7. INSTALL TURN SIGNAL BRACKET
Using a torx® socket wrench, install the turn signal bracket with
2 new torx® screws.
Torque: 7.5 N´m (75 kgf´cm, 65 in.´lbf)
HINT:
Make sure that the protrusion on the steering column housing
is fitted into the hole of the turn signal bracket.
8. INSTALL RELEASE LEVER SPRING
9. INSTALL SHIFT LEVER HOUSING
Using a torx® socket wrench, install the shift lever housing with
3 new torx® screws.
Torque: 12 N´m (120 kgf´cm, 9 ft´lbf)
10. INSTALL PARK LOCK CABLE ASSEMBLY (See page
AT±21)
11. INSTALL SHIFT LEVER
Using a torx® socket wrench, install the shift lever with a new
torx® screw.
Torque: 18 N´m (180 kgf´cm, 13 ft´lbf)
12. INSTALL COLUMN UPPER BRACKET
(a) Install the column upper bracket with 2 new tapered±
head bolts.
HINT:
Insert the bracket pin into the column tube hole.
(b) Tighten the tapered±head bolts until the bolt heads break
off.
13. INSTALL KEY CYLINDER LAMP ASSEMBLY
14. INSTALL TRANSPONDER KEY COIL
Page 3258 of 4323

SR1KE±01
F17897Matchmarks
F17913
Matchmarks
± STEERINGTILT STEERING COLUMN
SR±23
3250 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
NOTICE:
When replacing the steering angle sensor, drive the vehicle
straight ahead at a speed of 6.5 mph (10.5 km/h) or more.
Accordingly, zero point calibration of the steering angle
sensor is performed.
HINT:
If the steering angle sensor zero point calibration is not per-
formed, its value will be fixed. Check after driving the vehicle
straight ahead at a speed of 6.5 mph (10.5 km/h) or more (See
page DI±946).
1. INSTALL NO. 2 INTERMEDIATE SHAFT ASSEMBLY
(a) Align the matchmark on the No. 2 intermediate shaft as-
sembly with the one on the control valve shaft.
(b) Install the bolt.
Torque: 35 N´m (360 kgf´cm, 26 ft´lbf)
2. CONNECT NO. 2 UNIVERSAL JOINT ASSEMBLY
(a) Align the matchmark on the column assembly with the
one on the No. 2 universal joint assembly.
(b) Install the bolt.
Torque: 35 N´m (360 kgf´cm, 26 ft´lbf)
3. INSTALL STEERING COLUMN ASSEMBLY WITH NO.
2 UNIVERSAL JOINT ASSEMBLY
(a) Install the column assembly with the No. 2 universal joint
assembly.
(b) Install the 4 steering column set nuts.
Torque: 26 N´m (260 kgf´cm, 19 ft´lbf)
NOTICE:
Take care not to rotate the steering shaft.
(c) Connect the connectors.
4. CONNECT TRANSMISSION CONTROL CABLE AS-
SEMBLY
Connect the cable assembly to the shift lever assembly.
Page 3259 of 4323

F13260
F17896
BMatchmarks
A
F19948
Mark
SR±24
± STEERINGTILT STEERING COLUMN
3251 Author: Date:
2005 SEQUOIA (RM1146U)
5. INSTALL COLUMN HOLE COVER NO. 2
Install the column hole cover No. 2 to the body with the 3 bolts.
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
6. INSTALL SLIDING YOKE
(a) Align the matchmark on the sliding yoke with the one on
the No. 2 intermediate shaft assembly.
(b) Install the ºBº bolt.
Torque: 35 N´m (360 kgf´cm, 26 ft´lbf)
(c) Install the ºAº bolt.
Torque: 35 N´m (360 kgf´cm, 26 ft´lbf)
7. INSTALL BRAKE PEDAL RETURN SPRING
8. INSTALL NO. 2 HEATER TO REGISTER DUCT
9. INSTALL LOWER LH FINISH PANEL
(a) Install the lower LH finish panel with the 4 bolts.
(b) Connect the hood lock release lever with the 2 screws.
10. INSTALL COWL SIDE TRIM AND FRONT DOOR
SCUFF PLATE
11. INSTALL SPIRAL CABLE (See page BE±26)
12. INSTALL COMBINATION SWITCH WITH SPIRAL
CABLE
(a) Install the combination switch with the 3 screws.
(b) Connect the airbag connector.
(c) Connect the 4 connectors.
13. INSTALL UPPER AND LOWER COLUMN COVERS
Install the upper and lower column covers with the 3 screws.
14. CENTER SPIRAL CABLE
(a) Check that the front wheels are facing straight ahead.
(b) Turn the cable counterclockwise by hand until it feels firm.
(c) Then rotate the cable clockwise about 2.5 turns to align
the marks.
HINT:
The cable will rotate about 2.5 turns to both the left and right
from the center.
Page 3260 of 4323

F17129
Torx® Screw
Screw Case
± STEERINGTILT STEERING COLUMN
SR±25
3252 Author: Date:
2005 SEQUOIA (RM1146U)
15. INSTALL STEERING WHEEL
(a) Align the matchmark on the wheel with the one on the
main shaft.
(b) Install the wheel set nut.
Torque: 50 N´m (510 kgf´cm, 37 ft´lbf)
16. INSTALL STEERING WHEEL PAD
NOTICE:
Never use airbag parts from another vehicle. When
replacing parts, replace with new ones.
Make sure that the wheel pad is installed with the spe-
cified torque.
If the wheel pad has been dropped, or there are
cracks, dents or other defects on the case or connec-
tor, replace the wheel pad with a new one.
When installing the wheel pad, take care that the wir-
ings do not interfere with other parts and are not
pinched between other parts.
(a) Connect the horn terminal.
(b) Connect the airbag connectors.
(c) Install the wheel pad after confirming that the circumfer-
ence groove of the torx® screw is caught on the screw
case.
(d) Using a torx® socket wrench (T30), tighten the 2 torx®
screws.
Torque: 8.8 N´m (90 kgf´cm, 78 in.´lbf)
(e) Install the steering wheel lower No. 2 cover.
(f) Install the steering wheel lower No. 3 cover.
17. CHECK STEERING WHEEL CENTER POINT
18. CONNECT CABLE TO NEGATIVE BATTERY TERMI-
NAL
19. PERFORM INITIALIZATION (See page IN±20)
Some systems need initialization when disconnecting the cable
from the negative battery terminal.
Page 3261 of 4323
SR0MD±08
F06723
Air Cleaner Assembly
with Air Cleaner HoseMAF Meter Connector
Clamp
Return Hose
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable part
Gasket
46.5 (475, 34)Clip
Vacuum Hose
Clip
Drive Belt
PS Vane Pump
Assembly44 (450, 33)
Pressure Feed Tube
22 (220, 16)
SR±26
± STEERINGPOWER STEERING VANE PUMP
3253 Author: Date:
2005 SEQUOIA (RM1146U)
POWER STEERING VANE PUMP
COMPONENTS
Page 3262 of 4323
F06720
Pressure Port Union
83 (850, 61)
O±Ring
Flow Control Valve
Spring
O±Ring
Suction Port Union
13 (130, 9)
Vane Pump Shaft
with Vane Pump Pulley
Oil Seal
Front Housing
Gasket
24 (240, 17)
Rear Housing
O±Ring
Wave Washer
Side Plate
Cam Ring
Straight Pin
Vane Pump
Rotor
Snap Ring x10Vane Plate
N´m (kgf´cm, ft´lbf): Specified torque
Non±reusable part
Power steering fluid
± STEERINGPOWER STEERING VANE PUMP
SR±27
3254 Author: Date:
2005 SEQUOIA (RM1146U)
Page 3263 of 4323
SR0ME±08
EM6656
SR±28
± STEERINGPOWER STEERING VANE PUMP
3255 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE AIR CLEANER ASSEMBLY WITH AIR
CLEANER HOSE
(a) Disconnect the MAF meter connector.
(b) Disconnect the hoses.
(c) Remove the clamp.
(d) Remove the 3 bolts and air cleaner assembly with air
cleaner hose connected.
2. REMOVE DRIVE BELT
Loosen the drive belt tension by turning the drive belt tensioner
counterclockwise, and remove the drive belt.
3. DISCONNECT 2 VACUUM HOSES
Remove the 2 clips and disconnect the 2 vacuum hoses.
4. DISCONNECT RETURN HOSE
Remove the clip and disconnect the return hose.
5. DISCONNECT PRESSURE FEED TUBE
Remove the union bolt and gasket, disconnect the pressure
feed tube.
6. REMOVE PS VANE PUMP ASSEMBLY
Remove the 2 bolts, nut, stud bolt and PS vane pump assembly.
Page 3264 of 4323

SR0V7±04
F06739
± STEERINGPOWER STEERING VANE PUMP
SR±29
3256 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
NOTICE:
When using a vise, do not overtighten it.
1. MEASURE PS VANE PUMP ROTATING TORQUE
(a) Check that the pump rotates smoothly without abnormal
noise.
(b) Temporarily install the bolt.
(c) Using a torque wrench, check the pump rotating torque.
Rotating torque:
0.28 N´m (2.8 kgf´cm, 2.4 in.´lbf) or less
2. REMOVE SUCTION PORT UNION
(a) Remove the bolt and suction port union.
(b) Remove the O±ring from the union.
3. REMOVE PRESSURE PORT UNION, FLOW CONTROL
VALVE AND SPRING
(a) Remove the pressure port union, the flow control valve
and spring.
(b) Remove the O±ring from the pressure port union.
4. REMOVE REAR HOUSING
(a) Remove the 4 bolts and rear housing.
HINT:
If the wave washer and side plate are stuck to the rear housing,
lightly tap the rear housing with a plastic hammer, and remove
the wave washer and side plate.
(b) Remove the 2 O±rings from the rear housing.
5. REMOVE WAVE WASHER
6. REMOVE SIDE PLATE
7. REMOVE GASKET
8. REMOVE CAM RING, 10 VANE PLATES AND VANE
PUMP ROTOR
(a) Using a screwdriver, remove the snap ring from the vane
pump shaft.
(b) Remove the cam ring, 10 vane plates and vane pump ro-
tor.
NOTICE:
Be careful not to drop the plates.
9. REMOVE VANE PUMP SHAFT WITH VANE PUMP
PULLEY
10. REMOVE STRAIGHT PINS
Remove the 2 pins from the front housing.
