Page 3113 of 4323
SA15M±05
F14291
Brake Caliper
Disc Parking Brake Assembly Drain Plug
Gasket Filler Plug
Parking Brake
Cable Differential Carrier Axle Shaft (RH)
x10 Propeller ShaftAxle Shaft (LH)
Gasket
49 (500, 36)
Clip
O±ring
122 (1,244, 90)
Gasket
49 (500, 36)
15.5 (158, 11)
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable part
74 (750, 55)
73 (744, 53)
105 (1,070, 77)
8.0 (82, 71 in.´lbf)10 (102, 7.4)
2WD:
74 (750, 55)
Stud Bolt
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±109
3105 Author: Date:
2005 SEQUOIA (RM1146U)
REAR DIFFERENTIAL CARRIER
COMPONENTS
Page 3114 of 4323
F14292
N´m (kgf´cm, ft´lbf) : Specified torqueStraight Pin
Pinion ShaftPinion Gear
Thrust Washer
Side Gear
Ring Gear
Differential Case
Drive Pinion
Rear Bearing
Adjusting Washer
Bearing Spacer
Front Bearing
Dust Deflector Companion Flange
Bearing CapThrust Washer
Plate Washer
Side Bearing
Side Bearing
Plate Washer
Differential Carrier
Washer
Oil Seal
x12
125 (1,270, 92)
113 (1,150, 83)
113 (1,150, 83)
See page SA±119
Non±reusable part
Precoated part
Companion
Flange
2WD: SA±110
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3106 Author: Date:
2005 SEQUOIA (RM1146U)
Page 3115 of 4323

SA24E±02
F14273
SST
F14274
F14276
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±111
3107 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE 2 REAR WHEELS
Torque: 110 N´m (1,122 kgf´cm, 81 ft´lbf)
2. DRAIN HYPOID GEAR OIL
Torque: 49 N´m (500 kgf´cm, 36 ft´lbf)
3. DISCONNECT BRAKE LINES
(a) Using SST, disconnect the brake line and remove the clip.
SST 09023±00100
Torque: 15.5 N´m (158 kgf´cm, 11 ft´lbf)
(b) Use the same procedure described above to the other
side.
4. REMOVE BRAKE CALIPER AND DISC
(a) Remove the 2 bolts, brake caliper and disc.
Torque: 105 N´m (1,070 kgf´cm, 77 ft´lbf)
(b) Use the same procedure described above to the other
side.
5. REMOVE PARKING BRAKE ASSEMBLY
(a) Remove the parking brake assembly (See page
BR±43).
(b) Remove the 2 bolts and pull out the parking brake cable
from the backing plate.
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
(c) Use the same procedures described above to the other
side.
6. REMOVE AXLE SHAFTS
(a) Remove the 4 nuts.
Torque: 122 N´m (1,244 kgf´cm, 90 ft´lbf)
(b) Pull out the axle shaft and remove the O±ring.
NOTICE:
Be careful not to damage the oil seal.
(c) Use the same procedures described above to the other
side.
Page 3116 of 4323
F14294
Matchmarks
F14295
SA±112
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3108 Author: Date:
2005 SEQUOIA (RM1146U)
7. DISCONNECT REAR PROPELLER SHAFT
(a) 4WD:
(1) Place matchmarks on the propeller shaft and differ-
ential flange.
(2) Remove the 4 nuts, bolts, washers and disconnect
the propeller shaft.
Torque: 74 N´m (755 kgf´cm, 55 ft´lbf)
(b) 2WD:
(1) Place matchmarks on the propeller shaft and differ-
ential flange.
(2) Remove the 4 nuts, stud bolts, washers and discon-
nect the propeller shaft.
Torque: 74 N´m (755 kgf´cm, 55 ft´lbf)
(c) Support the propeller shaft securely.
8. REMOVE DIFFERENTIAL CARRIER ASSEMBLY
(a) Remove the 10 nuts, washers and differential carrier as-
sembly.
NOTICE:
Be careful not to damage the installation surface.
Torque: 73 N´m (744 kgf´cm, 53 ft´lbf)
(b) Remove the gasket.
Page 3117 of 4323

W00493
35 mm (1.38 in.)
SA24F±03
R04321
R04322
R04463
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±113
3109 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. CHECK COMPANION FLANGE RUNOUT
Using a dial indicator, measure the vertical and lateral runout of
the companion flange.
Maximum: runout: 0.09 mm (0.0035 in.)
If the runout exceeds the maximum, replace the companion
flange.
2. CHECK RING GEAR RUNOUT
Using a dial indicator, measure the ring gear runout.
Maximum runout: 0.05 mm (0.0020 in.)
If the runout exceeds the maximum, replace the ring gear.
3. CHECK RING GEAR BACKLASH
Using a dial indicator, while holding the companion flange, mea-
sure the ring gear backlash.
Backlash: 0.13 ± 0.18 mm (0.0051 ± 0.0071 in.)
HINT:
Measure at 3 or more positions around the circumference of the
ring gear.
If the backlash is not within the specified value, adjust the side
bearing preload or repair as necessary.
4. CHECK TOOTH CONTACT BETWEEN RING GEAR
AND DRIVE PINION (See page SA±119)
5. CHECK SIDE GEAR BACKLASH
Using a dial indicator, measure the side gear backlash while
holding one pinion gear toward the case.
Backlash: 0.05 ± 0.20 mm (0.0020 ± 0.0079 in.)
If the backlash is not within the specified value, replace the side
gear thrust washer of the different thickness (See page
SA±119).
Page 3118 of 4323

SA2352
F14486
40 mm
(1.57 in.)
F14485
SST
F14484
SST
SA±114
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3110 Author: Date:
2005 SEQUOIA (RM1146U)
6. MEASURE DRIVE PINION PRELOAD
Using a torque wrench, measure the preload of the drive pinion
using the backlash between the drive pinion and ring gear.
Preload (at starting):
0.8 ± 1.1 N´m (8 ± 11 kgf´cm, 7.0 ± 9.7 in.´lbf)
7. CHECK TOTAL PRELOAD
Using a torque wrench, measure the total preload with the teeth
of the drive pinion and ring gear in contact.
Total preload (at starting):
Drive pinion preload plus 0.4 ± 0.6 N´m (4 ± 6 kgf´cm,
3.5 ± 5.2 in.´lbf)
If necessary, disassemble and inspect the differential.
8. REMOVE COMPANION FLANGE
(a) Using a chisel and hammer, unstake the staked part of the
nut.
(b) 2WD:
Remove the companion flange nut.
(1) Using a torx® soket (E8), remove the stud bolt and
loosen the 3 bolts so that the heads come out 40
mm (1.57 in.).
(2) Set the SST and install the 3 nuts to the companion
flange.
SST 09213±58013
(3) Install the other SST to the set SST to hold the com-
panion flange, and remove the nut.
SST 09330±00021
(4) Remove the 3 nuts, stud bolts and SST from the
companion flange.
Page 3119 of 4323
SA2349
SST
R11391SST
SA2348
SST
Z00641
SST
R04324
Matchmarks
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±115
3111 Author: Date:
2005 SEQUOIA (RM1146U)
(c) 4WD:
Using SST to hold the flange, remove the nut.
SST 09330±00021
(d) Using SST, remove the companion flange.
SST 09950±30012 (09951±03010, 09953±03010,
09954±03010, 09955±03030, 09956±03050)
9. REMOVE FRONT OIL SEAL
Using SST, remove the oil seal from the differential carrier.
SST 09308±10010
10. REMOVE FRONT BEARING AND BEARING SPACER
(a) Using SST, remove the bearing from the drive pinion.
SST 09556±22010
If the front bearing is damaged or worn, replace the front bear-
ing.
(b) Remove the 2 washers and bearing spacer.
11. REMOVE DIFFERENTIAL CASE
(a) Place matchmarks on the bearing cap and differential car-
rier.
(b) Remove the 4 bolts and bearing cap.
Page 3120 of 4323

R04325
SST
R02482
SST
R04326
Front: Rear:
R04327
Matchmarks SA±116
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3112 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Using SST and a plastic hammer, remove the 2 side bear-
ing plate washers.
SST 09504±22012
HINT:
Measure the plate washer thickness and note it down.
(d) Remove the differential case with the bearing outer races
from the carrier.
HINT:
Tag the bearing outer races to show the location for reassem-
bling.
12. REMOVE DRIVE PINION FROM DIFFERENTIAL CAR-
RIER
Remove the drive pinion with the rear bearing.
13. REMOVE DRIVE PINION REAR BEARING
Using SST and a press, remove the bearing from the drive pin-
ion.
SST 09950±00020
HINT:
If the drive pinion or ring gear is damaged, replace them as a
set.
14. REMOVE FRONT AND REAR BEARING OUTER
RACES AND ADJUSTING WASHER
NOTICE:
Do not remove the outer races except when replacing the
bearings.
Using a brass bar and hammer, remove the outer races and ad-
justing washer from the carrier.
HINT:
Measure the adjusting washer thickness and note it down.
15. REMOVE RING GEAR
(a) Place matchmarks on the ring gear and differential case.
(b) Remove the 12 ring gear set bolts.
(c) Using a plastic hammer, tap on the ring gear to separate
it from the differential case.
16. CHECK DIFFERENTIAL CASE RUNOUT
(a) Install the differential case in the differential carrier (See
page SA±119).
