a) Select the following menu items: DIAGNOSIS/EN-
HANCED OBD II/SYSTEM CHECK/ AIR INJ CHECK/
MANUAL OPERATION/OPERATION 1 and 2
HINT:
OPERATION 1: AP:OFF, EASV:CLOSE, ASV1:CLOSE,
ASV2:CLOSE
OPERATION 2: AP:ON, EASV:OPEN, ASV1:OPEN,
ASV2:OPEN
(b) Check that the PRESSURE on the hand±held tester.
NOTICE:
This test only allows technicians to operate the AI system
for 5 seconds. Furthermore, the test can be performed 4
times a trip. If the test is repeated, intervals of at least 30
seconds are required between tests.
While the AI system operation using the hand±held tester
is prohibited, the tester displays the prohibition (WAIT or
ERROR). If the ERROR (AI STATUS NG) is displayed on the
tester, stop the engine for 10 minutes and then try again..
OK:
Tester operationPRESSURE
Operation 1Less then 2.5 kPa
Operation 25 to 8 kPa or more
NG Go to step 4.
OK
Page 634 of 4323

B17435Vacuum Hose
DI±432
± DIAGNOSTICSENGINE
626 Author: Date:
2005 SEQUOIA (RM1146U)
3 Check whether DTC output recurs.
PREPARATION:
(a) Start the engine and warm it up.
(b) Turn the ignition switch OFF.
(c) Connect a hand±held tester to the DLC3.
(d) Turn the ignition switch to ON and turn the tester ON.
(e) Clear the DTCs (see page DI±43).
(f) Start the engine.
CHECK:
(a) Perform SYSTEM CHECK to operate the air injection system.
Select the following menu items: DIAGNOSIS/ENHANCED OBD II/SYSTEM CHECK/AIR INJ
CHECK/AUTOMATIC OPERATION
(b) After operating the secondary air injection system, confirm the pending codes for the secondary air
injection system by selecting the following menu items: DIAGNOSIS / ENHANCED OBD II / DTC INFO
/ PENDING CODES.
(c) Read DTCs and check that no DTC is set.
OK:
DTC P2444 or P2445 for the secondary air injection system is not output.
NG Go to step 4.
OK
Check for intermittent problems
(See page DI±11).
4 Check vacuum hose.
CHECK:
(a) Remove the intake manifold (see page EM±36).
(b) Check the vacuum hose connection between the pres-
sure sensor and air switching valve.
OK:
The vacuum hose is securely connected.
CHECK:
(a) Check the vacuum hose for blockage or damage.
OK:
The vacuum hose has no blockage or damage.
NG Repair or replace vacuum hose.
OK
Page 635 of 4323

B17434
Pressure GaugePressure Sensor
B17436
± DIAGNOSTICSENGINE
DI±433
627 Author: Date:
2005 SEQUOIA (RM1146U)
5 Inspect ECM (air voltage).
PREPARATION:
(a) Remove the intake manifold (see page EM±36).
(b) Connect the pressure gauge to the pressure sensor as
shown in the illustration.
(c) Connect the hand±held tester to the DLC3 on the vehicle.
(d) Turn the ignition switch ON and push the hand±held tes-
ter main switch ON (Do not start engine).
(e) Select the following items: DIAGNOSIS / ENHANCED
OBD II / DATA LIST / AIR PUMP PRS.
CHECK:
Check that the pressure displayed on the hand±held tester fluc-
tuates when applying the pressure to the pressure sensor with
the pressure gauge.
OK:
Pressure fluctuates in response to the pressure ap-
plied with the pressure gauge.
NG Replace pressure sensor.
OK
6 Check connection of all air injection system piping and hoses.
CHECK:
(a) Remove the intake manifold (see page EM±36).
(b) Check that all the pipes and hoses between the air pump
and air switching valve are securely connected.
OK:
All the air injection pipes and hoses are securely con-
nected.
CHECK:
(a) Check the pipe and hoses for blockage or damage.
OK:
The air injection system pipes and hoses have no
blockage and damage.
NG Repair or replace air injection system piping.
OK
Page 636 of 4323
B17444
Wire Harness Side:
Air Injection Driver Connector
A41
+B
E
B17443
Wire Harness Side:
Air Injection Driver Connector
A40
BATT
DI±434
± DIAGNOSTICSENGINE
628 Author: Date:
2005 SEQUOIA (RM1146U)
7 Inspect air injection driver power source circuit.
PREPARATION:
(a) Remove the intake manifold (see page EM±36).
(b) Disconnect the A40 and A41 air injection driver connec-
tors.
(c) Turn the ignition switch to ON.
CHECK:
Measure the voltage between terminals A41±5 (+B) and A40±1
(BATT) of the air injection driver and body ground.
OK:
Standard:
Tester ConnectionSpecified Condition
A41±5 (+B) ± Body ground10 V or more
A40±1 (BATT) ± Body ground10 V or more
CHECK:
Measure the resistance between terminal A41±1 (E) of the air
injection driver and body ground.
OK:
Standard:
Tester ConnectionSpecified Condition
A41±1 (E) ± Body groundBelow 1 W
NG Repair or replace harness or connector.
OK
Page 637 of 4323

B17411
E4
AIRVAIRP
± DIAGNOSTICSENGINE
DI±435
629 Author: Date:
2005 SEQUOIA (RM1146U)
8 Check voltage between AIRP and AIRV terminal of ECM and body ground.
PREPARATION:
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch ON and turn the tester ON.
CHECK:
(a) When the air pump and air switching valve are operated
using the hand±held tester, measure the voltage between
terminals E4±25 (AIRP) and E4±4 (AIRV) of the air injec-
tion driver connector and body ground.
(b) Select the following menu items: DIAGNOSIS/EN-
HANCED OBD II/SYSTEM CHECK/AIR INJ CHECK/
MANUAL OPERATION/OPERATION 1 and 2
HINT:
OPERATION 1: AP:OFF, EASV:CLOSE, ASV1:CLOSE,
ASV2:CLOSE
OPERATION 2: AP: ON, EASV:OPEN, ASV1:OPEN,
ASV2:OPEN
NOTICE:
This test only allows technicians to operate the AI system
for 5 seconds. Furthermore, the test can be performed 4
times a trip. If the test is repeated, intervals of at least 30
seconds are required between tests.
While the AI system operation using the hand±held tester
is prohibited, the tester displays the prohibition (WAIT or
ERROR). If the ERROR (AI STATUS NG) is displayed on the
tester, stop the engine for 10 minutes and then try again..
OK:
Standard:
Air pump operationTester ConnectionSpecified Condition
ONE4±25 (AIRP) ±
Body ground10 V or more
OFFE4±25 (AIRP) ±
Body ground3.5 to 7.7 V*
ASV operation (EASV)Tester ConnectionSpecified Condition
OPENE4±4 (AIRV) ±
Body ground10 V or more
CLOSEE4±4 (AIRV) ±
Body ground3.5 to 7.7 V*
*: 35 to 55 % of the +B voltage.
NG Replace ECM (See page SF±80).
OK
Page 638 of 4323

B17444
Wire Harness Side:
Air Injection Driver Connector
A41
SIPSIV
DI±436
± DIAGNOSTICSENGINE
630 Author: Date:
2005 SEQUOIA (RM1146U)
9 Check voltage between SIV and SIP terminals of air injection driver and body
ground.
PREPARATION:
(a) Disconnect the A41 air injection driver connector.
(b) Connect the hand±held tester to the DLC3.
(c) Turn the ignition switch ON and turn the tester ON.
CHECK:
(a) When the air pump and air switching valve are operated
using the hand±held tester, measure the voltage between
terminals A41±3 (SIV) and A41±4 (SIP) of the air injection
driver connector and body ground.
(b) Select the following menu items: DIAGNOSIS/EN-
HANCED OBD II/SYSTEM CHECK/AIR INJ CHECK/
MANUAL OPERATION/OPERATION 1 and 2
HINT:
OPERATION 1: AP:OFF, EASV:CLOSE, ASV1:CLOSE,
ASV2:CLOSE
OPERATION 2: AP:ON, EASV:OPEN, ASV1:OPEN,
ASV2:OPEN
NOTICE:
This test only allows technicians to operate the AI system
for 5 seconds. Furthermore, the test can be performed 4
times a trip. If the test is repeated, intervals of at least 30
seconds are required between tests.
While the AI system operation using the hand±held tester
is prohibited, the tester displays the prohibition (WAIT or
ERROR). If the ERROR (AI STATUS NG) is displayed on the
tester, stop the engine for 10 minutes and then try again..
OK:
Standard:
Air pump operationTester ConnectionSpecified Condition
ONA41±3 (SIP) ± Body
ground10 V or more
OFFA41±3 (SIP) ± Body
ground3.5 to 7.7 V*
ASV operation (EASV)Tester ConnectionSpecified Condition
OPENA41±4 (SIV) ± Body
ground10 V or more
CLOSEA41±4 (SIV) ± Body
ground3.5 to 7.7 V*
*: 35 to 55 % of the +B voltage.
NG Repair or replace harness or connector be-
tween air injection driver and ECM.
OK
Page 639 of 4323

B17438
Wire Harness Side:
Air Pump Connector
A43
± DIAGNOSTICSENGINE
DI±437
631 Author: Date:
2005 SEQUOIA (RM1146U)
10 Check voltage between terminal 2 of air pump and body ground.
PREPARATION:
(a) Remove the intake manifold (see page EM±36).
(b) Disconnect the A43 air pump connector.
(c) Connect the hand±held tester to the DLC3.
(d) Turn the ignition switch ON and turn the tester ON.
CHECK:
(a) When the air pump is operated using the hand±held tes-
ter, measure the voltage between terminal A43±2 of the
air injection driver connector and body ground.
(b) Select the following menu items: DIAGNOSIS/EN-
HANCED OBD II/SYSTEM CHECK/ AIR INJ CHECK/
MANUAL OPERATION/OPERATION 1 and 2
HINT:
OPERATION 1: AP:OFF, EASV:CLOSE, ASV1:CLOSE,
ASV2:CLOSE
OPERATION 2: AP:ON, EASV:OPEN, ASV1:OPEN,
ASV2:OPEN
NOTICE:
This test only allows technicians to operate the AI system
for 5 seconds. Furthermore, the test can be performed 4
times a trip. If the test is repeated, intervals of at least 30
seconds are required between tests.
While the AI system operation using the hand±held tester
is prohibited, the tester displays the prohibition (WAIT or
ERROR). If the ERROR (AI STATUS NG) is displayed on the
tester, stop the engine for 10 minutes and then try again..
OK:
Standard:
Air pump operationTester ConnectionSpecified Condition
ONA43±2 ± Body ground10 V or more
OFFA43±2 ± Body groundBelow 1.0 V
NG Go to step 14.
OK
Page 640 of 4323
B17438
Wire Harness Side:
Air Pump Connector
A43
DI±438
± DIAGNOSTICSENGINE
632 Author: Date:
2005 SEQUOIA (RM1146U)
11 Check for open in harness and connector between air pump and body ground.
PREPARATION:
(a) Remove the intake manifold (see page EM±36).
(b) Disconnect the A43 air pump connector.
CHECK:
Check the resistance between the wire harness side connec-
tors and body ground.
OK:
Standard:
Tester ConnectionSpecified Condition
A43±1 ± Body groundBelow 1 W
NG Repair or replace harness or connector.
OK
